Contact LXTW01N User Manual

ENGLISH - USER MANUAL
Wireless headphones – LXTW01N
1. Characteristics
1.1 Technical specifications
Playtime: 5 hours
Battery: 200 mAh
Frequency range: 20 Hz - 20 kHz
Protection rating: IPX3 (sweat and rain proof)
Operation range: 10 meters
Connectivity: Bluetooth 5.3
Bluetooth frequency range: 2402-2480 GHz
Maximum transmitted power in frequency ranges: 6dbm
Sensitivity: 110±3 dB
Impedance: 32 Ω
Charging time: 2.5 hours
Weight: 193 g
Material: ABS + PU
1.2 In the box
1 x Headset
1 x USB-A to USB-C cable (30 cm)
1 x Jack 3.5 mm (1 m)
1.3 Product details
1. LED indicator
2. M button
3. Volume
1.4 Headphones LED indicators
The headphones LED indicator informs about the state of
the connection, among other aspects:
Pairing
Connected
Power on /
Music play
Charging
2. Initial setup
2.1 Turn on/off the headphones
To turn on the headphones press the multifunction button
for 3 seconds, you will then hear "Power on". To turn them
off, do the same; you will then hear "Power off".
4. ON/OFF
5. Jack port
6. USB-C port
A blue and red light will flash quickly
until the headphones are paired.
The flashing light will turn off.
A blue light will flash every 6
seconds.
A fixed red light will show when you
start charging them. When the
headphones
charged, no light will show.
are completely
