USER GUIDE
SPACE LAUNCHER 76MM
REFLECTOR TELESCOPE
The below guide will help you to learn correct use of different eyepiece
Eyepiece Setup
and Combination:
Every Telescope Comes With Different Eyepieces,
Barlow And Erecting Eyepiece.
This Telescope
Includes:
3 Eyepieces - 20mm, 12.5mm, 6mm
3X Barlow lens
1.5X Erecting Eyepiece
Standalone Eyepiece Combination:
Always start your observation with a low-magnification
eyepiece, i.e. 20mm and then slowly move to high
magnification eyepieces, i.e. 12.5mm and 6mm. Also
always start using your telescopes with land objects to
get familiar with the equipment. Then move brighter
night sky objects such as the Moon. Jupiter & Saturn
should come next and then Venus & Mars, due to their
small size.
12.5mm Eyepiece
In case of any further queries contact: +91 92126 69974 or info@spacearcade.in
Congratulations On Starting Your Astronomical Journey.
And lenses to get sharp and focused view from your telescope.
56x Magnification & laterally
inverted image
20mm Eyepiece
6mm Eyepiece
35x Magnification &
inverted image
116x Magnification &
inverted image
www.spacearcade.in
Advertisement
Related Manuals for Space Arcade SPACE LAUNCHER 76MM
Summary of Contents for Space Arcade SPACE LAUNCHER 76MM
- Page 1 USER GUIDE SPACE LAUNCHER 76MM REFLECTOR TELESCOPE Congratulations On Starting Your Astronomical Journey. The below guide will help you to learn correct use of different eyepiece And lenses to get sharp and focused view from your telescope. Eyepiece Setup and Combination: Every Telescope Comes With Different Eyepieces, Barlow And Erecting Eyepiece.
- Page 2 Eyepiece And 3x Barlow Lens Combination: 3x Barlow lens can be used with all 3 Eyepieces to get extra 3x additional magnification. 3x Barlow and 20mm Eyepiece 105x Magnification & Inverted Image Erecting Eyepiece And Eyepiece Combination: Erecting Eyepiece can be used with all 3 Eyepiece to get an erect image for nearby and land objects. Note: Erecting Eyepiece shall not focus for objects at infinity such as celestial objects or very far away land objects.
