Summary of Contents for TTLITTLINY ZD-X18
- Page 1 ZD-X18 2.5K Dash Cam...
- Page 2 DO NOT leave the camera in direct sunlight for a long period of ● time or where the temperature could go above 140°F(60°C). Be sure the camera lens is clean and there is nothing blocking ● the lens. After-sales Email:support@ttlittliny.com...
-
Page 3: Interface Introduction
Interface Introduction Recording Interface ① : When recording starts, a red point will appear in Video ● the upper left corner : when locked, the red point will turn into a yellow point ●. ② : The recording time is displayed Recording Time Stamp under normal recording. -
Page 4: Playback Interface
⑪ Audio Icon : When this feature off, it will be like this. ⑫ Power Icon : The icon is displayed when the car charger is connected for charging. ⑬ License Plate : Set it in setting menu. 2. Playback Interface ①... - Page 5 front camera's file; the end represents the rear camera's file; R.ts represents the emergency recording's file.The the end SOS.ts time on the right represents the file generation time. ⑥ Park Monitoring File: Click to view the parking monitoring mode record video file. (The park monitoring files of the front and rear cameras are respectively saved in the "park F"...
-
Page 6: Setting Interface
4. Setting Interface Click "Settings Button" on the device to enter the setting interface, and the default selection is resolution. ① First level menu: Display the setting menu function, you can press the UP and DOWN keys to select, after selection, the content of the current corresponding first-level menu and the default items will be displayed in the second-level menu. - Page 7 overwrite the oldest clips. 3. Parking Monitoring Parking monitoring is divided into four modes: off, low, medium and high. The default is off. Low, medium and high indicate the sensitivity of vibration monitoring. When using without step-down line, In the off state, if the car vibrates slightly, the recorder will automatically start recording and lock and lock the touch.
- Page 8 4. Gravity Sensor The machine has a built-in G-sensor, and the gravity sensor is divided into four modes: off, low, medium, and high, the default is off. Low, medium and high indicate the sensitivity of vibration monitoring. Turn on the gravity sensing function, if the machine vibrates during the recording process (such as collision, ete.), the current video can be automatically locked.
- Page 9 9. Audio Turn on/off the audio. 10. Rear Mirror Streaming media mirroring is divided into two types: On and Off, and the default is Off. Turning on streaming mirroring will mirror the rear view camera. 11. WDR WDR (Wide Dynamic Range) technology helps balance exposure level.
- Page 10 of the recorder will prompt "Enter time-lapse video recording" prompt box, and then enter the record media interface, the recording mode is time-lapse video mode, and the screen will be turned off after 5s. If a touch operation occurs within 5s or a touch operation occurs after the screen is closed, the screen will be closed again after 10s.
- Page 11 16. License Plate Settings The license plate setting tip pops up, and the license plate can be set. The default is AB123456, 8 digits, and it can be set to six digits for the green license plate. This setting will be updated to the interface to display the license plate and the OSD license plate watermark.
