- Page 1 INSTRUCTION MANUAL Portable Fridge/Freezer Model: YT-B-55PX / YT-B-65PX / YT-B-75PX Specifications Sheets Products...
- Page 2 INSTRUCTION MANUAL Portable Fridge/Freezer Model: YT-B-55PX / YT-B-65PX / YT-B-75PX PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE CONNECTING AND OPERATING THE APPLIANCE. SAVE IT FOR FUTURE REFERENCE.
-
Page 3: Table Of Contents
Contents Product features Parts list Safety instructions Preparing before use Operation and function Battery protector setting (low voltage protection) Defrosting Replacing fuse and light PCB Cleaning and maintenance Troubleshooting Packing list Notice: Please pay attention to the below markings: Safety cautions: improper operation may cause personal injury or damage to the fridge. -
Page 4: Product Features
I. Product features Model: YT-B-55PX / YT-B-65PX / YT-B-75PX • The fridge is suitable for cooling and freezing foods or drinks,two compartments. • The device is designed to be operated from a 12 V DC or 24 V DC on-board supply socket of a vehicle (e. -
Page 5: Safety Instructions
III.Safety instructions We hereby declare that, the damage caused by the following acts shall NOT be responsible for: • Faulty installation or connection. • Over voltage and mechanical damage cause. • Failure to use the appliance as required by instruction manual. •... -
Page 6: Preparing Before Use
IV.Preparing before use 1. Use a damp cloth to clean the fridge inside and outside when use it for the first time. Specifics please refer to the “Cleaning and maintenance”. 2. For convenient using, the lid can be opened from front or back side. 3. - Page 7 • For using with alternating current AC 100-240V, please insert the AC plug into an AC socket. During normal using, emergency mode is not applicable. Emergency mode is only used while the operating panel is malfunctioning. 2. Operating panel 3. Turning on the fridge •...
- Page 8 • Combine to exchange centigrade degree and Fahrenheit degree. The setting temperature appears on the display for a few seconds. The display flashes several times and then the interior temperature is displayed again. Digital display will show the interior temperature of freezer compartment. Temperature range of the Display is -30-60°C NOTE If the ambient temperature is above +32°C (+90 °F), the minimum temperature...
-
Page 9: Battery Protector Setting (Low Voltage Protection)
6. Turning off the fridge button three seconds continually to turn off the fridge. Pull In working status, press out power plug. 7. Emergency Mode / USB port While the operating panel malfunctions, Emergency mode (EMERGENCY OVERRIDE) is applicable. Slide Emergency switch to EMERGENCY OVERRIDE position, start this function. In such mode, temperature setting function is not available, refrigerating speed is down, and this mode is only for provisional use. -
Page 10: Defrosting
While the battery protector cut off the battery connection, you should warrant the battery to be charged sufficiently, so as avoid frequent restarting of compressor. Voltage range of battery protector: Power Supply Status Battery protector Low Mode Medium Mode High Mode Cutting-off Voltage 10.1±0.3V 11.4±0.3V... -
Page 11: Replacing Fuse And Light Pcb
VIII.Replacing fuse and the light PCB 1. Steps for replacing plug fuse (12/24 V): • Unplug the DC power plug; • Turn anticlockwise the cap to remove it and fuse from the plug; • Replace the defective fuse with a new one that has the same rating (insert style 32V 10-15A);... -
Page 12: Troubleshooting
X. Troubleshooting The Error codes are depicted by a number of flashes by the Error light in a sequence every fours seconds. Fault code Reason Solution Check whether input power is matching or not; The ignition No power input. must be switched on in most vehicles to apply current to the cigarette lighter. -
Page 13: Packing List
If Error indicator light blinks, the compressor will restart every 60 seconds until it starts successfully. Under Emergency Mode, If Error indicator light blink every 4 seconds, it means that input voltage is lower than lowest starting voltage, you need charge your battery.
