TARMOC TFT-B5-15MW-VFL Quick Start Manual

SMOOTH RUNWAY FOR YOUR NETWORK
Visual Fault Locator
* This product is developed and designed on the basis of
fullconsideration of safety
Please read the following precautions in this manual carefully
beforeuse.And strict compliance
1. Removing or oiling the cutting knife can cause malfunctions.So it is
absolutelyimpossible to implement.
2. The cutter belongs to precision machinery.Such as knocking, hitting theground,
being strongly impacted.lt may damage the precision of the cutter. ltmay
also cause injuries to people.Please be careful when using it.
3. Optical fiber and optical fiber debris are very fine and sharp.Sticking into
thefinger and into the eye will cause injury.Please be more careful whenoperating.
For safe operation.Please wear protective glasses.
4. Optical fiber and optical fiber debris are very fine and sharp.Sticking into
thefinger and into the eye will cause injury.Please be more careful whenoperating.
For safe operation.Please wear protective glasses.
Technical index
Model
Output wavelength
Interface Type
Quiescent Current
Working current
Battery life
Charging voltage
Recharging current
Charging time
Type of battery
Battery capacity
Product Size(mm)
Operating
temperature( ℃ )
Storage temperature( ℃ )
Net weight(g)
Instructions
1. Turn the rotary button clockwise to raise the laser head and turn it on, turn
the rotary button counterclockwise to hide the laser head and turn it off.
2. Short press (illumination button): turn on → turn off the LED lighting.
3. Long press (illumination button): When the 650 red light is turned on, long press
for 2 seconds to turn on → turn off the 650 flashing function; turn off the 650 red light
and automatically save the working state of the 650 red light when it is turned off.
4. Long press for 6 seconds (illuminated button), it is the reset function, and the
machine automatically restarts.
Charging function
When the battery power is too low, the power indicator in the last bar of
power-on flashes continuously and then power-off, please charge it before use.
Standard USB charging. When only one battery indicator is on, please charge.
The battery indicator flashes during the charging process, and all 4 battery indicators
are on after charging.
Standard accessories
Host, manual, warranty card, certificate, charging cable, ceramic tube.
Common fault solutions
Fault prompt
Does not boot
Weak red light
Normal luminescence but
not focusing
Maintenance and precautions
1. Lasers are harmful, especially eye protection. When the laser is working
it is strictly prohibited to look directly at the red light.
2. In general, the higher the temperature, the shorter the life of the laser
so try to avoid high temperature environments when using it.
3. After using for a period of time, please clean the interface with a special
optical fiber cleaning swab.
4. After use, please cover the dust cover to prevent dust from falling.
5. Please take out the battery if it is not used for a long time to avoid accidents
caused by battery leakage.
Maintenance regulations
1. Within twelve natural months after the user receives the goods, our company
will promise the quality and workmanship of its products. The warranty period is
within twelve months from the date of receipt. When the purchased product is
found to have quality problems during this period , Our company will make
corresponding treatment or replacement, but under any circumstances, our
responsibility will not exceed the purchase value of the product.
2. If there is a problem during the use of the instrument, it cannot be solved
according to the common fault prompt scheme. The user is not allowed to open the
case without authorization, please contact our company.
3. For product defects caused by faults, our company is responsible for free
maintenance or replacement of products.
This guarantee is only applicable to the normal use of the instrument, and there
is no damage or normal use, due to product quality or material defects caused by
failure, our company is responsible for free repair or replacement. Our company has
the right to refuse the warranty for accidents, improper use, and unauthorized
start-up maintenance.
2.5mm universal adapter
18650 lithium battery
-20 ~ +60 （ No condensation）
Possible Causes
Insufficient power
Insufficient power supply
or other
Ceramic tube cracking
TFT-B5-15MW-VFL
650nm
≤15uA
≤150mA
≥12H
5V
≤600mA
≤5H
1800mA
130x27
-40 ~ +85
≈96
Solution
Recharge
Charge or clean the laser
head
Replace the ceramic tube
