- Page 1 GV-Keyboard Instruction Manual Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. 2005/03...
-
Page 2: Table Of Contents
Connecting GV-Keyboard to One GV-System Connecting GV-Keyboard to Multiple GV-Systems Introduction Installation USB Driver The GV-Keyboard is used to program and operate GV-Systems. Through RS-485 configuration, it can control up to 16 additional GV-Systems. GV-Keyboard Application Defining Eight Function Keys Packing List... -
Page 3: System Connections
GV-Keyboard GV-Keyboard System Connections Connecting GV-Keyboard to One GV-System Rear Panel Overview There are four ways to connect the keyboard and one GV-System, using: USB Port, RS-232 Port (DC power required), Terminal Block (DC power required), or TERM RJ-11 Port (DC power required) -
Page 4: Connecting Gv-Keyboard To Multiple Gv-Systems
Connects to PC's USB Driver Power Supply RS-485+ If you are using the USB port to connect the keyboard and GV-System, it's RS-485- RS-485 Cable necessary to install the USB driver. These instructions are for Windows XP. to RJ-11 Port * Installation under Windows 2000 is similar, but not necessarily identical. -
Page 5: Gv-Keyboard Application
Note: Remember the COM port showing in the Prolific USB-to Serial Bridge entry. It indicates the port number that the keyboard is using. GV-Keyboard Application To run the GV-Keyboard application, follow these steps: Execute mcamctrl.exe from the GV-System folder. Click Next to display this warning window, and then click Continue Anyway. -
Page 6: Defining Eight Function Keys
GV-Keyboard GV-Keyboard The controls in the Multicam Controller window: Name Description DVR ID Selects the desired DVR ID for connection. DVR Name Gives the login DVR a descriptive name. Port Selects the port connecting to the keyboard. Startup type Selects Manual or Automatic to run Mulitcam Controller at next startup. -
Page 7: Id & Password Settings In Dvrs
Control (GV-Keyboard). This allows the export of its ID and Password. Reserved for future features P4-5 When logging in the GV-System, you will see the exported ID in the ID drop-down list of the Login dialog box. Locks the keyboard... - Page 8 GV-Keyboard GV-Keyboard Function keys Moves one frame forward F1-F8 Stops a video event Section B Launches Multicam Surveillance System (Main System) Sets the starting and ending frames for auto playing Launches ViewLog Increases playback speed Speed+ Turns full screen view on/off...
-
Page 9: Programming And Operation
GV-Keyboard GV-Keyboard Moves the PTZ camera to the default position Home Changing DVR ID Press P1, and enter a two-digit DVR ID. Changing password Press P2, enter a password, and press to browse Moves the PTZ camera to a preset location LCD displays. -
Page 10: The Osd In Main System
GV-Keyboard GV-Keyboard Changing the Main System OSD Options The OSD in Main System To change the Main System OSD options with the keyboard, follow the steps below: Press the OK/Menu button to open the OSD (see Figure 1). Use the direction buttons to select a menu you want. -
Page 11: Shortcut Key Conflict Test
See USB Driver Step 6 on page 7. If multiple GV-Systems are daisy-chained together, Execute GvKeyTest.exe from the GV-System folder. This displays the following (1) check connections among GV-Systems, and window. (2) turn on Terminal Resistance to increase frequency response. -
Page 12: Gv-Keyboard X
GV-Keyboard GV-Keyboard Specifications RS-232 to PC DB9 Female Output USB 1.1 RS-485+ Connects to GV-NET or GV-NET card RS-485+ RS-485- Connects to GV-NET or GV-NET card RS-485- RS-232 9,600 bps Communication RS-485 9,600 bps DC IN DC 12V 1A Power...
