Pulaski Furniture Caldwell P012170 Assembly Instructions

Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts
that may have come loose inside the carton during shipment. Identify and count all hardware and compare
with the hardware list below.
TOOLS REQUIRED (NOT PROVIDED)
Phillips screwdriver
HARDWARE LIST HEADBOARD:
No.
Description
Sketch
A Allen bolt
Lock washer
B
Flat washer
C
D L Allen key
HARDWARE LIST FOOTBOARD:
No. Description
Sketch
E Screw
HARDWARE LIST RAIL:
No. Description
Sketch
F
Hanger bolt
G Hexagon nut
Lock washer
H
I
Wrench
ASSEMBLY INSTRUCTIONS
ITEM #: P012170 / P012171 / P012172
DESCRIPTION: QUEEN PANEL BED
Q'ty
Size
1/4" x 2.3/8" 10 Pcs
10 Pcs
1/4"
10 Pcs
1/4" x 3/4"
M4 1 Pc
Q'ty
Size
10 Pcs
M4 x 1.1/4"
Q'ty
Size
5/16" x 3.1/2" 8 Pcs
8 Pcs
5/16"
8 Pcs
5/16"
1 Pc
12mm
RESIDENTIAL USE ONLY
PARTS LIST:
N Description
1
Headboard
2
Headboard Leg-Right
3 Headboard Leg-Left
4
Footboard
5 Slat
6 Support Leg
7 Side Rail
Sketch
Q'ty
1 Pc
1 Pc
1 Pc
1 Pc
5 Pcs
5 Pcs
2 Pcs
MADE IN VIET NAM
PAGE 1 OF 2
