SIK-Holz 8.30.6 Assembling Instruction

ASSEMBLING INSTRUCTION
8.30.6 Water Dispenser
Scope of delivery
Amount
1 water dispenser (stainless steel)
Sum
Tools
- tape measure, spirit level, power drill
- socket wrench 17 / 19 mm, screwdriver with insert Torx Bit (TX 10-30)
- suitable fastening material (screws)
- 1 person 1 h
Assembling
- Position the water dispenser on an on-site platform, stand or connection shaft, mark the fastening points for
the screw connection and the implementation of the on-site water supply and drill.
- Route the on-site water supply through the platform, stand or shaft and connect it to the water dispenser with
a GEKA coupling.
- Finally, the water dispenser must be attached to the platform, stand or shaft using suitable screws.
8.30.6.1 Water Dispenser (with ground sleeve)
Scope of delivery
Amount
1 water dispenser (stainless steel)
1 ground sleeve (stainless steel)
Sum
Tools
- spade, shovel, tape measure, spirit level, power drill
- socket wrench 17 / 19 mm, screwdriver with insert Torx Bit (TX 10-30)
- suitable fastening material (screws and dowels)
- 1 person 1 h
- approx. concrete 0.1 m³ C 20/25
Assembling
- Excavate foundation for ground sleeve and place 30 cm gravel layer to prevent waterlogging.
- Guide the ground sleeve over the on-site water supply and place it in the prepared hole, align it vertically so
that the ground sleeve surface can be horizontal and form the future footprint of the water dispenser.
- Finish the foundation properly according to the drawing and allow it to harden for approx. 3-5 days.
- Position the water dispenser on the foundation, mark and drill the fastening points for the screw connection.
- Connect the on-site water supply inside the water dispenser to the GEKA coupling.
- Finally, the water dispenser must be fixed to the foundation with suitable screws and dowels.
Notice: concrete needs about 28 days in order completely to harden.
Rev. 12.2022
FURTHER INFORMATIONS: SIK-HOLZGESTALTUNGS GMBH, LANGENLIPSDORF 54 A, D-14913 NIEDERGÖRSDORF; +49(0)33742.7990; WWW.SIK-HOLZ.DE; INFO@SIK-HOLZ.DE
All weights are approximate. The heaviest component is highlighted in bold.
All weights are approximate. The heaviest component is highlighted in bold.
Page 1 von 3
Denomination
Denomination
MASTER ENTERPRISE OF WOODCARVING HANDICRAFTS / © SIK-HOLZGESTALTUNGS GMBH
Measure
15 kg
approx. 15 kg
Measure
15 kg
3 kg
approx. 18 kg
