Samlexpower BRS-250 Owner's Manual

BRS-250 Bistable Relay
OWNERS MANUAL
PURPOSE
The BRS-250 relay is suitable for a wide range of voltages, has a very low current consumption and can
switch a high current.
FEATURES
• Suitable for both 12 V and 24 V systems
• High switching current
• Bistable relay
• Extremely low operating current
INSTALLATION
Follow the following steps and the connection diagram when connecting the BRS-250.
1. Connect the equipment to be controlled to T2.
2. (Optional.) Connect a lamp to the status/alarm output.
3. Connect the positive battery terminal to T1.
4. Connect the positive battery terminal to A1.
5. Connect the switch between positive terminal and START
6. Connect the negative terminal on the BRS-250 to the negative terminal on the battery via a 5 A fuse.
Warnings:
• The product may only be connected by skilled fitters who are aware of the regulations for working with
high battery voltages.
• The use of poor quality connection materials and/or excessively thin cables may result in damage to the
product. (See Technical Data  Cable diameter for the correct sizes.)
• A short circuit between the positive and negative terminals of the battery may severely damage your
system.
• Always use fuses.
• Do not place the BRS-250 in the vicinity of highly flammable materials.
• Place the BRS-250 in a cool and dry place.
OPERATION
START
When a voltage is supplied to T1 and a voltage of 5 V to 35 V is connected to the START input, the relay will
be closed. If the voltage is removed from the START input, the relay will open.
LED
The LED lights up the moment the relay is switched on and switches off when the relay is switched off.
