Summary of Contents for Trace Engineering 770K Series
- Page 1 Truck Series 770K Kit for Volvo Trucks Installation Guide 1999 Trace Engineering P/N 976-0001-00-01 Rev. A 10/99...
- Page 3 Truck Series 770K Kit Truck Series 770K Kit Installation Guide Table of Contents Section Description Page Installation ..............1 Service Information............9 Warranty ............... 10 1999 Trace Engineering...
- Page 4 • The inverter contains more than one live circuit (AC and batteries). Power may be present at more than one source. • This product contains no user-serviceable parts. Do not attempt to repair this unit. SAVE THESE INSTRUCTIONS 1999 Trace Engineering...
- Page 5 1 ½” dia. flexible plastic split conduit 9” & 12” nylon ties large cable cutters and cable crimpers (optional) 4/0 welding cable and crimp-on ring terminals (optional) 1” dia. shrink tubing (optional) heat gun or gas torch (optional) 1999 Trace Engineering...
- Page 6 C A B P O W E R A C I N P U T C A B F L O O R I N S I D E F L O O R L I N E Figure A Basic Installation and Wiring 1999 Trace Engineering...
- Page 7 ¼” pilot holes drill out the four corner holes with a 5/16” bit use a 2” hole saw to cut out the remaining three holes 1999 Trace Engineering...
- Page 8 Truck Series 770K Kit 1.0 INSTALLATION Figure B Pass-Trough Template Figure C Lower Pass-Through Block Figure D Pass-Through Block - Lower Assembly 1999 Trace Engineering...
- Page 9 RC8 Remote Control Template...
- Page 10 RC8 Remote Control Template Remove this page from the manual and place it over the mounting location. 5916 - 195th Street N.E., Arlington, WA 98223 Phone: (360) 435-8826 Fax: (360) 435-2229 visit our website at: www.traceengineering.com...
- Page 11 Floor Pass-through Template...
- Page 12 Floor Pass-through Template Remove this page from the manual and place it over the mounting location. 5916 - 195th Street N.E., Arlington, WA 98223 Phone: (360) 435-8826 Fax: (360) 435-2229 visit our website at: www.traceengineering.com...
- Page 13 NOTE: Make sure cable runs are clear of the exhaust system and that you allow enough slack for movement of the cab. Figure E Fuse Block Assembly 1999 Trace Engineering...
- Page 14 Blinking Fast - - - - - - - - - - - - - - - - - - Error Figure G RC8 Remote Black White Green White Black Wire Wire or Bare Wire Wire Figure H Inverter Terminal Block 1999 Trace Engineering...
- Page 15 17. Locate the chassis ground lug on the back of the inverter/charger. run the green chassis ground wire to the lug. cut off any excess wire, strip ½” of green insulation from wire, insert into the lug and tighten the set screw to secure wire 1999 Trace Engineering...
- Page 16 NOTE: When you connect the positive battery cable to the positive battery post you can expect a spark. This is caused by the internal capacitors charging and is completely normal. The installation in now complete. Refer to the inverter/charger owner’s manual for complete operating procedures. 1999 Trace Engineering...
- Page 17 Truck Series 770K Kit 2.0 SERVICE INFORMATION Trace Engineering takes great pride in its products and makes every effort to ensure your unit fully meets your independent powering needs. If your product needs repair, contact our Service department at: (360) 435- 8826 to obtain an RMA# and shipping information;...
- Page 18 (4) in components, parts, or products expressly warranted by another manufacturer. Trace Engineering agrees to supply all parts and labor, or repair or replace defects covered by this warranty with parts or products of original or improved design, at its option, if the defective product is returned to any Trace...
- Page 20 5916 - 195th Street N.E., Arlington, WA 98223 Phone: (360) 435-8826 Fax: (360) 435-2229 visit our website at: www.traceengineering.com...
