Installation Instructions and
Declaration of Performance
INLAP & INLAP-ST fire dampers
according to the Certificate of
Constancy of Performance 1139-CPR-1046/12
INLAP
TIROTECH
®
Fire protection systems
EI120(h
,v
,i o)S
o
e
EI90(h
,v
,i o)S
o
e
BFM/K310
INLAP-ST
PREMO BML
SW
TW
EI120(h
,v
,i o)S
o
e
EI90(h
,v
,i o)S
o
e
BFBL
Advertisement
Table of Contents
Summary of Contents for AIR FIRE TECH INLAP
- Page 1 Fire protection systems Installation Instructions and Declaration of Performance INLAP & INLAP-ST fire dampers according to the Certificate of Constancy of Performance 1139-CPR-1046/12 INLAP INLAP-ST EI120(h ,i o)S EI120(h ,i o)S EI90(h ,i o)S EI90(h ,i o)S TIROTECH BFM/K310 PREMO BML BFBL ®...
-
Page 2: Table Of Contents
Typographical and printing errors as well as technical changes cannot be ruled out. Solid floors ■ Cross-laminated timber floors ■ For penetration elements and classifications not mentioned in these installation instructions, please contact AIR FIRE TECH Brandschutzsysteme. TIROTECH ® fire protective mortar ■ Penetration seals ■... -
Page 3: Installation Steps
Installation steps – wall Installation steps – wall INLAP-ST in horizontal air ducts (spiral ducts) INLAP in horizontal insulated air ducts (spiral ducts) INLAP-ST INLAP INLAP With 5-15 mm overhang on both sides of the wall, apply 1 layer of... - Page 4 Installation steps – floor Installation steps – floor INLAP-ST in vertical air ducts (spiral ducts) INLAP in vertical air ducts (spiral ducts) with change of direction INLAP-ST INLAP Cut the air duct to length flush with the floor. Cut the air duct to length flush with the floor.
- Page 5 Installation steps – PREMO BML TW Installation steps – PREMO BML SW Wall duct PREMO BML TW in stud partition walls with INLAP-ST Wall duct PREMO BML SW in shaft walls with INLAP PREMO BML TW PREMO BML SW Cover one side of the...
-
Page 6: Fixing The Air Duct In Place
Fixing the air duct in place – wall Fixing the air duct in place – floor maximale Distanz der Maximum distance of starren Befestigung zur BSK: 1,0 m rigid fixing to fire damper: 1.0 m (mit schräger Abstützung: 2,0 m) (with diagonal support: 2.0 m) ≥... -
Page 7: Installation Information
Fire dampers or ducts into which the dampers are inserted must be installed in such a way that The INLAP fire damper is intended for use at temperatures between -20 °C and 50 °C with UV their position in relation to the separating element remains unchanged during the fire resistance exposure but without exposure to rain. -
Page 8: Installation Steps
® ® according to EN 15882-5 according to EN 15882-5 Installation steps – wall Installation steps – floor INLAP-ST INLAP Cut the air duct to length Cut the air duct to length flush with the wall. flush with the floor. -
Page 9: Fixing The Air Duct In Place
Distance between Nippel Nipple AIR FIRE TECH fire dampers (1139-CPR-1046/12) and ≥ 50 AIR FIRE TECH fire damper air vents flexibler brennbarer Leitungsteil Flexible combustible duct section ≥ 300 mm (R-14.3.2-18-7924/7925) ≥ 50 mm. Distance between AIR FIRE TECH fire dampers TIROTECH ®... -
Page 10: Certificate Of Constancy Of Performance
Certificate of Constancy of Performance... - Page 11 No. 01/2023/INLAP according to Annex III of Regulation (EU) No. 305/2011 (Construction Products Regulation) Remove the flexible combustible duct section from the connecting piece of the INLAP-ST. Carefully pull the fire damper out of the air duct for a functional check.
