Summary of Contents for Brunner HKD 7 SK

Page 2: Table Of Contents
CONTENTS Notes on ceramic glass..........4 Safety precautions............5 Initial operation.............. 7 Firewood and heating power........8 Basic rules for operation..........12 Components..............16 Door opening............... 17 Cleaning................ 18 Note................19 User Guide (1.1) © 2019 Brunner GmbH...
Page 3 Subject to technical changes! Please keep the User Guide for future reference! Waste on fire = Toxins in your garden © 2019 Brunner GmbH User Guide (1.1)
Page 4: Notes On Ceramic Glass
NOTES ON CERAMIC GLASS BRUNNER uses only ceramic glass supplied by SCHOTT. SCHOTT is an international technology company with over 125 years of experience in the field of specialty glass, special materials and advanced technologies. With over 60 million of sold ROBAX® ceramic glass panes, SCHOTT is a leading manufac- turer of transparent heat resistant materials.
Page 5: Safety Precautions
Under certain cir- cumstances this can lead to risk of flue gas poisoning. The fire- place door must stay closed even if the fire is not burning. © 2019 Brunner GmbH User Guide (1.1)
Page 6 Risk of deflagration! Consult your stove fitter and follow the instructions in chapter "Manual adjusting of com- bustion air in the case of emergency" of the User Guide for the control system. User Guide (1.1) © 2019 Brunner GmbH...
Page 7: Initial Operation
(194°F). Operating temperatures below 60°C (140°F) will cause fast soot build-up on the heat exchanger faces and significant loss of efficiency. Above 95°C (203°F) the thermal discharge safety device will respond, lead- ing the excessive heat safely away. © 2019 Brunner GmbH User Guide (1.1)
Page 8: Firewood And Heating Power
You can support our efforts to protect our environment by respecting the following recommendations for low-emission heating: Use only dry, natural wood with a residual humidity factor below 20%, or wood briquettes according to DIN EN 17225-3. User Guide (1.1) © 2019 Brunner GmbH...
Page 9 >8 cm (3.15 in) (right). What amount of heat will I get when buying wood per weight? 500 kg freshly cut wood Water content 50% 500 kg x 2.0 kWh/kg = 1000 kWh © 2019 Brunner GmbH User Guide (1.1)
Page 10 Too much of firewood or inappropriate fuel types can cause overheating and damage. No kind of waste shall be burned in a fireplace! Waste on fire = Toxins in your garden! User Guide (1.1) © 2019 Brunner GmbH...
Page 11 HKD 7 SK 3,0 kg - 8,0 kg 33 cm - 50 cm 20 cm - 30 cm HKD 7 SK Tun- 3,0 kg - 8,0 kg 33 cm - 50 cm 20 cm - 30 cm At the beginning, set the maximum filling quantity, light it at the top and let it burn.
Page 12: Basic Rules For Operation
The fireplace door must always stay closed, even if the fire is not burning. Stoves and fireplaces from Ulrich Brunner GmbH are designed for period- ic burning. It means that always a minimal amount of firewood has to be loaded and the combustion air must be adjusted according to the following instructions.
Page 13 Please ask your stove setter for the allowed loads and heating in- tervals. Different heating intervals will apply, when the stove is op- erated for the first time! © 2019 Brunner GmbH User Guide (1.1)
Page 14 Important note: Single cracks on fire-resistant combustion chamber linings are no reason for concern. The damper flap is installed in the flue pipe connecting piece between the heating insert and the chimney and regulates the chimney draft. User Guide (1.1) © 2019 Brunner GmbH...
Page 15 This is a normal, unavoidable process and does not constitute a reason for reclamation. Door sealing ropes BRUNNER is using only high-quality door sealing ropes, which are exactly adapted to the requirements of our heating devices. Yet the door sealings are wear parts, and therefore are not covered by our product warranty.
Page 16: Components
COMPONENTS Door handle Door with glass pane Boiler body Operating handle cleaning mechanics Safety heat exchanger User Guide (1.1) © 2019 Brunner GmbH...
Page 18: Cleaning
Lifetime of sealing ropes will be significantly shorter, if they are soaked by fluids or cleaning agents. Curing of the sealing rope can lead to glass breakage! Re- place it when necessary! User Guide (1.1) © 2019 Brunner GmbH...
Page 19: Note
The warranty expires if the device has not been used as intended. Intended use includes reading and following the instructions of this User Guide. It is necessary to follow any other relevant instructions, like the "Operating instructions for tiled stove water boilers"! © 2019 Brunner GmbH User Guide (1.1)
Page 20 My stove fitting company: Ulrich Brunner GmbH Zellhuber Ring 17-18 D-84307 Eggenfelden Tel.: +49 (0) 8721/771-0 Fax: +49 (0) 8721/771-100 Email: info@brunner.de Art.Nr.: 201969 User Guide (1.1) © 2019 Brunner GmbH...

This manual is also suitable for:

Hkd 7 sk tunnel
