SG1&2
(2024 & After)
Pure Water System
Effective May, 2024
Pure Water
Window Cleaning System
Operation and Maintenance
Manual
Overview
Congratulations on your purchase.
Thank you for purchasing the SG Pure Water System!
With proper care, this unit will provide you with years
of trouble free service. This system was designed with
professional window cleaners in mind. The SG will help
you clean faster, safer, and better than ever before,
leaving spot free results that you and your customers
will love!
The following is provided to help you understand how
your system purifies water. The SG is a multi-stage
water purification unit using sediment, carbon, reverse
osmosis, and deionization to remove impurities from
water before delivery to surfaces for cleaning. General
lifespan of the filters will vary depending on feed water
TDS (Total Dissolved Solids). Based on an average
TDS of 100 ppm (parts per million) in your water,
approximately 20,000 gallons of water can be passed
through the Carbon/Sediment and DI filters before
replacement filters are needed. Lower TDS levels in the
source water will allow for a longer lifespan, while higher
TDS source levels will lead to a shorter lifespan. It is
recommended that the Carbon/Sediment and DI filters
be replaced at the same time. The RO membrane is
rated to process 100,000 gallons under ideal conditions.
Failure to properly maintain the RO membrane will
reduce the life of the filter.
In The Box
Parts Check
• SG System
• Handheld TDS Meter
• Shutoff Valve
• Pressure Gauge (SG2 only)
1. Unpacking/Inspecting The System
Your system is packaged to stay undamaged in transit.
Please inspect all components to ensure no damage
has occurred prior to continuing. Carefully remove the
packaging material from around the system and discard.
Your SG comes with all filters installed. Inspect your SG unit
for any shipping damage. If damage has occurred, notify
abc Window Cleaning Supply as soon as possible to begin
a damage claim. Check all fittings to ensure that they are
connected tightly, as they may loosen during shipping.
SG Pure Water System Operation and Maintenance Manual - 1
Advertisement
Table of Contents
Related Manuals for abc SG1
Summary of Contents for abc SG1
- Page 1 If damage has occurred, notify approximately 20,000 gallons of water can be passed abc Window Cleaning Supply as soon as possible to begin through the Carbon/Sediment and DI filters before a damage claim. Check all fittings to ensure that they are replacement filters are needed.
- Page 2 BYPASS LINE WHILE USING THE SYSTEM (some bypass water should always be flowing out). See Bypass Valve Operation section below for more Follow these steps for starting up the SG1. If information. you have an SG2 (it will have a pump and motor 10.
- Page 3 result in the plastic overheating and pressure rating 4. Bypass Valve Operation of the RO housing dropping. Setting your system up out of direct sunlight on hot days will also help protect the plastic RO housing from heat damage. 11. Once the air has been pushed out of the filters, close the bypass valve partially to begin producing pure water.
- Page 4 5. SG2 Pump Operation If you experience little or no flow coming out of the bypass tube attached to the RO with your source water turned on, the pump may be restricting flow. The pump is located before the RO membrane, so no bypass flow usually indicates that the pump is restricting flow.
-
Page 5: Maintenance
As with any new procedure, clean water as the temperature of the water gets colder. practicing the use of your WaterFed® A pump can help to compensate for low source water temperatures. Do not let the system or any filter freeze pole is the best way to achieve optimal results. -
Page 6: Filter Replacement
When the TDS levels reach 5. Tighten the bolt to secure the filter (checking to make unacceptable levels for your application (abc suggests sure that the filter is seated in the bottom clip). 10ppm or less for window cleaning and 40ppm or less 6. - Page 7 1. Remove the RO Membrane through the membrane. This will deplete the downstream DI filters at a faster rate. abc recommends that you run water Start by removing the RO membrane from the frame. through your Carbon/Sediment filter and RO membrane With the unit standing upright, use a 7/16”...
-
Page 8: Troubleshooting
(½”) or a shorter hose length between the system and long and short bolts we just affixed. Insert the long bolt on the tap can also improve flow. If using the SG1, adding a pump, such as the abc boost pump (WF1000-BP) the left side of the mounting bracket and the remaining short bolt on the right side. - Page 9 Replacement parts your water sample. Do not get the body of the meter wet, can be ordered from abc or bought from a local store. it is not waterproof. Minerals can stay in the cap from The plastic hole size is ½”...
- Page 10 The customer must first contact abc Window Cleaning merchandise and insuring that the product is properly Supply to notify them of the problem. abc Window packaged to arrive in a new resellable condition. The Cleaning Supply may require the merchandise to be customer is responsible for all costs associated with shipped back to them at the customer’s expense to...
-
Page 11: Replacement Parts
SG 1 > SG2 Upgrade Kit Outlet Splitter Kit 10’ Source Hose WF7000-OSK WF612010 TSSG-Upgrade Replacement Hoses available upon request. 1-800-989-4003 www.abcWindowSupply.com 12371 Mead Way, Littleton, CO 80125 1.800.989.4003 // ©abc Window Cleaning Supply, Inc. SG Pure Water System Operation and Maintenance Manual - 11...
