SoundGate Simple-fi VIDHOND1V4 Manual

Be Sure To Ask Your Autosound Specialist About
These Other Exciting SoundGate Products...
• Competition-Grade Interfaces for adding amplifiers
• Remote audio control interfaces that let you control aftermarket receivers and CD players from your
factory rear seat, or steering-wheel-mounted audio controls.
• And many others!
Why SoundGate Dealers have the edge...
The technologies used in today's vehicles are as sophisticated as any laptop computer. At
SoundGate we believe these new technologies are full of opportunities for mobile electronic
dealers across the nation. We make it a high priority to not only research these new systems, but
to understand them and their impact on the aftermarket car audio industry. Armed with this
knowledge, we are well equipped to help you integrate new components into these systems with
our innovative, high-performance interfaces and unparalleled technical support.
Liability Disclaimer: SoundGate ® , Stillwater Designs, Inc., its subsidiaries, or Officers of the corporation
cannot be held liable for damages or injuries caused by, or resulting from the use of this instruction guide or product.
REPAIR OR REPLACEMENT IS THE EXCLUSIVE REMEDY OF THE PURCHASER. ANY IMPLIED WARRANTY ON THIS PRODUCT
INCLUDING MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS LIMITED IN DURATION TO THE DURATION OF
THE WARRANTY(please see the enclosed Limited Warranty document for complete Warranty information). SOUNDGATE
NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION
WITH THE SALE AND USE OF THIS PRODUCT. SOUNDGATE PROHIBITS ANY RETAILER FROM EXTENDING ANY WARRANTY
OR WARRANTIES ON BEHALF OF SOUNDGATE TO ANY PERSON. SOUNDGATE IS NOT RESPONSIBLE FOR ANY INDIRECT,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
Strictly adhere to all car manufacturer warnings that pertain to the disassembly, maintenance, or servicing of the vehicle and
any of its associated parts or systems.
SoundGate cannot be held responsible for discrepancies, or inconsistencies that may occur due to vehicle
manufacturing changes.
If you feel that you cannot agree with the above limitations, please return this product to the dealer you
purchased it from, or call SoundGate Customer service at 800-256-0808 for a Return Authorization number, and return the
product to SoundGate for a credit or refund.
Page 1
VIDHOND1V4
Purpose...
The VID-
HOND1V4
allows you to
add up to 2
video signals
(DVD, VCR, rearview camera, game console, etc.)
to the factory navigation systems in the Honda
vehicles listed below.
Note: The VIDHOND1V4 provides video input only.
To input audio signals, you will need an additional
interface (sold separately - see below).
The SoundGate VIDHOND1V4 works in the following vehicles, only when they are
equipped with a factory Navigation System with the 12-pin connector at the Nav unit (for
20-pin connectors, please see VIDHOND2V4):
HONDA
2004-2006 Odyssey
2006-2008 Ridgeline
2004-2008 Pilot
Audio input interfaces (required if you need to input audio signals also):
AUXHOND3, or VIDFM8T or VIDFM40T - All vehicles
Copyright © 2004-2007 SoundGate ® . All Rights Reserved. SoundGate ® is a
registered trademark of Stillwater Designs, Inc. All other trademarks are the property
of their respective owners.
If you experience any problems, call SoundGate Technical Support at 800-256-0808
or e-mail us at sgtech@soundgate.com.
Features...
The VIDHOND1V4 utilizes microprocessor control,
ultra-reliable surface-mount
construction, and advanced firmware design, to
flawlessly match the video signal from the new
sources to the factory system. The VIDHOND1V4
is also equipped with brightness, color, contrast
and tint adjustments to allow you to get the best
quality picture possible.
ACURA
2001-2002 MDX
2005-2008 RL
2004-2008 TL
2004-2008 TSX
w w w w w w . . s s o o u u n n d d g g a a t t e e . . c c o o m m
Rev 20070827
