PecanPi®+ Streamer Premium Instructions
Table of Contents
Page 1. Table of Contents and Specifications
Page 2. Accessing Volumio and Powering Up
Page 3. Powering Down, S/PDIF (Coax) Input, and Networking (Wi-Fi)
Page 4. USB Ports and Volume Control
Page 5. Headphone Connections / Roon Operation
Pages 6-11: First Bootup / Initial Configuration
Specifications
Please see
this document
for device specifications.
1 |
P a g e
Rev 1.0
Advertisement
Summary of Contents for Orchard Audio PecanPi+ Streamer Premium
- Page 1 PecanPi®+ Streamer Premium Instructions Table of Contents Page 1. Table of Contents and Specifications Page 2. Accessing Volumio and Powering Up Page 3. Powering Down, S/PDIF (Coax) Input, and Networking (Wi-Fi) Page 4. USB Ports and Volume Control Page 5. Headphone Connections / Roon Operation Pages 6-11: First Bootup / Initial Configuration Specifications Please see...
- Page 2 PecanPi®+ Streamer Premium Instructions Volumio’s Interface Access Volumio’s interface can be accessed in a few different ways. • Using the built-in touchscreen • Using Volumio app: o Android Devices - https://play.google.com/store/apps/details?id=volumio.browser.V olumio o Apple Devices - https://itunes.apple.com/app/volumio/id1268256519?mt=8 • Using an internet browser o Open the browser and go to http://pecanpi+.local/ Powering Up the Streamer...
- Page 3 PecanPi®+ Streamer Premium Instructions Powering Down the Streamer To power down: 1. In the Volumio interface perform a device shutdown. 2. Wait 30 seconds 3. Push the power button in the back to turn the device off. The button will stop being illuminated.
- Page 4 PecanPi®+ Streamer Premium Instructions USB Ports The four (4) USB ports on the back of the streamer can be used to connect an external USB DAC or storage devices like flash drives that contain music. To play music to the external DAC the settings must be changed to play to the external device.
- Page 5 PecanPi®+ Streamer Premium Instructions Headphone Connections Single Ended Headphones: The streamer has a 1/4’’ (6.35mm) jack on the front of the unit. This can be used with any single ended headphones. A 1/4’’ (6.35mm) to 1/8’’ (3.5mm) adapter may be needed. Balanced Headphones: For balanced headphones an adapter will be needed to connect them to the XLR outputs on the back of the device.
- Page 6 PecanPi®+ Streamer Premium Instructions Bootup When the device boots up for the first time you will be presented with the following prompts. Select the language of your choice and click next. P a g e Rev 1.0...
- Page 7 PecanPi®+ Streamer Premium Instructions This streamer comes with a lifetime myVolumio premium membership if you already have an account log in and it will be applied to your existing account if not create an account. You may choose to do neither and just continue (click “Next”). The streamer will function without logging into an account but with some limitations.
- Page 8 PecanPi®+ Streamer Premium Instructions Here you can select the name of the device as it will appear on your network. This will determine how you are able to access it from a web browser on your network. This does not affect operation of the Volumio app. You can also just leave the default of “PecanPi+”...
- Page 9 PecanPi®+ Streamer Premium Instructions Here leave the default setting of “PecanPi+ Analog Out” and click next. P a g e Rev 1.0...
- Page 10 PecanPi®+ Streamer Premium Instructions On this screen you can log into any of the streaming services that you use. It is not required at this step and can also be done later. Click “Next” when finished. 10 | P a g e Rev 1.0...
- Page 11 PecanPi®+ Streamer Premium Instructions Here select if you would like to have automatic software updates. This setting can also be changed later in the device’s setting menu. Click “Done” to complete initial configuration. 11 | P a g e Rev 1.0...
