Summary of Contents for UTE ATS358S022
- Page 1 User Manual ATS358S022 Monitored Automatic Transfer Switch PDU All Rights Reserved Version: ATS358S022_2023V1.0 www.ute.de...
- Page 2 Different models and specifications are subject to real product. This manual is only for operation instruction of ATS358S022, please contact the local distributor for maintenance assistance. The functions described in this version were updated till January, 2023. In the constant effort to improve the product, we reserve the right to make functions or parameters changes without notice or obligation.
- Page 3 It may cause electric shock and/or damage of ATS358S022. ATS358S022 consists of elements that cannot be fixed by the user. All repairs must be done in manufacturer`s authorized service. Power sockets, RJ45 port, sensor port and cable must be checked before usage if there are no mechanical damages.
-
Page 4: Table Of Contents
ATS358S022: Monitored Automatic Transfer Switch PDU Table of Contents 1. ATS358S022 characteristics ..................1 1.1 Features ......................2 1.2 Package List ...................... 3 2. Panel Description ......................4 2.1 View of server module panel ................4 2.2 View of automatic transfer switch panel............. 5 2.3 Status of LED diodes .................. - Page 5 ATS358S022: Monitored Automatic Transfer Switch PDU 5.3.3.4. Example of signalization when there is a power in primary power source again after the break (when the voltage is stable within 10 seconds)..................18 5.4 Monitoring Settings / Monitoring Configuration Screen ........19 5.4.1 Current section ..................
-
Page 6: Ats358S022 Characteristics
Redundancy improves reliability and provides permanent power supply to appliances. ATS358S022 has two cables, white and black, that are used to connection of two different power sources. First power source, the primary one, is connected to the white cable and the second, secondary one, is connected to the black cable. -
Page 7: Features
The time-delayed switching from the secondary power supply back to the primary power source is an extremely useful feature of this ATS-PDU. If the ATS358S022 did not have this feature and there was a loose contact at power source A, the automatic transfer switch would switch to the primary power supply continuously, i.e. -
Page 8: Package List
ATS358S022: Monitored Automatic Transfer Switch PDU 1.2 Package List 1x ATS358S022: Automatic transfer switch with ammeter & web server and ⚫ 2x Schuko outlets (German standard, 45° rotated) for loads up to 16A 2x Rack Mounting Brackets and screws for installation in 4 orientations ⚫... -
Page 9: Panel Description
ATS358S022: Monitored Automatic Transfer Switch PDU 2. Panel Description 2.1 View of server module panel Figure 2-1 View of server module panel ATS358S022 U.T.E. electronic GmbH & Co. KG www.ute.de... -
Page 10: View Of Automatic Transfer Switch Panel
Green and yellow diodes indicate the power source that supplies the sockets (receivers). Red diode indicates the damage, no current in one of the power sources. Figure 2-2 View of automatic transfer switch panel ATS358S022 2.3 Status of LED diodes Green 0,5 sec. -
Page 11: Description Of Led Signaling
ATS358S022: Monitored Automatic Transfer Switch PDU 2.4 Description of LED signaling only green LED lights, green and red LEDs lights, basic power source works basic power source works second source is available second source is not available yellow and red LEDs lights,... -
Page 12: System Connection
ATS358S022: Monitored Automatic Transfer Switch PDU 3. System Connection 3.1 Usage Precaution Make sure all components and accessories included before installation. ⚫ System should be installed in a clean environment with proper temperature and ⚫ humidity. All of the power switches, plugs, sockets, and power cords should be insulated and ⚫... -
Page 13: Gui Control / Monitoring Setup
ATS358S022: Monitored Automatic Transfer Switch PDU 5. GUI Control / Monitoring setup The Monitored Automatic Transfer Switch PDU ATS258S022 can be controlled via TCP/IP. The default IP settings are: IP Address: 192.168.0.2 Subnet Mask: 255.255.255.0 Gateway: 192.168.0.1 Type 192.168.0.2 in your internet browser, it will enter the below log-in webpage. -
Page 14: Gui Overview
ATS358S022: Monitored Automatic Transfer Switch PDU 5.2 GUI Overview 5.2.1 Menu Admin view Admin can modify all configuration settings of the PDU. U.T.E. electronic GmbH & Co. KG www.ute.de... -
Page 15: Menu User View
ATS358S022: Monitored Automatic Transfer Switch PDU 5.2.2 Menu User view User is entitled just to preview of monitoring menu that contains basic settings and current parameters. U.T.E. electronic GmbH & Co. KG www.ute.de... -
Page 16: Monitoring Overview Screen
ATS358S022: Monitored Automatic Transfer Switch PDU 5.3 Monitoring Overview Screen Basic information about the strip, current values and visualization showing diodes status are shown in the monitoring overview screen. The Admin view is shown as an example here. The view between user and admin is only different in the number and accessibility of the menu items (refer to section 5.2). -
Page 17: Description Of Monitoring Screen Section
ATS358S022: Monitored Automatic Transfer Switch PDU 5.3.1 Description of monitoring screen section 5.3.1.1. Current section • 'Current – Range' column- defines range of possible to measure parameters of current load in Amperes [A] • ‘Current – Current’ column- shows current load value for output sockets. -
Page 18: Power Sources Status Section
ATS358S022: Monitored Automatic Transfer Switch PDU 5.3.1.2. Power sources status section 'Status' column shows two information: 'OK' or 'no power'. Relevant information is showed and it depends on if there is a power in a power source or not. (To make the server works, there is only one active power source needed. -
Page 19: Temperature Monitoring Section
