Owner's Manual
(LED Monitor*)
* LG LED Monitor applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and retain it for future reference.
27GP95RP
27GP95U
www.lg.com
Copyright
2023 LG Electronics Inc. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UltraGear 27GP95U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG UltraGear 27GP95U

Summary of Contents for LG UltraGear 27GP95U

  • Page 1 Owner’s Manual (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 27GP95RP 27GP95U www.lg.com Copyright 2023 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS LICENSE ........3 USING THE MONITOR ....15 - Connecting to a PC...........15 OPEN SOURCE SOFTWARE HDMI Connection NOTICE INFORMATION ....4 DisplayPort Connection - Connecting AV Devices ...........16 ASSEMBLING AND PREPARING 4 HDMI Connection - Supported Drivers and Software ......5 - Connecting Peripherals...........17 - Product and Button Description......5 USB Device connection...

  • Page 3: License

    LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. The SuperSpeed USB Trident logo is a registered trademark of USB Implementers Forum, Inc.

  • Page 4: Open Source Software Notice Information

    • It is recommended that use the supplied components. • If you use generic cables not certified by LG, the screen may not display or there may be image noises. • Illustrations in this document represent typical procedures, so they may look different from the actual product.

  • Page 5: Supported Drivers And Software

    Supported Drivers and Software Product and Button Description You can download and install the latest version from the LGE website (www.lg.com). Drivers and Software Installation Priority Monitor Driver Recommended Recommended LG Calibration Studio Optional Joystick Button...

  • Page 6: How To Use The Joystick Button

    Moving and Lifting the Monitor How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or When moving or lifting the monitor, follow these instructions to prevent the monitor moving it left/right/up/down with your finger. from being scratched or damaged and to ensure safe transportation, regardless of its shape or size.

  • Page 7: Installing On A Table

    Installing on a Table CAUTION • Lift the monitor and place it on the table in an upright position. Place the monitor • Avoid touching the monitor screen as much as possible. at least 100 mm away from the wall to ensure sufficient ventilation. - This may result in damage to the screen or some of the pixels used to create images.

  • Page 8: Adjusting The Stand Height

    Adjusting the Stand Height CAUTION Place the monitor mounted on the stand base in an upright position. • Unplug the power cord before moving or installing the monitor. There is risk of Handle the monitor with both hands for safety. electric shock.

  • Page 9: Adjusting The Angle

    27GP95U Adjusting the Angle • Be careful not to touch or press the screen area when adjusting the angle of the monitor. Place the monitor mounted on the stand base in an upright position. Adjust the angle of the screen. The angle of the screen can be adjusted forward or backward from -5°...

  • Page 10: Pivot Feature

    Pivot Feature Raise the monitor to the maximum height. The pivot feature allows the monitor to rotate 90° clockwise. Head 27GP95RP 27GP95U Adjust the angle of the monitor in the direction of the arrow as shown in the figure. 27GP95RP 27GP95U Stand WARNING...

  • Page 11: Tidying Up Cables

    Tidying up Cables Rotate the monitor clockwise as shown in the figure. Arrange the cables using the cable holder as shown in the illustration. Mouse Holder Complete the installation by rotating the monitor 90° as shown below. 27GP95RP 27GP95U WARNING •...

  • Page 12: Using The Kensington Lock

    Using the Kensington Lock Installing the Wall Mount Plate The connector for the Kensington security system is located at the bottom of the This monitor meets the specifications for the wall mount plate or other compatible monitor. devices. For more information on installation and usage, refer to the Kensington lock owner’s Place the screen face down.

  • Page 13: Installing On The Wall

    If you use screws longer than the standard length, it may damage the inside of bracket. the product. A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable for any accidents relating to the use of non- standard screws. 100 mm Wall Mount (mm)
  • Page 14 Installing the monitor on the ceiling or on a slanted wall may result in the monitor Back of the falling off, which could lead to injury. Use an authorised LG wall mount and contact Monitor the local dealer or qualified personnel.

  • Page 15: Using The Monitor

    USING THE MONITOR Connecting to a PC • This monitor supports the *Plug and Play feature. • Illustrations in this manual may differ from the actual product. * Plug and Play: A feature that allows you to add a device to your computer without Press the joystick button, go to Settings →...

  • Page 16: Displayport Connection

    Connecting AV Devices DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. HDMI Connection NOTE HDMI transmits digital video and audio signals from your AV device to the monitor. • There may be no video or audio output depending on the DP (DisplayPort) version of the PC.

  • Page 17: Connecting Peripherals

    Connecting Peripherals Connecting Headphones Connect peripherals to the monitor via the headphones port. USB Device connection NOTE The USB port on the product functions as a USB hub. • Peripheral devices are sold separately. To use USB 3.0, connect the A-B type USB 3.0 cable of the product to the PC. •...

  • Page 18: User Settings

    USER SETTINGS Button Menu Status Description Main menu disabled Enables the main menu. Enters the Settings feature. Activating the Main Menu (Holding down the button to turn off the monitor. You can Main menu enabled turn off the monitor this way at any time, including when the Press the joystick button on the bottom of the OSD is on.) monitor.

  • Page 19: Main Menu Features

    Main Menu Features Main Menu Description Power Off Input Sets input mode. Power Off Turns off the monitor. Settings Input Game Mode Settings Configures the screen settings. Exit Game Mode Sets the game mode for gaming. Exit Exits the main menu.

