- Page 1 Controllers (HP series) HP2410/HP2420 User manual www.terko.com.uy...
- Page 2 LCD screen Mounting holes Solar Battery Load panel 3. Installation instructions and precautions 1) The controller shall be installed securely, and its dimensions are as follows: HP2410 External dimensions:103×71×36 (mm) Installation dimensions:96×60 (mm) HP2420/HP2420-S External dimensions:130×75×38 (mm) Installation dimensions:122×64 (mm) www.terko.com.uy...
- Page 3 Only when in-flow energy outpaces out-flow energy can the battery be charged fully. Users shall bear this in mind when configuring the system. Check whether the controller's each connection terminal is tightened securely; if not, it may suffer damage when there is excessive current. www.terko.com.uy...
- Page 4 1 minute Operating temperature -25 ℃ to +55 ℃ IP protection degree IP30 Net weight 100 g 160 g Solar panel short circuit and reverse-connection protection Protection functions Over-temperature, overload and short circuit protection 103×71×36 (mm) 130×75×38 (mm) Dimensions www.terko.com.uy...
- Page 5 Daytime or charging Steady on Night recognition Steady off Quick flashing Load short circuit or overload Steady on Load switched on Steady off Load switched off Normal battery All on Over discharge Only the outline flashes Over voltage 3 dashes flashing www.terko.com.uy...
- Page 6 10s to let the system save and exit automatically. Load mode Mode flashing Mode flashing Long Short press press the key the key Set the needed mode Long press the Load mode key to save the setting www.terko.com.uy...
- Page 7 Load switched on Load switched off Short press the key Note: As load start is a type of soft start, display of the load icon on the LCD screen will be delayed after the load is switched on. www.terko.com.uy...
- Page 8 The load icon flashes quickly, short-circuited. After the problem is solved, long press and there is no output. the key or wait until it recovers automatically. Check whether wiring is sound and reliable, Other symptoms and system voltage is correctly recognized. www.terko.com.uy...
-
Page 9: Warranty Card
4) Damage or loss caused by external causes due to force majeure 5) Disassemble or modify without authorization from the supplier 6) Violation machine operation / terms of use (such as continuous overloading, wrong battery input voltage) Customer signature: Date: www.terko.com.uy...
