Audial Pebble User Manual

Usb & s/pdif d/a converter

Advertisement

Quick Links

D-09
"Pebble"
USB & S/PDIF D/A Converter
User Manual
Rev.A, December 2011
Audial d.o.o Belgrade, Serbia
www.audialonline.com, info@audialonline.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pebble and is the answer not in the manual?

Questions and answers

Summary of Contents for Audial Pebble

  • Page 1 D-09 “Pebble” USB & S/PDIF D/A Converter User Manual Rev.A, December 2011 Audial d.o.o Belgrade, Serbia www.audialonline.com, info@audialonline.com...
  • Page 3 IMPORTANT PRECAUTIONS 1. Do not expose this device to rain or moisture, excessive heat or mechanical force. 2. Use this device exclusively with specified mains voltages. 3. Unplug the device from the wall outlet during a lighting storm. To prevent the risk of electric shock, do not remove the cover! This device contains no user serviceable parts inside.
  • Page 4 Thanks for choosing D-09 D/A converter. This User Manual comprises introducing information on use and performance of this device. For more information please refer to the Audial site, www.audialonline.com/html/d09/, or send your questions to info@audialonline.com.
  • Page 5: Package Content

    Usually, this 3. Invoice (only if unit was sold directly by diode will light only once the playback is Audial). actually started, however with some sources it may light permanently. Along the regular set of unbalanced RCA...
  • Page 6: Everyday Use

    The DAC senses the PLL mode set by the The D-09 USB front stage uses its own PLL switch during the power up sequence supply, that is galvanically separated from (about a half a second after the power up). the rest of the unit and coupled to Hence, to switch between two PLL modes, internal coupling transformer.
  • Page 7: Warranty

    For the units sold directly by Audial, invoice is also guarantee certificate. Since Audial maintains own data base of directly sold units, the original buyers in most cases won’t need it.
  • Page 9: Front Panel

    2 - Signal lock LED indicator 3 - Input LED indicators 4 - Input selector Rear Panel POWER S/PDIF S/PDIF D-09 PEBBLE #01-2345 Made in Serbia OUTPUTS INPUTS 220-240VAC ~50-60Hz FUSE T500mA L250V Analog stereo output (RCA) Digital S/PDIF output (BNC)
  • Page 10: Specifications

    D-09 Specifications INPUTS S/PDIF electrical, true 75 Ohm BNC S/PDIF electrical, RCA S/PDIF optical, Toslink USB 1.1, standard B connector SAMPLING FREQUENCY S/PDIF: ≤ 192kHz USB: ≤ 48kHz OUTPUTS Analog: RCA unbalanced Output voltage: 1.7V RMS Output impedance: ≤ 150 Ohm Digital: S/PDIF electrical, true 75 Ohm BNC FREQUENCY RESPONSE Sin(x)/x equivalent:...
  • Page 12 © 2009-2011 Audial d.o.o. Belgrade Printed in Serbia 2011 •...
