MAINLINE WS1 Manual

INTRODUCTION
WS1 is a set of complete wireless access kit for home/office use. It consists of a Wireless
Keypad, a Wireless Bolt Lock (suitable for metal/wooden door and framed glass door), a
Wireless Exit Button, 2 Remote Transmitters and 5 Keyfobs. Super strong 3M stickers provide
simple installation way.
Major Parts
Battery type
Wireless Keypad: 3 units of AAA batteries
Wireless Lock: 2 units of AA batteries
Wireless Exit Button: 1 unit of 2032 Lithium battery (Battery is already contained in the
equipment)
Remote Transmitter: 1 unit of 2032 Lithium battery (Battery is already contained in the
equipment)
Because of ultra low power consumption, the keypad, exit button and remote transmitters
can work as long as one year (bases on 30 times/day); the open times of the lock is over
16,000 times (can work about one year bases on 40 times/day).
It will remind people to replace batteries intelligently if low battery.
How to release the door?
(All parts are paired already, and the keyfobs are added in the device. Users can operate it
directly.)
3 versions for option
WS1: including a wireless keypad, a wireless lock, a wireless button, 2 remote transmitters
and 5 keyfobs
WS1-A: including a wireless keypad, a wireless lock, a wireless button and 5 keyfobs
WS1-B: including a wireless lock, a wireless button and 2 remote transmitters
Features
All wireless, no need wires any more
Easy for installation and operation
Open times: 16,000 times for lock, 10,000 times for keypad
433MHz Rolling Code technology
Ultra low power consumption
With two Remote Transmitters
100 PIN/card users
4-6 digits PIN, 125KHz EM card / 13.56MHz Mifare card (Optional).
Specifications
