ACR Electronics ResQFlare Quick Start Manual

SPECIFICATIONS
Product ResQFlare (Electronic Distress Flare)
Battery C Cell Alkaline Batteries (x2)
Battery
Replace Batteries Annually
Replacement
Light Source High Efficiency 0.5W LED (x7)
Light Color White
Dimension φ2.36" x 8.07" (φ60 x 205 mm)
Weight
0.3 lbs (135g)
(excluding batteries and flag)
SOS Distress Signal Light (meets
USCG specifications for a Night Visual
Function
Distress Signal as required by 33 CFR
part 175)
Light Intensity ≥75cd (6.2 miles visual distance)
≥20 hrs over 75 cd (room
Operation Time
temperature)
Waterproof Level IP67
Inherently Buoyant (no buoyancy/flo-
Buoyant
tation ring necessary)
Storage
-22°F ~ 149°F (-30°C ~ 65°C)
Temperature
Working Temp. 30.2°F - 86°F (-1°C~ 30°C)
Activation Manual
Warranty 1 Year
Fire-resistant, Oil-resistant, Mycete-
Environmental proof, Corrosion-proof, and Water-
Performance proof. Meet RoHS and asbestos-free
requirement.
Approval Certified to meet USCG 161.013, CE
approval
Product Distress Flag
Color of Flag Orange
Black Square + Black Circle (distress
Pattern of Flag
signal)
Dimensions
>35.43" x 35.43" (900 x 900 mm)
(L x W)
Weight >0.26 lbs (120 g)
Storage
-22°F ~ 149°F (-30°C ~ 65°C)
Temperature
Distress Flag (meets USCG
specifications for a Day Visual
Function
Distress Signal as required by 33 CFR
part 175)
Fly the flag by attaching to the mast or
simply hoisting to the highest possible
point. Flag can be displayed by hand,
tied to and then waved on items such
as a boat hook, paddle, or fishing rod,
Operation
or it can be laid flat on the deck to
attract aircraft. Should be used as a
day signal only and when displayed
correctly, the black square should be
over the black circle.
Approval Certified to meet USCG 160.072
F o r a d d i t i o n a l
i n f o r m a t i o n , p l e a s e v i s i t :
W W W . A C R A R T E X . C O M
Y1-06-0364 Rev. B
ACR Electronics
Quick Start Guide
ELECTRONIC DISTRESS FLARE
P R O D U C T N o . 3 9 6 6
