PRODUCT INTRODUCTION
This product is a multi-functional USB-C
USB-C ™ 3.2 Gen 1 + HDMI 4K@60HZ+ PD 100W + SD/TF 3.0 + Audio. It allows to
expand more interfaces on your mobile phone, iPad, tablet and other devices with
USB-C ™ 3.2 Gen 1 port. The output of HDMI is suitable for projector, display screen,
TV and other devices. The HDMI resolution supports up to 4K@60Hz output; the
extended USB 3.2 Gen 1 can connect USB mouse, keyboard, USB ash disk, mobile
hard disk, card reader and other digital products to read and write data. USB 3.2 Gen
1 transmission rate can reach 5Gbps, and can provide 5V/0.9A power supply for
external electronic equipment; the USB-C
transfer and 5V/0.9A power supply for external USB-C
equipment; 100W PD fast charging power supply, allows charging and playing
without power loss. The card reader supports most of memory cards such as
SD/SDHC, micro SD, micro SDHC etc. The 3.5 mm audio output can be used to
connect microphone and earphone. The shell is made of aluminium alloy and it has a
shape of an iPad stand, which is foldable and allows a 360° rotation. It is for sure
easy to carry.
MAIN FEATURES
• Use a USB-C 3.2 Gen 1 male to USB-C
™
ICA-TBL DOCK81 host and your devices to use.
• When using the product, if the device connected to the product is disconnected,
the data will be lost. The connection will be restored after a few seconds.
• PD function requires connection to an external PD wall charger.
• USB Ports are recommended for data transmission and should not be used as an
output current unless the computer or HUB is connected to a power supply.
• 3.0 Card reader, SD Card and TF card cannot be used at the same time.
• PD charging is required when connected to high-power devices such as the large
capacity portable hard disk.
• The operating temperature is about 45°C.
SPECIFICATIONS SPECIFICATIONS
ITEM DESCRIPTION
Product
ICA-TBL DOCK81
Model
178 mm (L)
Size 160 mm (W)
55 mm (H)
Materials Aluminium Alloy
Input: USB-C ;
™
Output: 2*USB-A 3.2 Gen 1 +
Interface USB-C ™ 3.2 Gen 1 + HDMI
4K@60HZ + PD 100W + SD/TF
3.0 + Audio (Mic+earphone)
VL171 + GL3510 + VL162
Chipset + GL3224 + SL2.1 + AC1279
+ IM2603 + AG9411
Data
5Gbps
Transmission
High
4K(3840*2160)@60Hz
Resolution
Compatible for PC, Macbook,
mobile phone, digital camera,
Application
camera and other products with
USB-C interface.
™
Working
0°C ~ 50°C
Temperature
Storage
-20°C ~ 80°C
Temperature
Relative 0% to 90% in
Humidity non-condensing state
WWW.TECHLY.COM
hub: USB-C to 2*USB-A 3.2 Gen 1 +
™ ™
™ 3.2 Gen 1 interface can be used for date
interface electronic
™
3.2 Gen 1 male cable to connect the
™
REMARK
Sliver
Atmospheric pressure:
101.325kPa
Contact surface
temperature: <50°C
USB-C
INTENDED USE
We do not permit using the device in other ways like described in this
user's manual. Use the product only in dry interior rooms. Not attending
to these regulations and safety instruction might cause fatal accidents,
injuries, and damages to persons and property. The manufacturer/
supplier assumes no liability for damages caused by failure to comply with the
intended use.
SAFETY INDICATIONS
• Your product is not a toy and is not meant for children, because it contains small
parts which can be swallowed and can injure when used inappropriately! • Please
install the system and devices attached to it in a way that persons cannot be injured,
or objects not be damaged for example by dropping or stumbling. • Please remove
the packing materials, because children may cut themselves on them while playing.
• Avoid places with high temperatures, or humidity, or places which might come into
contact with water. Do not install the product close to openings of air conditioners, or
at places with an excessive amount of dust or smoke. • Do not install the product at
places subject to vibration or oscillation • Do not modify and alter the product and any
accessories! Do not use any damaged parts. • Keep enough space around all devices
for a good ventilation and free motion and to avoid damages.
In compliance with EU Directive WEEE this product is marked with
this symbol. It means that used electrical and electronic products
should not be mixed with general household waste. There is a separate
collections system for these products in compliance with WEEE
directive, otherwise contaminative and hazardous substances can
pollute the environment.
With the CE sign, Techly
basic European standards and directives.
TABLET STAND WITH
DOCKING STATION
™
® ensures that the product is conformed to the
