Wall mount 2.5kg front load washing machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Wall Mount 2.5Kg
Front Load Washing Machine
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 050122 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Camec 050122

Summary of Contents for Camec 050122

  • Page 1 Wall Mount 2.5Kg Front Load Washing Machine User Manual...

  • Page 2: Table Of Contents

    Contents Safety Precautions ������������������� 2 Installing the Washing Machine �������������� 7 Inspection and preparation before washing�������� 11 Using methods of detergents and additives �������� 14 Overview of the control panel�������������� 16 Maintaining the washing machine ����������� 20 Drum clean ��������������������� 20 Cleaning the enclosure �����������������...

  • Page 3: Safety Precautions

    Safety Precautions Important Safety Symbols and Precautions.Please read this manual carefully before using the product and keep it properly. Please read the instructions carefully and perform operation with caution and care when installing, maintaining and operating your washing machine to make the most of functions and extend the service life of the machine.we are't liable for damages resulting from improper use.
  • Page 4 Safety Precautions Please exclusively use The washing machine 220-240V 220-240V, 50Hz, 10A shall be installed on a and above professional solid wall. Otherwise, AC power outlet. abnormal vibration or noise may occur. If the washing machine In case of gas leakage, does not run, smokes do not touch any button;...
  • Page 5 Safety Precautions If the power cord pins are covered by dust or washing machine but get wet, wipe them contact service clean with dry cloth center when it is tilted before use; otherwise, or unbalanced. a fire may be caused. Children and others who In case of abnormal are not familiar with...
  • Page 6 Safety Precautions Do not plug in / out Please prevent pets or other animals from with wet hands, since entering the drum of this may cause electric the washing machine, shock hazard. which cause injury. Do not spill water on Please unplug the the washing machine washing machine...
  • Page 7 Safety Precautions Do not put the magnet Always unplug near washing washing machine and machine when turn off the water supply machine is running. faucet after use. Do not attempt to repair the washing machine by If the supply cord is yourself.

  • Page 8: Installing The Washing Machine

    This system is designed for mounting the 2.5kg ④ ② ② ③ Camec Wall Mount Washing Machine to structurally sound caravan walls that are ① 20mm - 65mm thick. ③ The washing machine must only be mounted Inside wall of caravan, for to structurally sound caravan walls that are fit...
  • Page 9 Installing the Washing Machine Unpack your washing machine and inspect it for shipping damage. Also make sure that you have received all items shown below. If the washing machine was damaged during shipping or you do not have all items,contact your dealer immediately. ASSY-TUB&DRUM ASSY-DOOR PLUG...
  • Page 10 Installing the Washing Machine Accessories (X1) ERECTING FIXTURE(X1) ASSY-HOSE DRAIN(X1) (X1) MANUAL-BOOK WATER SUPPLY HOSE SET BOLT(X8) THREE-PORT VALVE( X1) INSTALLATION GUIDE(X1) TRUNKING(X1) Power supply ◆To avoid the unnecessary risk of fire, electric shock or personal injury, all electrical circuit and grounding must be set as per the national electrical standard.
  • Page 11 Installing the Washing Machine Water supply ◆ The working water pressure of the washing machine is 0.05MPa~0.8MPa. When the water pressure is below 0.05MPa,the water supply valve may not work normally,or the time of water supply is longer than that of program control,and the display screen shows "SF". ◆...

  • Page 12: Inspection And Preparation Before Washing

    Inspection and preparation before washing To prevent the fault of washing machine and the damage to laundry,you have to pay attention to the following items. 1. Take objects out from the pocket. ◆ Please check and empty the pockets of the laundry. Such hard objects as decorations and coins may damage the washing machine or result in abnormal fault.
  • Page 13 Inspection and preparation before washing 4. To protect the skin of the baby. ◆ Baby's laundry (baby's clothes and towels) such as diapers shall be washed separately. Try to avoid washing with the laundry of adults. 5.Before washing the laundry,take off the metal decorations and zip up the laundry,buckle the collar,then turn over the laundry.
  • Page 14 Inspection and preparation before washing 7.Before washing,please confirm if there are stains on the laundry. ◆ Do not place the laundry in the washing machine for a long time since they may get mildew and stains. ◆ Confirm if the laundry washed for the first time are fading. Wipe the inconspicuous tails of the laundry with a white towel stained with detergent to see if the towel is dyed with the color of the laundry.

