Related Manuals for DigiTech QM3793
Summary of Contents for DigiTech QM3793
- Page 2 Wiring Diagram...
-
Page 12: Wiring Diagram
WIRING DIAGRAM: Connecting an optional reversing camera so your head unit displays video automatically when you select reverse gear. QC3530 or QC3532 cameras are recommended. The camera is powered by taking 12vdc from the wiring to a Reverse Light. An extension cable with Yellow plugs on each end sends the video from the camera to the head unit.
