MH-C940
Charger-Analyzer
Thank you for purchasing the Powerex MH-C940 Charger-
Analyzer. Read these instructions carefully before
operating this unit.
GET STARTED VIDEO
Learn how to use the MH-C940 Charger-Analyzer
YouTube Video Link: https://youtu.be/oQFK8UqIxjQ
Or Scan the QR Code with your phone
GENERAL PRECAUTIONS
Do not charge battery cells other than NiMH or NiCD. AA
batteries must be able to accept a 1000mA (Turbo Mode)
/ 500mA (Default Mode) charge current. AAA Batteries
must be able to accept a 500mA (Turbo Mode) / 250mA
(Default Mode) charge current.
Do not use the 2 hour Turbo Mode on AA batteries rated
under 2000mAh and AAA batteries under 700mAh. To
charge them, use the Default Mode (refer to "Default
Mode").
Do not expose the unit to rain or moisture due to the risk
of fire.
Do not operate the charger if it appears damaged in any
way.
Always place the battery cells with positive tip facing the
top. Incorrect polarity may cause fire or explosion.
Observe polarity diagrams located on the charger.
Do not allow the unit to be exposed to direct sunlight.
Operate in well-ventilated area.
Do not allow the battery terminals to become shorted.
PRINTED IN TAIWAN A03-3713510-000
To reduce the risk of damage to the power cord, always
pull by connector rather than the cord.
FEATURES & SPECIFICATIONS
Charges 1-8 AA or AAA NiMH rechargeable batteries
independently
2 Charging Speeds: Default Soft Mode and Turbo Mode
Deep Battery Conditioning System to rejuvenate older
batteries with capacity readout
Backlit LCD display with On/Off option
Ultra quiet fanless operation with thermal protection
Turbo Charge Current:
1000mA (AA), 500mA (AAA)
Default Charge Current:
500mA (AA), 250mA (AAA)
Ninth-Generation MH-
Microprocessor:
NM7108 Powerex Precision
Microprocessor
120 Minutes (Turbo), 240
Charge Time*:
Minutes (Default)
Input Voltage:
AC 100-240V 50-60Hz
* Charge time based on 2000mAh capacity batteries. Charge
time will vary depending upon the brand, capacity, and
condition of batteries being charged.
MODES
This section explains various charging modes and when to use
them. To enable each mode, refer to the "Operation" section.
Default Mode
Soft charge to maximize battery life and
performance. Recharging time is approximately 4-6
hours.
NOTE: Time may vary depending on battery
capacity and how much charge is remaining in the
battery.
Suitable for most NiMH or NiCD batteries.
Recommended if recharging time is not critical.
Turbo Mode
Faster recharging time. Charges twice as fast as the
Default Mode, approximately 2-3 hours.
Recommended for AA NiMH batteries with capacity
of at least 2000mAh and AAA NiMH with capacity of
at least 700mAh.
Conditioning Mode
Rescues degraded batteries and exercise
infrequently used batteries.
Rejuvenates and cycles the batteries. It applies a
special conditioning cycle which restores battery
performance. Requires up to 48 hours to complete
the cycle.
Actual capacity will be displayed at the end of the
conditioning cycle.
Recommended every 6 months or once a year to
ensure battery performance.
OPERATION
Default Mode
1.
Plug the power connector to the charger first then plug
the AC adapter into the wall outlet.
2.
Insert AA and/or AAA batteries. For best performance,
insert the batteries from the left to right.
3.
Once the battery is inserted, charging will commence for
that slot. Each slot number will start flashing indicating it's
charging.
The displayed mAh value represents the amount of
energy that was charged into the battery. It is NOT
the actual capacity of the battery.
4.
Charging time will take approximately 4-6 hours.
Once a battery is done charging, the slot number will stop
flashing and remain solid. The charger will display DONE
for each channel that is done charging. The charged
battery may be removed for use.
The displayed mAh value represents the amount of
energy that was charged into the battery. It is NOT
the actual capacity of the battery.