-
Page 12: Shaft Walls
DECLARATION OF PERFORMANCE DECLARATION OF PERFORMANCE Permissible separating elements − walls Size Duct insulation Annular gap Additive Classification Separating building element Shaft walls 9–19 mm ≤ 5 mm silicone ≤ DN250 Cladding on one side with 2x20, 3x15 or 2x25 mm Synthetic rubber (between insulation and PREMO BML) PREMO BML SW... -
Page 13: Solid Floors
DECLARATION OF PERFORMANCE DECLARATION OF PERFORMANCE Permissible separating elements − floors Size Duct insulation Annular gap Additive Classification Separating building element Solid floors − − Thickness ≥ 150 mm, density ≥ 500 kg/m ≤ 10 mm 9 mm BFM/K310 fire protection sealant 1 layer BFBL ,i ↔... - Page 14 AIR FIRE TECH fire dampers (1139-CPR-1046/12) and ≥ 100 ≥ 100 ≥ 50 AIR FIRE TECH fire damper air vents INLAP DN ≤ 160 (R-14.3.2-18-7924/7925) ≥ 50 mm. Ringspalt ≤ 10 mm mit Fugenfüller Annular gap ≤ 10 mm with joint filler...
- Page 15 Brandschutzfugenmasse fire protection sealant (≥ 10 mm thick) (≥ 10 mm tief) INLAP INLAP-ST INLAP ≤ DN160 EI90(v EI90(v ↔ ↔ 1 layer BFBL on both sides beidseitig 1 Lage BFBL 2 x 3 mm Elastomer...
- Page 16 Brandschutzfugenmasse fire protection sealant Brandschutzfugenmasse (≥ 10 mm thick) (≥ 10 mm thick) (≥ 10 mm tief) (≥ 10 mm tief) INLAP INLAP-ST INLAP ≤ DN160 INLAP-ST ≤ DN160 EI90(v EI90(v EI120(v ↔ ↔ ↔ EI120(v ↔...
- Page 17 Mineralwolle (melting point ≥ 1000 °C (Schmelzpunkt ≥ 1000 °C) Annular gap ≤ 30 mm with mineral Ringspalt ≤ 30 mm mit INLAP ≤ DN160 INLAP INLAP-ST wool Mineralwolle (melting point ≥ 1000 °C (Schmelzpunkt ≥ 1000 °C) INLAP ≤...
- Page 18 Flexible duct section Flexibler Leitungsteil Flexible duct section Flexibler Leitungsteil Flexibler Leitungsteil Flexible duct section Flexibler Leitungsteil Flexible duct section INLAP INLAP-ST INLAP Cladding according to EN 520 Beplankung gemäß EN 520 Cladding according to EN 520 Beplankung gemäß EN 520 INLAP-ST...
- Page 19 (≥ 10 mm thick) (≥ 10 mm tief) With coating on duct EI120(v With coating on duct EI120(v ↔ ↔ INLAP INLAP-ST ≤ DN160 EI120(v ↔ Nippel Nipple Flexibler Leitungsteil Flexible duct section Flexibler Leitungsteil Flexible duct section beidseitig 1 Lage BFBL...
- Page 20 Brandschutzfugenmasse Brandschutzfugenmasse (≥ 10 mm thick) (≥ 10 mm tief) (≥ 10 mm thick) (≥ 10 mm tief) INLAP-ST INLAP INLAP ≤ DN125 INLAP ≤ DN125 Beplankung Cladding according to Nippel Nipple gemäß EN 520 EN 520 Flexibler Leitungsteil...
- Page 21 EI90(h EI90(h EI90(h EI90(h ↔ ↔ ↔ ↔ Flexible duct section Flexibler Leitungsteil Flexible duct section Flexibler Leitungsteil INLAP-ST INLAP-ST INLAP INLAP Beplankung Beplankung Cladding according to Cladding according to gemäß EN 520 EN 520 gemäß EN 520 EN 520...
- Page 22 The manufacturer named above is responsible for producing the declaration of performance according to with EU Regulation no. 305/2011. Signed for the manufacturer and in the name of the manufacturer by: Bad Vöslau, February 2023 (Uwe Stefani, Managing Director CEO AIR FIRE TECH Brandschutzsysteme GmbH)
- Page 23 Design drawing INLAP & INLAP-ST Design drawing PREMO BML Fire protection module for insulated or non-insulated air ducts INLAP & INLAP-ST PREMO BML TW (profile width) (Profilbreite) optional optionally with limit switch mit Endschalter PREMO BML SW (Klappenblatt) (damper blade)
- Page 24 Notes...
- Page 25 Hanuschgasse 1 / Top 4A *depending on the 2540 Bad Vöslau separating element Austria INLAP T: +43 1 982 01 74-0 DOP 01/2023 / INLAP F: +43 1 982 01 74-930 E: office@airfiretech.at I: www.airfiretech.at EN 15650:2010 Fire damper fire damper...
