I-Rocks IRK59M Quick Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
K59M
Split Ergonomic RGB Mechanical Keyboard

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IRK59M and is the answer not in the manual?

Questions and answers

Related Manuals for I-Rocks IRK59M

Summary of Contents for I-Rocks IRK59M

  • Page 1 K59M Split Ergonomic RGB Mechanical Keyboard...
  • Page 2 HOTKEY QUICK REFERENCE CHANGE BACKLIGHTING EFFECTS ......LOCKOUT Windows KEY (GAME MODE) .... TURN OFF/ON KEYBOARD BACKLIGHTS ..TURN OFF/ON SMART WHEEL BACKLIGHT ..CHANGE SMART WHEEL MODE..... (click) MODE COLOR (click) Volume White Up / Down Mute Application Switch Select Scroll Blue...
  • Page 3 快速操作指南 切換背光特效 ............. 鎖定 Windows®鍵 (遊戲模式) ....... 開啟或關閉鍵盤背光 .......... 開啟或關閉智慧轉輪背光 ........切換智慧轉輪模式........... (click) 模式 滾輪顏色 (click) 音量 白色 大聲 / 小聲 靜音 工作頁面 紅色 切換 選定 滾輪 藍色 上捲 / 下捲 調整亮度 變更顏色 變更速度 背光 綠色...
  • Page 4 Download the app to upgrade to the latest firmware, customize backlighting,program macros, and more... 下載鍵盤專屬設定程式，以便您升級韌體、自訂背光、 錄製巨集與探索更多功能 Model No.：IRK59M Quick Installation Guide...

  • Page 5: Keyboard Layout

    KEYBOARD LAYOUT Media Hotkeys Fn Key Linking Cable Smart Control Wheel Keyboard Interface (R) Keyboard Cable Windows® Lockout Key Keyboard Interface (L) Keycap Puller Backlighting Key USB Pass-Through Port Extra Esc & Macro Keycaps Macro Keys Keyboard Port...

  • Page 6: Setting Up Your Keyboard

    SETTING UP YOUR KEYBOARD 1. Connect the linking cable (A,B) to each of the keyboard halves. (Note : icon logo faces up.) 2. Connect the keyboard cable (C) to a free USB-A port on your Windows® PC or Apple Mac®.
  • Page 7 SMART CONTROL WHEEL Pressing the Fn key (A) + Smart Control Wheel (B) will cycle through the available modes with the color changing to indicate the current mode. After selecting a mode, rotate the wheel left, right, or click to adjust mode settings.
  • Page 8 BACKLIGHTING EFFECTS Keyboard backlighting effects can be changed by pressing the backlight- ing key (A). All backlighting can br turned on/off by pressing the Fn key (B) + back- lighting key (A). Smart Control Wheel backlighting can be turned on/off by pressing the Fn key (B) + “Q”...

  • Page 9: Macro Keys

    MACRO KEYS Macros can be recorded at any time (without software) via on board commands. The keyboard supports a maximum of 16 key combinations per macro. The macro functions : Select All / Copy / Paste / Cut are preprogrammed into the 4 macro M-keys (B).

  • Page 10: Media Hotkeys

    MEDIA HOTKEYS Media Player ．Fn key (B) + F1 key (A) Play/Pause ．Fn key (B) + F2 key (A) Stop ．Fn key (B) + F3 key (A) Previous ．Fn key (B) + F4 key (A) Next ．Fn key (B) + F5 key (A) WINDOWS®...

  • Page 11: Factory Reset

    FACTORY RESET To return the keyboard to its factory settings, press the Fn key (A) + “Esc” key and hold for 3 seconds. Note : All custom programmed macros and backlight colors will be erased when the keyboard is returned to factory settings.
  • Page 12 鍵盤功能配置 Fn 鍵 鍵盤傳輸連接線 ( 23 CM) 多媒體熱鍵 鍵盤主線連接線 ( 180 CM) 智慧滾輪 右鍵盤連接埠(R) 左鍵盤連接埠 (L) 鎖Windows® 鍵 拔鍵器 USB 2.0 輸出埠 背光特效 延伸替換鍵 USB 主線連接埠 快捷鍵...
  • Page 13 鍵盤安裝 1. 鍵盤傳輸連接線連結於 (A,B) 點。 ( 兩邊圖示ICON 要朝上) 2. 連接主連接線於鍵盤 (C) , 另一邊連接電腦端的 USB-A埠...
  • Page 14 智慧轉輪 ．按壓Fn鍵 (A) + 滾輪 (B) 進行滾輪模式切換，共有四種模式及對應的背光。 ．按壓Fn鍵 (A) + Q鍵 , 可關閉/開啟滾輪背光。 模式 轉輪顏色 (click) 音量 白色 大聲 / 小聲 靜音 工作頁面 紅色 切換 選定 滾輪 藍色 上捲 / 下捲 調整亮度 變更顏色 變更速度 背光 綠色...
  • Page 15 背光特效 ．按壓 背光特效切換按鍵(A) 可進行背光特效切換 ,共有20種背光特效可以 　提供選擇。 ．按壓Fn (B) +背光特效切換按鍵(A) 可將背光進行開跟關。 ．按壓Fn鍵 (B) + Q鍵 , 可關閉/開啟滾輪背光...
  • Page 16 巨集鍵 1. 軟體巨集錄製請安裝對應軟體進行操作。 2. 直接鍵盤硬體錄製，支援4 組(M1 ~M4)(B) 自定巨集功能，並且儲存 於鍵盤內存記憶體中，操作方式如下: 　　　a. 選擇要錄製的M1~M4其中一鍵按鍵 ( 例如 M1 ) 　　　b. 按Fn鍵 (C) +M1 ( B )開始錄製 ( M指示燈會慢閃 ) 　　　c. 鍵入所欲錄製的字元，最大支援16字元 ( 超出部分不會被錄製) 　　　　錄製時間要在3分鐘內完成，超過時間將自動結束不保存 　　　d. 再次按壓Fn+M1 保存 (MR指示燈快閃3次熄滅，完成儲存 ) 　　　e. 其他M1~M4 錄製方式同上 　　　f. 按壓M1~M4 叫出所錄製的巨集 3.
  • Page 17 多媒體熱鍵功能 ．Fn key (B) + F1 key (A) 多媒體播放 ．Fn key (B) + F2 key (A) 播放 ．Fn key (B) + F3 key (A) 停止 ．Fn key (B) + F4 key (A) 上一首 ．Fn key (B) + F5 key (A) 下一首...
  • Page 18 恢復原廠設定 ．按壓 FN鍵 (A) + ESC 鍵 約3秒鐘可恢復原廠設定 注意 : 恢復原廠設定後所有的按鍵巨 集及背光設定值將被清除，恢復出 廠值。...
  • Page 19 Technology Co., Ltd. i-Rocks Korea www.i-rocks.co.kr Headquarter Office i-Rocks Malaysia 7F., No. 786, Zhongzheng Rd., Zhonghe Dist., 57-A, Jalan SS21/1A, Damansara Utama, 47400, New Taipei City 23586, Taiwan Petaling Jaya, Selangor, Malaysia Tel : +886-2-2225-5080 Tel : +603-77339233 Fax : +886-2-2228-1712 www.i-rocks.com...
