EDAM-8510
Isolated RS-422/485 Repeater
Introduction
The EDAM-8510 repeater boosts the RS-422/485 signals to extend the reach distance up to 4000 ft
(1200 m) and increase the maximum number of connected nodes up to 128.
With a special circuitry, EDAM-8510 is able to automatically detect the data flow and switch the
direction of the data lines accordingly.
"Auto baud rate detector" enables EDAM-8510 to automatically configure RS-422/485 signals to
any baud rate without external switch setting.
Build in Opto-isolators on EDAM-8510 provides 3000 Vdc of isolation to protect the host computer
from ground loops and destructive voltage spikes on the RS-422/485 data lines.
EDAM-8510 also offers internal surge-protection on the data lines. Internal high-speed transient
suppressors on each data line protect the module from dangerous voltages levels or spikes.
Features
• Automatic internal RS-422/485 bus supervision
• No external flow control signals required for RS-485
• Minimum 3000 V DC isolation protection
• Transient suppression on RS-485 data lines
• Supported baudrate up to 115.2 Kbps
• Reach distance up to 4000 feet (1200 m)
• Reserved space for termination resistors(R8,R9)
• Power and data flow indicator for troubleshooting
• Power requirement: +10 to +30 Vdc
• Mounts easily on DIN-rail or panel
Specifications:
• Power requirement: Unregulated +10 to +30 V DC with protection from power reversals
• Case: ABS with captive mounting hardware
• Accessories (Supplied):NYLON DIN-rail Mounting Adapter SECC Panel Mounting Bracket
• Plug-in screw terminal wiring: Accepts AWG 1-#12 to #22 (0.5 to 2.5 mm) wires
• Supported baudrates (bps):1200, 2400, 4800, 9600, 19.2 K, 38.4 K, 57.6 K, 115.2 K
• Isolation voltage: 3000 Vdc
• RS-422/RS-485 connector: plug-in screw terminal
• Power consumption: 0.7W
• Operating temperature:0 ~ 70 °C (32 ~ 158 °F)
• Storage temperature:-25 ~ 85 °C (13 ~ 185 °F)
• Humidity: 5 ~ 95%, non-condensing
Power supply
EDAM modules are designed to accept industry standard +24 Vdc unregulated power. Operation is
guaranteed when using any power supply between +10 and +30 Vdc.
Power ripples must be limited to 5V peak to peak while the voltage in all cases must be maintained
between +10 and +30 Vdc. All power supply specifications are referenced at module connector.
