Summary of Contents for Hougen 10950
- Page 1 Resharpening Companion 10950 Correct Angles, Pictures, and Step-By-Step Instructions...
-
Page 2: Setting Up Your Machine
BENCH / STAND SUPPORT FOR YOUR NEW SHARPENING MACHINE Your new Model 10950 may be mounted to a bench-top with a thickness of 5/8" to 3/4" using the socket head cap screws provided. If your bench top thickness is not in this range, alternate screws must be used to properly secure the machine. - Page 3 Read and follow operator’s manual. Check and comply with all applicable federal, state, local, and company safety standards. If you cannot locate your operator’s manual, call or write to Hougen Mfg., Inc. for additional FREE copy. Unplug from power when changing tools or servicing machine. Keep fingers away from grinding area during operation.
- Page 4 ANATOMY OF A CUTTER "12,000-Series" Standard Cutter up to 13/16" (21mm) (See Instructions starting on Page 5) REGRINDING ORDER Outside Inclination 1. Gullets (If needed) Gullets 2. Inside Inclination Angle Inside Inclination 3. Outside Inclination Angle " "12,000-Series" Standard Cutter 7/8" (22mm) to 2-3/8 (60mm) (See Instructions starting on Page 8) REGRINDING ORDER Gullets...
- Page 5 GULLETS • It is not necessary to deepen the gullets every time you sharpen the teeth. A new cutter has .075 to .125" (1.91mm to 3.18mm) of gullet depth. When the gullet depth is reduced and becomes less that .065" (1.65mm) you must grind the gullet to increase the depth.
- Page 6 PRIMARY INCLINATION ANGLE • Install the cup-grinding wheel into the motor. Insert the shank of the cutter you are going to sharpen into the tool holder. Align the flat on the shank of the cutter with the set screw. Tighten the set screw.
- Page 7 OUTSIDE INCLINATION ANGLE • Install the cup-grinding wheel into the motor. Loosen the spindle-locking handle and rotate the cutter to a 3:00 Outside o’clock position. Use your steel ruler to align the cutter in Inclination shown in the proper position. Upon aligning the cutter, tighten the yellow spindle locking handle.
- Page 8 HOUGEN-EDGE ® CUTTERS Cutters 7/8" to 2-3/8 " • The "12,000-Series" cutters (7/8" and larger) are more complex and have four major surfaces on the cutter. The surfaces are identified by: - Primary Inclination Angle - Secondary Inclination Angle - Outside Inclination Angle - Gullets •...
- Page 9 HOUGEN-EDGE ® CUTTERS - Continued from Page 8 - Cutters 7/8" to 2-3/8 " Gullets (Refer to Page 5) • If the gullet is less than .065 you will need to deepen the gullets. To deepen the gullets use the same procedures as the standard cutters.
- Page 10 10950 EXPLODED VIEW 05413 GGS 27L(A Model) 03979 04940 10624 10543 05411 04941(A Model) 03784 10624 41055 03983 10791 03972 41090 41046 41091 10541 41058 41092 01893 41092 41070 04103 41120 03971 03964 41074 41119 41077 41004 04115 03984 41049...
-
Page 11: Parts List
PARTS LIST Part # Description Part # Description 01893 Screw - Drive #2 x 3/16 04115 Wick Oil Screw SOC Set 3/8-16 04940 Motor Base Plate 01990 x 1/4 Cup 04941 Motor Bracket ( A Model) 02385 Screw BHC #6-32 x 1/4 05411 Motor Plate - Upper Screw SOC Set 5/15-18... - Page 12 .040" (1.02mm). A new cutter has sufficient gullet depth, roughly .050 to .090" (1.27mm to 2.29mm) • More time must be taken with Hougen-Edge Cutters. Remember they have a height variation of .007" (.177mm) •...
