QUICK-START GUIDE
TRUGRADE 12
for
* Refer to operators manual for complete safety and operation info.
A
Hydraulic Reference
B
Set-up Information
1) Connect to Tractor Drawbar.
NOTE: Use only a tractor with adequate power to pull
the TruGrade under ordinary operating conditions.
TruGrade is rated at 400 HP MAX.
Ideal horsepower is range: 120 to 400 HP.
2) Place Jack in storage position.
3) Connect Hydraulics.
4) TruGrade
14
|
16
follow procedure below to take out of narrow transport.
IMPORTANT: Do not use any hydraulic functions
while in Narrow Transport or damage may occur.
5) For all models in Standard Transport Position:
• Fully extend the Lift Cylinder
C
Narrow Transport Into Operating Position
1) To transition from Narrow Transport
position to the normal Operating
Postition, begin by driving the
TruGrade onto level ground,
straight behind the tractor.
2) Connect all hydraulics to the tractor and
place the Angle Circuit
3) On the LH side angle cylinder, remove
the rod-end cylinder pin and swing the
cylinder rearward out of the pin lugs.
3
*
|
14
|
16
1
2
3
4
models in Narrow Transport Position,
1
2
in float.
REMEMBER! You must complete Product
Registration to be eligible for Warranty.
Lift ............................................
Angle .....................................
Tilt .............................................
Rear-Steer .......................
• Rotate up the red transport
lock and secure in open
position with the lock pin.
• Lower the machine into
operating position.
5) Ensure that the hitch clevis is set at the correct height for
the tractor drawbar and trailer height.
NOTE: The correct height is when the mouldboard is
perpendicular to the ground when the cutting edge is on
the ground.
6) Experience will teach you the most efficient operating
speed, but as a rule 3-4 MPH (5-7 km/h) is a normal
operating range.
4) On the RH side angle
cylinder, remove the
rod-end cylinder pin
and swing the cylinder
rearward, out of the pin lugs.
CAUTION:
3
AREA BEFORE REMOVING PINS
As the pins are removed, the
blade may swing to a neutral
position. Be aware of a potential
crushing/impact hazard for any
people in the direct vicinity.
5) Continued on next page...
WARRANTY
Lift Cylinder
Angle Cylinder
Tilt Cylinder
Rear-Steer Cylinder
(TruGrade 14
|
16 models only.)
CLEAR BLADE
4
143572 v1.0
