VENTED NATURAL
GAS LOG CHASSIS
MODELS
BGLVC18H - 1
/ SKU: 170776
BGLVC24H - 1
/ SKU: 170886
OWNER'S INSTALLATION AND OPERATION MANUAL
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable va-
pors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Before returning to your retailer, contact our customer service department by
PFS F09 - 049
Questions, problems, missing parts?
email at service@bluegrassliving.com
PFS
®
US
Z21.84 - 2017: MANUALLY
LIGHTED, NATURAL GAS
DECORATIVE GAS APPLIANCES
FOR INSTALLATION IN SOLID -
FUEL BURNING FIREPLACES
Advertisement
Table of Contents
Related Manuals for BLUEGRASS BGLVC18H-1
Summary of Contents for BLUEGRASS BGLVC18H-1
- Page 1 ® PFS F09 - 049 Z21.84 - 2017: MANUALLY LIGHTED, NATURAL GAS VENTED NATURAL DECORATIVE GAS APPLIANCES FOR INSTALLATION IN SOLID - GAS LOG CHASSIS FUEL BURNING FIREPLACES MODELS BGLVC18H - 1 / SKU: 170776 BGLVC24H - 1 / SKU: 170886 OWNER'S INSTALLATION AND OPERATION MANUAL WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Specifications ..........3 Inspecting Burners........14 Safety ............3 Care and Maintenance ......14 Product Features ........5 Accessories ..........14 Local Codes..........5 Troubleshooting ........15 Unpacking..........5 Replacement Parts ........17 Air For Combustion and Ventilation ... 6 Parts ............ -
Page 3: Specifications
The fireplace must include a working flue and The charts indicate technical information venting system with the minimum openings regarding the installation of your gas log set. shown as below. Model BGLVC18H-1 BGLVC24H-1 Gas Type Natural Natural BTU Input* 45,000 BTU/Hr... - Page 4 SAFETY 5. You must operate this log set with a fire- WARNING: Any change to place screen in place. Make sure fireplace this log set or its controls can screen is closed before running log set. If be dangerous. the fireplace has glass doors, they must remain OPEN while this log set is in op- eration.
-
Page 5: Product Features
PRODUCT FEATURES ON/OFF SAFETY PILOT VALVE KIT WITH PROPANE CONVERSION An optional on/off valve/safety pilot kit, Model NVDWA2, is available to convert this appliance for use with propane gas. This system requires no matches, batteries, or other sources to light. Follow the instructions provided with the kit to complete the conversion and qualified connection to a propane gas supply, See Check Gas Type under INSTALLATION, on page 6. -
Page 6: Air For Combustion And Ventilation
AIR FOR COMBUSTION AND VENTILATION WARNING: If the area in which WARNING: Before installing in a solid fuel burning fireplace, the heater may be operated does the chimney flue and firebox not meet the required volume for indoor combustion air, combus- must be cleaned of soot, creo- sote, ashes, and loose paint by tion and ventilation air shall be... - Page 7 INSTALLATION INSTALLING DAMPER CLAMP Secure the damper stop clamp provided to Damper the leading edge of the damper as shown in Clamp Figure 2. If for any reason this clamp doesn't Damper work on your fireplace, another suitable clamp or permanent stop must be installed, or the damper blade must be cut or removed.
- Page 8 INSTALLATION Installation and Gas Connection Gas Connector 1. Place the burner pan assembly in the Tube (sold center of the fireplace floor. Make sure separately) the front of pan faces forward. 2. Thread the gas supply fitting to the fire- place gas supply pipe.
- Page 9 INSTALLATION CHECKING GAS CONNECTIONS WARNING: Never use an WARNING: Test all gas piping open flame to check for a leak. and connections for leaks after Apply a noncorrosive leak detec- installing or servicing. Correct tion fluid to all joints. Bubbles all leaks immediately.
- Page 10 DO NOT INSTALL LOGS NOT APPROVED FOR USE ON THIS CHASSIS. The following log kits have been tested and approved for use with this chassis: Model BGLVC18H-1 BVLC18-1 / SKU: 170700 Vented Gas Logs 18in Cluster - Drift-wood BVLC18-2 / SKU: 170701...
-
Page 11: Operation
OPERATION FOR YOUR SAFETY READ BEFORE LIGHTING • Immediately call your gas supplier WARNING: If you do not fol- from a neighbor’s phone. Follow the low these instructions exactly, gas supplier’s instructions. a fire or explosion may result • If you cannot reach your gas supplier, call the fire department. - Page 12 LIGHTING INSTRUCTIONS ( IF USING NVDWA2 PILOT KIT ) 7. Keep control knob pressed in for 30 WARNING: It is recommended seconds after lighting pilot. After 30 sec- that you operate this appliance onds, release control knob. If control knob with the fireplace screen in place.
- Page 13 TO TURN OFF GAS TO APPLIANCE ( IF USING NVDWA2 PILOT KIT ) Shutting Off Appliance Shutting Off Burner Only (pilot stays lit) 1. Push in control knob slightly and turn Push in and turn knob clockwise clockwise to the OFF position. Do the PILOT position.
-
Page 14: Inspecting Burners
INSPECTING BURNERS PILOT FLAME PATTERN ( IF USING NVDWA2 PILOT KIT ) Figure 21 shows a correct and incorrect pi- If pilot flame pattern is incorrect, as shown lot flame patterns. The incorrect pilot flame • turn fireplace off (see To Turn Off Gas to is not touching the thermocouple. -
Page 15: Troubleshooting
ACCESSORIES Model: VLRK-OO SKU: 170557 - Natural Gas - With Propane Conversion - Remote Controlled ON/OFF - Includes CSA Certified Gas Control Valve For all models; an alternative to NVDWA2 for propane installation. TROUBLESHOOTING WARNING: If you smell gas: • Shut off gas supply. •... - Page 16 TROUBLESHOOTING Problem Possible Cause Corrective Action Log set is smoking/ soot- 1. Poor fuel quality. 1. Contact local natural gas ing excessively company. 2. Fireplace venting system not 2. Adjust damper wide open Note: It is natural and drafting properly. and/or have fireplace and unavoidable for vented v e n t i n g p r o f e s s i o n a l l y...
-
Page 17: Replacement Parts
REPLACEMENT PARTS Note: Use only original replacement parts. This will protect your warranty coverage for parts replaced under warranty. PARTS UNDER WARRANTY Contact authorized dealers of this product. • Model and serial number of your heater If they can’t supply original replacement •... -
Page 18: Parts
MODELS BGLVC18H - 1AND BGLVC24H - 1 This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 17 of this manual. ITEM BGLVC18H-1 DESCRIPTION **BL050-01 3/8" Female x 5/8" Flare Adapter... - Page 19 PARTS MODELS BGLVC18H - 1 AND BGLVC24H - 1 www.bluegrassliving.com 164019-01B...
-
Page 20: Warranty
This is Bluegrass Living’s exclusive warranty, and to the full extent allowed by law; this express warranty ex- cludes any and all other warranties, express or implied, written or verbal and limits the duration of any and all implied warranties, including warranties of merchantability and fitness for a particular purpose to one (1) year on new products and 30 days on factory reconditioned products from the date of first purchase.
