Item #1008 017 093
Model #FCS01380-2PK
USE AND CARE GUIDE
STEEL SLING CHAIR RIVERBED 2PK
Questions, problems, missing parts?
Before returning to the store, call Stylewell Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in StyleWell through the purchase of this chair. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement
needs. Thank you for choosing StyleWell!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StyleWell FCS01380-2PK
Summary of Contents for StyleWell FCS01380-2PK
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in StyleWell through the purchase of this chair. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly ..............3 Planning Assembly ..............3 Important Safety Instructions ........2 Hardware Included ..............3 Save These Instructions ............2 Package Contents..............Read All Instructions Before Use ..........2 Assembly................. -
Page 3: Warranty
Warranty 1 YEAR FRAME AND 1 YEAR FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant to be free of manufacturing defects to the original purchaser for one year for the frame and one year for the fabric. WHAT IS NOT COVERED It remains the customer’s responsibility for freight and packaging charges to and from our service center. -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS Part Description Quantity Right arm Left arm Cross bar Backrest tension bar Sling bucket... -
Page 5: Assembly
Assembly Inserting the Cross Bars into the Left Arm Place the left arm (B) on a soft surface. Insert the cross bars (C) into the left arm (B). Connecting the Cross Bars to the Chair Arms Insert the cross bars (C) into the right arm (A). Connect the cross bars (C) to right arm (A) and the left arm (B) using M6x15 combination bolts (BB). - Page 6 Assembly (continued) Unfolding the Sling Bucket Unfold the sling bucket (E), as shown below. Connecting the Sling Bucket to the Chair Arms Place the sling bucket (E) upside down on a soft surface. Connect the sling bucket (E) to the right arm (A) and the left arm (B) using M8x35 combination hex bolts (AA). NOTE: Loosely tighten all the bolts using wrench (FF).
- Page 7 Assembly (continued) Connecting the Backrest Tension Bar to the Sling Bucket Put the M8 plastic washer (CC) into the backrest tension bar (D), as shown below. Put the left side of backrest tension bar (D) into the sling bucket (E) rst and then insert the right side of backrest tension bar (D) into the sling bucket (E).
-
Page 8: Care And Cleaning
Assembly (continued) Tightening All Bolts Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (EE) and wrench (FF). Ensure all connections are secure before use. Care and Cleaning For best results, clean the chairs with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. - Page 9 Questions, problems, missing parts? Before returning to the store, call StyleWell Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use. For certification use only...
