Summary of Contents for SmartCow Mars
- Page 1 Mars User's Manual August 2023...
-
Page 2: Copyright And Legal Statement
It is subject to change without notice, and should not be construed as a commitment by SmartCow. SmartCow acts in good faith and attempts to ensure that content is accurate, complete or reliable, but it does not represent it to be error-free. SmartCow, its subsidiaries, the directors, employees, and agents assume no responsibility or liability for any inaccuracies, omissions, or errors that may appear in the content of this document. -
Page 3: Acknowledgements
Acknowledgements All other products’ names or trademarks are properties of their respective owners. ® • NVIDIA , the NVIDIA logo, JetsonTM, Jetson OrinTM, and JetPackTM are trademarks of the NVIDIA Corporation. ® ® • Arm and Arm v8-M architecture are registered trademarks of Arm Limited. ®... -
Page 4: Declaration Of Conformity
Declaration of conformity This equipment has been tested and verified to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 5: Safety Precautions
• All cables and adapters supplied by SmartCow are certified and in accordance with the material safety laws and regulations of the country of sale. Do not use any cables or adapters not supplied by SmartCow to prevent system malfunction or fires. -
Page 6: Warranty And Rma
Additionally, the needed repairing time depends on component acquisition. • Any products returned by SmartCow to other locations besides the customers’ site will bear an extra charge and will be billed to the customer. -
Page 7: Rohs Compliance
In order to meet the RoHS compliant directives, SmartCow has established an engineering and manufacturing task force to implement the introduction of green products. The task force will ensure that we follow the standard SmartCow development procedure and that all the new RoHS components and new manufacturing processes maintain the highest industry quality levels for which SmartCow is renowned. -
Page 8: Table Of Contents
Mars packing list..............................11 Mars accessories list...............................11 Chapter 2: Installing Mars........................12 Mars key components............................12 Connecting Mars to a power source........................13 Connecting IP cameras to Mars..........................14 Chapter 3: Flashing Mars firmware....................15 Putting Mars into recovery mode.......................... 15 Flashing Mars firmware for AGX ORIN 32G......................15... -
Page 9: Chapter 1: About Mars
Mars can handle complex AI models with large volumes of video input analysis and data transmission. This makes it suitable for the construction of smart cities. Other use cases include smart traffic monitoring and running smart factory environments. -
Page 10: Mars Specifications
Mars specifications ® ® NVIDIA Jetson AGX Orin AGX Orin 32GB 8-core NVIDIA Arm Cortex A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3 1792-core NVIDIA Ampere GPU with 56 Tensor Cores Memory 32GB 256-bit LPDDR5 204.8 GB/s Storage 64GB eMMC 5.1 ®... -
Page 11: Mars Ordering Information
200 × 180 × 114mm (L × W × H) Mechanical Dimension Weight Mars ordering information Part number Description HAEGM-AR32/AR64 32G/ 64G AGX Orin with fan, M.2 1TB NVMe SSD, 200 × 180 × 114mm, 24V DC, 100W power adapter, IP65, -20 ~ 60°C... -
Page 12: Chapter 2: Installing Mars
Connecting Mars to a power source • Connecting IP cameras to Mars Mars key components The following section covers the key internal components of Mars. Note: Mars is a IP65-rated device. Therefore, you cannot open or disassemble it. Installing Mars... -
Page 13: Connecting Mars To A Power Source
Connecting Mars to a power source When you connect Mars to a 24V power adapter, the system can boot without any setting. Installing Mars... -
Page 14: Connecting Ip Cameras To Mars
Connecting IP cameras to Mars Installing Mars... -
Page 15: Chapter 3: Flashing Mars Firmware
• Use a USB type A to USB type C cable to connect the USB-C socket on the computer. Then, connect the USB-A to the computer. Procedure You can use one of the following methods to put Mars into recovery mode. • When the device is powered on, follow these steps. a. Keep pressing the recovery button. -
Page 16: Flashing Mars Firmware For Agx Orin 64G
9. Flash the firmware of the Jetson device by running the following command. sudo ./tools/kernel_flash/l4t_initrd_flash.sh --flash-only --massflash 8 Flashing Mars firmware for AGX ORIN 64G Procedure 1. Extract the SmartCow Board Support Package (BSP) image. tar xvjf SmartCow_BSP_image_file_name 2. Flash eMMC by running the following commands. sudo tar xpfv mfi_jetson-agx-orin-devkit_mars64_emmc.tar.gz mv mfi_jetson-agx-orin-devkit mfi_jetson-agx-orin-devkit_mars64_emmc 3. - Page 17 Document control Document version Product version Release date 2023-08-04 Document control...
