Summary of Contents for Race Result LED CLOCK
- Page 1 TITEL LED CLOCK Subtitel Setup & Operation Manual LED-Großanzeige — Anleitung | LED Clock — Instructions...
- Page 2 — Plug the power supply unit from the case, or another — Use the “OK“-Button for Start and Stop. compatible 12V power supply unit, into the LED Clock. — Use the “Edit“-Button to edit the settings for the — A 12V car battery can be used with an adapter.
- Page 3 The tripod legs inner braces should be aligned horizontally. Tighten the screw at the tripod, where the three legs come together. Under windy conditions, put the water filled weight ring on the tripod. LED-Großanzeige — Anleitung | LED Clock — Instructions...
- Page 4 Take the telescope pole (3) and the pass-through attachment (4) out of the case. Stick the attachment on the pole of the tripod, and pass the telescope-pole through the attachment into the tripod. Tighten the screw, when the desired height is reached.
- Page 5 2. Use the “±10S” button to activate or deactivate a 10s pre-countdown. — “-10” stands for deactivated pre-countdown. — “10” stands for activated pre-countdown. 3. For starting the timer, use the “OK”-button. 4. For reset, press the „Reset“-button (not labeled). LED-Großanzeige — Anleitung | LED Clock — Instructions...
-
Page 6: Interval Timer
Count-Down/Count-Up Timer General: — To set up a Count-Down or a Count-Up. — Count-Down: Counts down from preset time. — Count-Up: Counts up from preset time. — Format: HH:MM:SS Settings: 1. For Count-Up press the “Arrow-Up”-button. 2. For Count-Down press the “Arrow-Down”-button. 3. - Page 7 2. Use the “±10S” button to activate or deactivate a 10s pre-countdown. — “-10” stands for deactivated pre-countdown. — “10” stands for activated pre-countdown. 3. For starting the timer, use the “OK”-button. Please pack the parts back in exactly the same way! LED-Großanzeige — Anleitung | LED Clock — Instructions...
- Page 8 © Copyright race result AG. Alle Rechte vorbehalten. Das Copyright sowie das geistige Eigentum aller Texte, Bilder und Grafiken, wie auch deren Gestaltung, obliegen, sofern nicht anders angegeben, der race result AG. Das Reproduzieren, Verarbeiten, Vervielfältigen oder Weitergeben von Inhalten erfordert unsere vorherige schriftliche Zustimmung.