  • Page 15: Using Methods Of Detergents And Additives

    Using methods of detergents and additives The user shall pour detergent from the mouth of the drum into the washing machine as required. Should the softener be used, please pour the softener into the drum after the washing procedure. Choose “rinse + spin” or other procedure to wash again. Note:1.Use “low foam”...
  • Page 16 Using methods of detergents and additives ① Connect the water inlet, place the drain pipe and turn on the faucet. ② Power on. ③ Open the machine door to put clothes in, add detergent into the drum and then close the machine door. ④...

  • Page 17: Overview Of The Control Panel

    Overview of the control panel Time display area shows remaining time and delay time. Note: the remaining time reduces gradually with washing; If abnormality occurs during washing, corresponding code will be displayed; If the remaining time is inconsistent with the actual time, it is a normal adjustment made by the program based on actual conditions rather than a fault.
  • Page 18 Overview of the control panel Spin Delicates For care of delicate clothing items, it is not Perform the spin procedure only and spin dry recommended to wash together with other excess water from the clothes. clothes. Strap on the back hookbefore washing. Drum clean Rinse+Spin This program is designed to clean the inner...
  • Page 19 Overview of the control panel 1.Press the Delay button, time displaying“3:00”; 2. Continue pressing the Delay button three times in succession, time displaying “6:00”; 3. The washing will be finished 6 hours later. Method of cancellation: press the power button or change to another washing procedure to exit from this function.
  • Page 20 Overview of the control panel Temp. button The set temperature will be displayed at the temperature display area. Select the appropriate water temperature based on the clothes to be washed. Power button Turn on/off the washing machine by pressing this button. If the washing machine is kept unused for 10 minutes after power on, the power supply will be shut off...

  • Page 21: Maintaining The Washing Machine

    Maintaining the washing machine Keep the washing machine clean to enhance the performance, avoid unnecessary maintenance and increase the service life. Drum clean This is a drum auto clean program and can remove the possibly bred mould in the drum. 1.Turn on the water supply faucet.

  • Page 22: Cleaning The Enclosure

    Maintaining the washing machine Cleaning the enclosure ◆ Before cleaning ◆ Wipe the washing machine ◆ Do not pour water on the washing machine,the machine enclosure,with a soft cloth enclosure in case parts of the shall be unplugged. and nonabrasive household machine would be damaged.

  • Page 23: Handling A Frozen Washing Machine

    Maintaining the washing machine Remove residues and stains on each part and ensure no blockage inside. Reconnect the water supply hose.Turn on the faucet and make sure the connections are watertight. Keep the washing machine clean to enhance the performance, avoid unnecessary maintenance and increase the service life.

  • Page 24: Storing The Washing Machine

    Maintaining the washing machine Pour warm water into the washing machine drum and let warm water it sit for 10 minutes. Reconnect the water supply hose to the water faucet and check if the water supply and drain operations are normal. ◆...

  • Page 25: Troubleshooting

    Troubleshooting Phenomenon Solution ◆ Check whether the installation place of the washing machine is flat or tilted. Washing machine vibrates ◆ Check if the washing machine is touching any other objects. or is too noisy ◆ Check if the laundry load is balanced in the inner drum of the washing machine.
  • Page 26 Troubleshooting Error messages description Error code Code description Solution Check if the door is opened and make sure the door is closed ● firmly. Whether the wiring harness of the computer board falls off. Abnormal door lock ● Check if the plug wire of door switch is loose or has a poor ●...
  • Page 27 Troubleshooting Water heating Check whether the wire harness terminal plugs firmly. ● Please contact the after-sales service department to replace tube failure ● the heating tube or other parts. Press the power button for reboot; run the single spin and ●...

  • Page 28: Product Specifications

    Product specification Model 050122 Rated Voltage 220-240V~ Rated Frequency 50Hz Tap water pressure(MPa) 0.05MPa-0.8MPa Net weight (kg) 18kg Rotation rate of spin 700RPM External dimensions (mm) 575×670×348 Enter into the energy efficiency test program: Engery testing program (energy Cotton 40℃,700rpm): turn on the power, press Power button, then...

  • Page 29: Program Control Board

    Program Control Board MAIN CONTROL PCB CN12 WHT[6P] WHT[7P] CN6WHT[5P] CN10WHT[2P] CN5WHT[10P] CN13 WHT[5P] WHT[4P] WHT[10P] 6 5 4 3 2 1 7 6 5 4 3 2 1 1 2 3 4 5 6 7 8 9 10 1 2 3 4 3 2 1 1 2 3 4 5 1 2 3 4 5 6...

  • Page 30: Warranty

    Warranty...
  • Page 31 Warranty...
  • Page 32 Warranty...
  • Page 33 Camec Pty Ltd 47-63 Remington Drive, Dandenong South, Victoria, 3175 www.camec.com.au...
