DREAMSEAT Zipchair Xpression PRO Assembly Instructions

Xpression PRO Gaming Chair
Assembly Instructions // For any questions, please call us at 631.656.1066 or email Info@Zipchair.com
A B
Seat Back x1
D E
Base x1
G H
Gas Lift & Cover x1 Recliner Mechanism Covers x2
J K
Universal Tool x1
M N
Head and Back Pillow Set x1 Adjustment Handles x2
C
Seat Bottom x1 Armrest x2
F
Wheels x5 Tilt Mechanism x1
I
Screws (Pre-Attached)
L
Cover Caps x2 Screws (Pre-Attached)
O
Optional: Logo Panel x1
Step 1
Bolts shown are already
attached to chair at delivery.
Remove bolts,
align arms on seat
bottom, and attach
bolts as shown in
the diagram.
Arms are labeled
with R and L decals
for right and left
position placements.
Note: Make sure
bolts are secured
tight, should be
flush to the chair.
Step 2
Align seat back to side
brackets already attached
to the seat bottom.
Important: Attached
right side of chair to
seat bottom first.
Do not tighten
until chair is fully
assembled. Tighten
evenly on each side.
Left
Right Arm
Back
Front
Left Arm
Right
