Summary of Contents for TIGERFLOW OCELOT 25
- Page 1 TIGERFLOW OCELOT SIMPLEX BOOSTER OCELOT 25 SIMPLEX BOOSTER www.tigerflow.com...
-
Page 2: Product Description
ENERGY EFFICIENT MULTIPLE PROTECTION INTELLIGENT OPERATION The OCELOT 25 Booster pump is a self-priming, variable speed pump with a permanent Self-priming up to 5ft magnet motor. The pump is constructed with stainless steel materials that provide durabil- ity and corrosion resistance. The pump includes automatic control for variable speed and Media temperature: 0 - 104 degF low ow detection, slowing or stopping the pump when needed. -
Page 3: Product Information
OCELOT SIMPLEX BOOSTER Product Information Performance Curve The Ocelot 25 Simplex Booster is the perfect solution for small water boosting applications such as residential, Ocelot series performance chart H (FT) light commercial, RVs, boats, cabins and remote locations, temporary water boosting, among others. -
Page 4: Product Size
(HP) (GPM) (FT) (GPM) (FT) (in) suction range 160-260V Ocelot 25 24.2 13.2 91.86 0.98 29.5’ 50/60Hz Product Size P R O D U C T D I M E N S I O N S : 1 5 . 3 5 i n * 7 . 6 8 i n * 1 1 . 4 2 i n C H A S S I S D I M E N S I O N S 1.20"... - Page 5 TIGERFLOW TIGERFLOW USE TYPE SELECTION USE TYPE SELECTION OCELOT SIMPLEX BOOSTER OCELOT SIMPLEX BOOSTER Pump Selection For Residential Applications Pump Selection For Villa For the selection of the target room, 7-8 faucets are used as an example. The flow of each faucet is 3.08GPM - 3.96GPM, and the internal pressure of the pipeline is the cumulative superimposed pressure.
-
Page 6: Installation Instructions
TIGERFLOW TIGERFLOW INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS OCELOT SIMPLEX BOOSTER OCELOT SIMPLEX BOOSTER Items to Check Before Installation Precautions to Check Before Installation - Inspect for any damaged parts - Use the template below to locate the mounting screws. - Inspect inlet and outlets and remove covers - Mount the screws through pump base opening, and ensure the pump is leveled. -
Page 7: Connection Points
TIGERFLOW TIGERFLOW INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS OCELOT SIMPLEX BOOSTER OCELOT SIMPLEX BOOSTER Connection Points Checklist For Inlet Connection - Ensure the incoming water is shut-off. 1. Incoming water is cut-off before connecting the inlet piping. 2. Inlet piping must be PVC or steel to avoid collapsing. -
Page 8: Operating Display
TIGERFLOW TIGERFLOW OPERATING DISPLAY OPERATING DISPLAY OCELOT SIMPLEX BOOSTER OCELOT SIMPLEX BOOSTER Operating Display Menu Pressure Setting Operating Display Indicating Lights THE PUMP IS RUNNING PIPELINE LEAK POWER FAILURE OPERATION: IMPORT WATER SHORTAGE ENERGY USAGE DISPLAY... - Page 9 TIGERFLOW TIGERFLOW OPERATING DISPLAY OPERATING DISPLAY OCELOT SIMPLEX BOOSTER OCELOT SIMPLEX BOOSTER Operating Display Changing Operating Mode Operating Display Reset Press theeeeeekey for 10 seconds to switch the operating mode. In automatic pressure mode, theeeeee light is on. In manual mode, the eeeeelight is off.
- Page 10 TIGERFLOW TIGERFLOW OPERATING DISPLAY OPERATING DISPLAY OCELOT SIMPLEX BOOSTER OCELOT SIMPLEX BOOSTER Press the start button to run the 1.After starting, the pump run pump. There is a 3 second delay indicating light is on. after power up 2.When the piping outlets are closed, the water will stop flowing and the pump will turn off.
-
Page 11: Exploded Diagram
TIGERFLOW TIGERFLOW EXPLODED DIAGRAM EXPLODED DIAGRAM OCELOT SIMPLEX BOOSTER OCELOT SIMPLEX BOOSTER Exploded Diagram Exploded Diagram Items Part Part Hull Fan cover Water inlet Guide glade Guide glade Capacitor box Impeller Gland Prop Controller Radiation fin Stator Seal holder Overhead tank... -
Page 12: Troubleshooting
TIGERFLOW TIGERFLOW TROUBLESHOOTING TROUBLESHOOTING OCELOT SIMPLEX BOOSTER OCELOT SIMPLEX BOOSTER The Pump Never Stops -Close the discharge valve, if the pump stops after a few seconds, check for leakage downstream of the valve. If the pump does not stop, check the check valve for any debris, and the pressure in the bladder tank. - Page 13 TIGERFLOW TIGERFLOW TROUBLESHOOTING TROUBLESHOOTING OCELOT SIMPLEX BOOSTER OCELOT SIMPLEX BOOSTER Assembly of Check Valve Inlet Check Valve Disassembly Instructions O-ring Disassembly Instructions Mechanical Seal Disassembly Instructions WETTED COMPONENTS...
-
Page 14: Factory Settings
TIGERFLOW TIGERFLOW TROUBLESHOOTING TROUBLESHOOTING OCELOT SIMPLEX BOOSTER OCELOT SIMPLEX BOOSTER Factory Settings Tank Disassembly Instructions Pressure Sensor Disassembly Instructions Action Instruction Notes To enter factory menu Simultaneously long press key to enter the factory menu. After entering the factory menu , Simultaneously long press... -
Page 15: Common Fault And Troubleshooting
TIGERFLOW TIGERFLOW TROUBLESHOOTING TROUBLESHOOTING OCELOT SIMPLEX BOOSTER OCELOT SIMPLEX BOOSTER Common Fault And Troubleshooting Common Faults And Solutions Error Code Corresponding Fault Troubleshooting Please check whether the panel cable is connected well, and try plugging and unplugging again. If it cannot be Panel and motherboard communication failure resolved. -
Page 16: Water Pump Maintenance
TIGERFLOW TIGERFLOW TROUBLESHOOTING MAINTENANCE OCELOT SIMPLEX BOOSTER OCELOT SIMPLEX BOOSTER Common Faults And Solutions Water Pump Maintenance Maintenance in operation 1. Inlet piping must be full of liquid and the pump shall not run in state of cavita- tion. 2. Check the motor current regularly to ensure is withing normal parameters.
