Summary of Contents for SANIKOM Hotbox 300
- Page 1 Operating Manual Hotbox 300 Sanikom d.o.o. Industry zone A47 4208 Sencur / Slovenia page 1...
-
Page 2: Table Of Contents
7 – 9 4. Start-up / shut-down 5. Maintenance and service page 10 6. Frost protection page 11 7. Technical data page 12 8. CE Declaration of Conformity page 13 Sanikom d.o.o. Industry zone A47 4208 Sencur / Slovenia page 2... -
Page 3: Foreword
Operation Manual. Sanikom offers training schemes enabling the user to use this unit according to its intended purpose, to carry out day-to-day routine care & service operations, and to eliminate minor problems that might occur with the machine. -
Page 4: Safety Instructions
Observe the following instructions before, during and after operation. Read this Operation Manual before the initial start-up of the machine. Operate the machine in compliance with the instructions to preclude dangers. Hotbox 300 Hotbox 300 Sanikom d.o.o. Industry zone A47 4208 Sencur / Slovenia page 4... -
Page 5: Construction And Function
The infrared radiation produced by the flame and the hot exhaust gases allow the water flow in the heating coil to be economically heated to the operating temperature set at the thermostat. Sanikom d.o.o. Industry zone A47 4208 Sencur / Slovenia page 5... -
Page 6: Start-Up / Shut-Down
• Check indicators/gauges/components are working properly. • Check for pressure/temperature changes. • Check for excessive flue gas. • Check for leaking hoses and connections. • Check for unusual noise. Sanikom Sanikom d.o.o. Industry zone A47 4208 Sencur / Slovenia page 6... - Page 7 VDE. Reeled extension cords must be fully unwound to avoid overheating in the reel. You are recommended to use an upstream residual-current-operated circuit-breaker. Observe the VDE instructions. Water connection Prior to start-up, establish the water connection according to the following schematic drawing. Sanikom d.o.o. Industry zone A47 4208 Sencur / Slovenia page 7...
- Page 8 If the burner stops in normal operating condition without restarting automatically, the problem may have the following causes: The temperature safety cutout was triggered. To reset the system, fill the HotBox 300 with cold water and allow the system to cool down until the burner restarts.
- Page 9 Disconnect the unit from the power mains / water supply system. When the unit has cooled down completely, disconnect the hoses. Sanikom d.o.o. Industry zone A47 4208 Sencur / Slovenia page 9...
-
Page 10: Maintenance And Service
After the end of the antiliming process, allow the Hot Box 300 to run with clear water for other 5 minutes in the cleaning/circulation mode. Collect the acid mixture for proper disposal in compliance with the relevant environmental regulations. Sanikom d.o.o. Industry zone A47 4208 Sencur / Slovenia page 10... -
Page 11: Frost Protection
• Start the circulation pump and allow the liquid to circulate for approximately 5 minutes. • Then stop the circulation pump and shut the ball valves on the Hot Box 300. Sanikom d.o.o. Industry zone A47 4208 Sencur / Slovenia page 11... - Page 12 The scope of delivery comprises the following articles: • 1x6m hot water hose with 2xD-Storz • 1x6m hot water hose with 1xD-Storz • 1x4m hot water hose with 2xD-Storz • 1x2m hot water hose with 2xD-Storz Sanikom d.o.o. Industry zone A47 4208 Sencur / Slovenia page 12...
-
Page 13: Ce Declaration Of Conformity
We hereby confirm that the aforesaid product is in compliance with the requirements of the following EU directives: • 89/392/EEC Technical Specifications: 79/113/EEC 81/1051/EEC DIN 45 635 DIN VDE 0700 Part 265 10.91 Sanikom d.o.o. Industry zone A47 4208 Sencur / Slovenia page 13...