ATS358S022: Monitored Automatic Transfer Switch PDU 5.3.2 Temperature monitoring section To see the values of temperature, it is necessary to connect temperature sensor to RJ9 socket and activate the temperature monitoring which is described in section 5.5.2. If temperature monitoring is not activated, this area is not displayed. -
Page 20: Visualization Of Diodes Actual State
ATS358S022: Monitored Automatic Transfer Switch PDU 5.3.3 Visualization of diodes actual state Presentation of monitoring screen views showing possible states of primary and secondary power sources and power supply in power sockets. The Admin view is also shown as an example in these sections. -
Page 21: Example Of Signalization In Case Of Lack Of Power Supply In Primary Power Source
ATS358S022: Monitored Automatic Transfer Switch PDU 5.3.3.2. Example of signalization in case of lack of power supply in primary power source. • Power source status section: lack of power in primary power source, power in secondary source is available. •... -
Page 22: Example Of Signalization In Case Of Lack Of The Power Supply In Secondary Power Source, Receivers Are Supplied By Primary Power Source
ATS358S022: Monitored Automatic Transfer Switch PDU 5.3.3.3. Example of signalization in case of lack of the power supply in secondary power source, receivers are supplied by primary power source • Power source status section: there is a power in primary power source, lack of power in secondary source. -
Page 23: Example Of Signalization When There Is A Power In Primary Power Source Again After The Break (When The Voltage Is Stable Within 10 Seconds)
ATS358S022: Monitored Automatic Transfer Switch PDU 5.3.3.4. Example of signalization when there is a power in primary power source again after the break (when the voltage is stable within 10 seconds). • Power source status section: there is a power in primary and secondary power source. -
Page 24: Monitoring Settings / Monitoring Configuration Screen
ATS358S022: Monitored Automatic Transfer Switch PDU 5.4 Monitoring Settings / Monitoring Configuration Screen 'Monitoring settings' menu enables setting of circuit and temperature limits. Exceeding these limits will cause the alert. This menu item respectively this section is accessible to administrators only. -
Page 25: Phase Control Section
ATS358S022: Monitored Automatic Transfer Switch PDU 5.4.2 Phase control section • 'E-mail', 'Syslog', 'Log' and 'Trap' checkboxes are used to tick the way of sending alert when a phase fails. The way of sending alert for the primary and secondary phases can be selected and adapted to individual requirements independently of each other. -
Page 26: System Functions Setup / Pdu Configuration Screen
ATS358S022: Monitored Automatic Transfer Switch PDU 5.5 System Functions Setup / PDU Configuration Screen This menu item respectively this section is accessible to administrators only. 5.5.1 Configuration of PDU location and network settings • 'Location' and 'Name' boxes of 'Settings' section allow to describe the place of installation, define location of the PDU in a server room, its functions, etc. -
Page 27: Configuration Of The Temperature Sensor
ATS358S022: Monitored Automatic Transfer Switch PDU 5.5.2 Configuration of the temperature sensor In 'Temperature monitoring' section proper box should be ticked to activate the function of monitoring the limit of temperature value entered in 'Monitoring settings' (refer to section 5.4.3). -
Page 28: Alert Configuration
ATS358S022: Monitored Automatic Transfer Switch PDU 5.6 Alert Configuration This menu item respectively this section is accessible to administrators only. 5.6.1 SMTP setup In 'SMTP – user name' box can be entered up to 40 ASCI signs. ⚫ In 'SMTP – password' box can be entered up to 10 ASCI signs. -
Page 29: Syslog Setup
ATS358S022: Monitored Automatic Transfer Switch PDU 5.6.2 Syslog setup In 'Syslog – IP address for Server' box can be entered 4 numbers from 0 to 255 ⚫ separated by dots. In 'Syslog – port number' box can be entered a number from 0 to 65535. -
Page 30: System Clock Setup / Date And Time Screen
ATS358S022: Monitored Automatic Transfer Switch PDU 5.7 System clock setup / Date and Time screen This menu item respectively this section is accessible to administrators only. In 'Date and time' section current data should be entered. If in 'Alert configuration' section, in SNTP server settings box, correct NTP server data are entered, then update/ revision of the internal clock will be automatically. -
Page 31: Logbook/ System Log Screen
ATS358S022: Monitored Automatic Transfer Switch PDU 5.8 Logbook/ System Log screen This menu item respectively this section is accessible to administrators only. 'System log' tab- this is a system event log. 'Start', 'Previous', 'Next' and 'End' fields allow to change the viewed pages. -
Page 32: Specification
ATS358S022: Monitored Automatic Transfer Switch PDU 6. Specification 6.1 Technical data Connectors (2) Schuko plugs Power Connector 2 meters hard-wired input cables (2) Schuko outlets (German standard) Power Ports 45° rotated Network/ Control (1) Ethernet connector (TCP(IP) - RJ45 sockets... -
Page 33: Reset To Default Settings/ Factory Reset
Connect authorized dealer Broken RJ45 ports. for checking. Note: If your problem still remaining after following the above troubleshooting steps, please contact your local dealer or our technical support (info@ute.de) for further assistance. U.T.E. electronic GmbH & Co. KG www.ute.de... -
Page 34: Customer Service
ATS358S022: Monitored Automatic Transfer Switch PDU 8. Customer Service If there appear some problems when running this device, please check and deal with the problems referring to this user manual. Any transport costs are borne by the users during the warranty. - Page 35 ATS358S022: Monitored Automatic Transfer Switch PDU 5) Technical Support: Email to our after-sales department or make a call, please inform us the following information about your cases. Product version and name. ⚫ Detailed failure situations. ⚫ The formation of the cases.
- Page 36 U.T.E. electronic GmbH & Co. KG Tel: +49 (0)2302 / 28283-0 Fax: +49 (0)2302 / 28283-10 Email: info@ute.de Website: www.ute.de...