  • Page 20: User Settings

    User Settings Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Settings. Configure the options by moving the joystick up/down/left/right. To return to the upper menu or set other menu items, move the joystick to or pressing ( ) it.
  • Page 21 This mode is for users who cannot distinguish between red and green. It enables users with colour weakness to easily Color Weakness distinguish between the two colours. Calibration 1 Adjusts to the calibrated screen. Calibration 2 NOTE Calibration 1/Calibration 2 : Please install LG Calibration Studio to run calibration. •...
  • Page 22 Game Mode on HDR signal. Settings > Game Mode Description Gamer 1 In this mode, users can customise elements including game-related options. Gamer 1 and Gamer 2 picture modes allow you to save two sets of customised display settings, including game-related Gamer 2 setup options.
  • Page 23 Settings > Game Adjust Description Sets Overclock to a higher refresh rate than specified by the panel specification. Disables the Overclock improvement feature. NOTE Overclock • After the monitor reboots, change the maximum refresh rate setting in the GPU control panel. •...
  • Page 24 Sets a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended that you use Fast. For a fast-moving picture, it is recommended that you use Faster. Once Faster Mode is selected, Motion Blur may occur depending on the content. Response Time Faster Sets the response time to faster.
  • Page 25 Settings > Picture Adjust Description Brightness Adjusts the brightness of the screen. Contrast Adjusts the contrast of the screen. Sharpness Adjusts the sharpness of the screen. Mode 1, Mode 2, The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma value, the Mode 3 lighter the image becomes.
  • Page 26 Maximizes the contrast ratio by making the bright areas of the screen brighter and the dark areas of the screen darker. Turning this option off may increase energy consumption. Faster Sets the local dimming to faster. Local Dimming Fast Sets the local dimming to fast. Normal Sets the local dimming to normal.
  • Page 27 Settings > Input Description Input List Selects the input mode. Adjusts the aspect ratio of the screen. Aspect Ratio Full Wide Displays the video in widescreen, regardless of the video signal input. Input Displays the video in 4:3. When automatic input switch is set to On, display will automatically switch to new input when connected. Auto Input Switch Enables Auto Input Switch.
  • Page 28 Settings > General Description Language Sets the menu screen to the desired language. User-defined Key 1 You can customise the main menu to access your preferred menu easily. User-definded Key 1 and User-definded Key 2 appear at the left/right of the main menu. User-defined Key 2 Select the sound equipment what you are using.
  • Page 29 Feature that automatically turns off the monitor when there is no movement on the screen for a period of time. You can set Automatic Standby a timer for the auto-off function. (8H, 6H, 4H and Off) Please set the Input Compatibility Version to match the version of the connected external device. 2.1(PC)/2.1(AV)/1.4 HDMI If you want to use the HDR, select the Input Compatibility Version to 2.1(PC) or 2.1(AV).

  • Page 30: Troubleshooting

    Have you installed the display driver? • Be sure to install the display driver from our web site: http://www.lg.com. • Make sure to check if the graphics card supports Plug and Play function. Some features are disabled.
  • Page 31 The screen retains an image. Does image sticking occur even when the • Displaying a still image for a prolonged time may cause damage to the screen, resulting in the retention of the image. monitor is turned off? • To extend the lifetime of the monitor, use a screensaver. Screen display is unstable and shaky.
  • Page 32 NOTE • Vertical Frequency: In order to display an image, the screen must be refreshed dozens of times per second, like a fluorescent lamp. The number of times the screen is refreshed per second is called vertical frequency, or refresh rate, and is represented by Hz. •...
  • Page 33 The display colour is abnormal. Does the display appear discoloured • Set the colour to 24 bit (true colour) or higher. In Windows, go to Control Panel > Display > Settings > Colour Quality. (The (16 colours)? settings may differ depending on the operating system (OS) you use.) Does the display colour appear unstable •...

  • Page 34: Product Specification

    PRODUCT SPECIFICATION LCD Screen Colour Depth HDMI 8-bit/10-bit colour is supported. DP (DisplayPort) 10-bit colour is supported. Resolution Max Resolution 3840 x 2160 @ 144 Hz (HDMI) 3840 x 2160 @ 160 Hz (DP / Overclock On) Recommended Resolution 3840 x 2160 @ 144 Hz (HDMI) 3840 x 2160 @ 144 Hz (DP) Power Sources Power Rating...
  • Page 35 Dimensions Monitor Size (Width x Height x Depth) With Stand 27GP95RP 609.2 x 574.7 x 291.2 (mm) 27GP95U 609.2 x 577.9 x 253.7 (mm) Without Stand 609.2 x 352.9 x 54.3 (mm) Weight (Without Packaging) With Stand 27GP95RP 7.4 kg 27GP95U 7.2 kg Without Stand...

  • Page 36: Factory Support Mode

    Factory Support Mode HDMI Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.897 60.317 1024 x 768 48.363 1280 x 720 44.444 59.979 1280 x 1024 79.976 75.025 1920 x 1080 67.5 1920 x 1080 66.587...
  • Page 37 DisplayPort Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.897 60.317 1024 x 768 48.363 1280 x 720 44.444 59.979 1280 x 1024 79.976 75.025 1920 x 1080 67.5 1920 x 1080 166.587 143.981 Recommended Timing...

  • Page 38: Hdmi Timing (Video)

    HDMI Timing (Video) Factory support mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Remarks (Preset Mode) 480P 31.5 720P 1080P 67.5 1080P 2160P 2160P...

  • Page 39: Power Led

    Power LED Mode LED Colour On Mode Red (For a few seconds) Sleep Mode (Standby Mode) Off Mode...
  • Page 40 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Model Serial No.
