TS4000 Bernzomatic Torch
(TS4000TK includes torch and a Map-Pro cylinder)
Description
The Bernzomatic® Advanced Performance Torch is built with instant on/off
ignition, a swirl flame profile and flame lock option for continuous use. The
Advanced Performance Torch is compatible with 14.1 oz Bernzomatic MAP-
Pro® fuel and 14.1 oz and 16 oz Bernzomatic Propane fuel, sold separately.
Limited Lifetime Warranty.
Specifications
•
Flame type: swirl flame
•
Warranty: limited lifetime warranty
•
Approval: ANSI/UL 147. Certificate no. 20120611-MH5592
•
Fuel type: Bernzomatic Map-Pro (1811120) or
Bernzomatic Propane (1811220)
•
Instant on/off ignition
•
Continuous flame lock
•
Pressure regulated for consistent performance when inverted
•
Durable, cast body construction
•
Uses: ideal for large diameter soldering, light brazing, woodworking and cooking.
•
Torch head not available on its own. Only available in a kit with the cylinder.
Spare Parts
A replacement tip can be purchased from any Bromic distributor using part
number T21198
Assembly
1.
Turn ignition knob (2) to LOCKED position.
2. Hold torch so that burn tip (4) is pointed away from persons and flammable
materials. Thread gas cylinder into regulator/torch body. Hand tighten only. Do not
force.
3. Check all joints and couplings periodically to ensure against loose connections.
With valve open, without lighting, test all connections with soapy water. If bubbles
appear, gas is leaking and torch must be repaired. NEVER USE A FLAME TO
CHECK FOR LEAKS. Make this test in a well-ventilated and spark-free area and
where there are no open flames.
© BROMIC PTY LTD. AUS: 1300 276 642 NZ: 0508 276 642
TECHNICAL DATA SHEET
BROMICPLUMBING.COM
1
V1 11/2023
Advertisement
Summary of Contents for Bromic Heating TS4000
- Page 1 TECHNICAL DATA SHEET TS4000 Bernzomatic Torch (TS4000TK includes torch and a Map-Pro cylinder) Description The Bernzomatic® Advanced Performance Torch is built with instant on/off ignition, a swirl flame profile and flame lock option for continuous use. The Advanced Performance Torch is compatible with 14.1 oz Bernzomatic MAP- Pro®...
- Page 2 TECHNICAL DATA SHEET Warnings This torch is used with a flammable product. Failure to comply with these warnings and instructions may result in an explosion or fire that may cause property damage, serious personal injury or death. Read and comply with the instructions and warnings in this manual and familiarize yourself with the torch before lighting and using.
- Page 3 TECHNICAL DATA SHEET Lighting And Operation CAUTION: Tipping the gas cylinder more than 60 degrees from its upright position may cause torch to flare. The torch has a built-in regulator that controls pressure and reduces the risk of pulsating or yellow flames when used other than upright. It is recommended to start working with a disposable hand torch cylinder at room temperature and to keep torch upright as much as possible.
- Page 4 Bromic warrants to the original purchaser that this product is free from defects in material and workmanship for as long as you own your TS4000. This warranty does not apply to product that has been damaged as a result of improper maintenance, accident or other misuse, or which fails to operate due to normal wear and tear.
