Cadex MY23 TRI Technical Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
|ENGLISH|
MY23 TRI TECHNICAL MANUAL
|ENGLISH|
MY23 TRI TECHNICAL MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the MY23 TRI and is the answer not in the manual?

Questions and answers

Related Manuals for Cadex MY23 TRI

Summary of Contents for Cadex MY23 TRI

  • Page 1 |ENGLISH| MY23 TRI TECHNICAL MANUAL |ENGLISH| MY23 TRI TECHNICAL MANUAL...
  • Page 2 |ENGLISH| MY23 TRI TECHNICAL MANUAL 1. MY23 TRI 1.1 PARTS LIST_COCKPIT...
  • Page 3 |ENGLISH| MY23 TRI TECHNICAL MANUAL 1.2 PARTS LIST_H.SET PART Item Name Part Number Size 380000063 Top Cap 160000009 Headset Fork steering axle 上側の10ｍｍHEXで玉当たりを調整後、下側の6mmHEXを締め付け、フォークを固定します。...
  • Page 4 |ENGLISH| MY23 TRI TECHNICAL MANUAL 1.3 PARTS LIST_STORAGE SYSTEM Item Name Part Number Size 380000065 For M, L 380000066 Bento Box For XS, S 380000067 For XXS 470000003 For S, M, L Hydration Bag with Straw 470000004 For XXS, XS...
  • Page 5 |ENGLISH| MY23 TRI TECHNICAL MANUAL 1.4 PARTS LIST_AERO BARS Item Name Part Number 180000374 Sync Arm Pad 180000373 Sync Arm Cup Set Sync Evo Extensions 180000372 (including extensions, extension grips, computer mount, end cap) Extension grip 410000159 Computer Mount 180000407...
  • Page 6 |ENGLISH| MY23 TRI TECHNICAL MANUAL The bolt for SRAM Blip box, M4*L8 ONLY Item Name Part Number Note Size 180000371 Handlebar Bridge 470000005 Straw Adapter 380000053 380000054 380000055 MATT BLK 380000056 380000057 HT front cover set 380000058 380000059 380000060 GLOSS BLK...
  • Page 7 |ENGLISH| MY23 TRI TECHNICAL MANUAL 1.5 PARTS LIST_HANDALBAR Item Name Part Number Note 180000407 Handlebar Item 2 + 3 Shims only Handlebar shim 2 pcs / left and right Double-sided tape 4 pcs / one bike 1.6 PARTS LIST_HEADTUBE Item...
  • Page 8 |ENGLISH| MY23 TRI TECHNICAL MANUAL ! WARNING Notifications for Long Bolts (L100 mm) Suitable spacer height: 0~40mm Key Points No matter which angle of clamp and spacer you are using, the maximum height of spacer should not exceed 40mm. In other word, there are always maximum 4pcs of 10mm spacer underneath the extension clamp.
  • Page 9 |ENGLISH| MY23 TRI TECHNICAL MANUAL DETAILS INFORMATION _ SPACER...
  • Page 10 |ENGLISH| MY23 TRI TECHNICAL MANUAL DETAILS INFORMATION _ CLAMPS...
  • Page 11 |ENGLISH| MY23 TRI TECHNICAL MANUAL 1.7 PARTS LIST _SEATPOST Item Name Part Number 150000122 Seat-post Saddle Clamp Seatpost set 150000124 ISC cover 150000123 1.8 PARTS LIST _FRAMES ❶ ❶ Please apply the anti-slip paste inside the round clamp The other 7x9 top clamp for carbon rail...
  • Page 12 |ENGLISH| MY23 TRI TECHNICAL MANUAL Item Name Part Number Note 133480060 Cable plug 270000003 Hanger Unit Including hanger body, bolt, hanger nut 137520780 Di2 Cable plug For SHIMANO Wireless plug or SRAM 300000171 Thru Axle Front 300000110 Rear thru axle...
  • Page 13 |ENGLISH| MY23 TRI TECHNICAL MANUAL Item Name Note ST bottle mount 130520010※ FD adapter EW-GM300-S (シマノより入手可能) Di2 cable plug 133441200 No hole cap Battery holder ※フロントシングルの場合は➑を取り外し、➓ のキャップでねじ穴を塞ぎます。...
  • Page 14 |ENGLISH| MY23 TRI TECHNICAL MANUAL 1.9 PART LIST_ CABLE PROTECTIONS Item Name Part Number Note Nylon sleeve D5 For Disc cable protection. L100 mm Nylon sleeve D10 For straw protection. L100 mm For rear hydraulic cable. L700 mm Protection foam (cut it for difference frame size) 1.10 PART LIST_ CABLE PROTECTIONS...
  • Page 15 |ENGLISH| MY23 TRI TECHNICAL MANUAL STRAW ███ Cable Routing_Using Straw * Straw goes to right side of frame 1.11 CABLE ROUTING_DISC BRAKE Front Disc Brake Rear Disc Brake ███ ███...

  • Page 16: Left Side

    |ENGLISH| MY23 TRI TECHNICAL MANUAL LEFT SIDE RIGHT SIDE Front Disc Brake Rear Disc Brake ███ ███...
  • Page 17 |ENGLISH| MY23 TRI TECHNICAL MANUAL 1.12 CABLE ROUTING_SHIMANO E-CABLE Front Disc Brake Rear Disc Brake E-cables (HB) E-cables (Extensions) ███ ███ ███ ███ Item Note Qty. (pcs) SM-JC41 EW-SD50 EW-JC130-SM EW-AD305 EW-SD300 BT-DN-300...
  • Page 18 |ENGLISH| MY23 TRI TECHNICAL MANUAL Item Note SM-JC41 EW-JC130-SM EW-AD305 (Into from to connect AD305, near BB)
  • Page 19 |ENGLISH| MY23 TRI TECHNICAL MANUAL Item Note Recommend Length To HB-R To HB-L To link JC130 and JC41 To Extension-L To Extension-R 600 for XXS To link JC41 and AD305 650 for XS~S 700 for M~L...
  • Page 20 |ENGLISH| MY23 TRI TECHNICAL MANUAL Item Note Recommend Length 600 for XXS To link JC41 and AD305 650 for XS~S 700 for M~L To link AD305 and BT-DN300 To FD To RD...
  • Page 21 |ENGLISH| MY23 TRI TECHNICAL MANUAL 1.13 CABLE ROUTING_SRAM E-CABLE Front Disc Brake Rear Disc Brake E-cables (HB) E-cables (Extensions) ███ ███ ███ ███...
  • Page 22 |ENGLISH| MY23 TRI TECHNICAL MANUAL Item Note Qty.(Set) ES-EAC-CLIC-A1 ES-EAC-BLIP-A1 ES-EAC-BBOX-D1...
  • Page 23 |ENGLISH| MY23 TRI TECHNICAL MANUAL Item Note Recommend Length To HB-R To HB-L To Extension-R To Extension-L...
  • Page 24 |ENGLISH| MY23 TRI TECHNICAL MANUAL ASSEMBLY INSTRUCTIONS _ STEP BY STEP STEP 1 Mount the Blipbox STEP 2 Mount the adapter onto the fork...

  • Page 25: Cable Length Reference

    |ENGLISH| MY23 TRI TECHNICAL MANUAL 1.14 CABLE LENGTH REFERENCE * SHIMANO system Name Length Qty. Notes SM-JC41 junction box 1 pc located in HT aero cover for extension for extension e-cable EW-SD50 3 pcs located in frame for connecting AD305 to junction D 2.6...
