SkyLine SKY-1005 Instruction Manual

Harnesses / slings / lanyards
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER INSTRUCTIONS MANUAL
FOR SKYLINE HARNESSES / SLINGS / LANYARDS
Document # 120228E
Revision 4
February 2023
This document contains 20 pages
IMPORTANT: Make sure this user instructions manual is the latest version available.
Contact Skyline to obtain the latest document revisions,
important updates and other notices.
Skyline Ziplines Ltd.
6-1006 Lynham Road
Whistler, British Columbia, Canada V0N 1B1
T. 604-905-4149
admin@skylineziplines.ca
www.skylineziplines.ca

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SKY-1005 and is the answer not in the manual?

Questions and answers

Summary of Contents for SkyLine SKY-1005

  • Page 1 Revision 4 February 2023 This document contains 20 pages IMPORTANT: Make sure this user instructions manual is the latest version available. Contact Skyline to obtain the latest document revisions, important updates and other notices. Skyline Ziplines Ltd. 6-1006 Lynham Road Whistler, British Columbia, Canada V0N 1B1 T.
  • Page 2 The information herein is confidential and proprietary to Skyline Ziplines Ltd. Such information may not be used, reproduced or disclosed to others except as is specifically permitted in writing by Skyline Ziplines Ltd. The recipient of this information, by its retention and use thereof, agrees to protect the same as it would its own confidential and proprietary information.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Warnings and important notices...………………………………………………………………………………..… 4 1. Description of the Skyline harnesses, slings, lanyards and ropes…..…………………………………………..… 5 2. Limitations…………………...………………………………………………………………………………….… 11 3. System requirements……..……………………………………………………………………………………… 12 4. Donning and fitting…………….………………………………………………………………………………… 13 5. Training…………………………………………………………………………………………………………… 16 6. Inspection………………………………………………………………………………………………………… 16 7. Maintenance and storage………………………………………………………………………………………... 17 8.

  • Page 4: Warnings And Important Notices

    WARNING: This product is designed for Skyline zip line operations only. The user must read and understand the instructions in this manual before using this equipment.

  • Page 5: Description Of The Skyline Harnesses, Slings, Lanyards And Ropes

    1. DESCRIPTION OF THE SKYLINE HARNESSES, SLINGS AND LANYARDS 1.1 APPLICATIONS: Skyline harnesses, slings and lanyards are to be used as personal equipment for Skyline zip line amusement rides only. 1.2 STANDARDS: Refer to local, provincial/state and federal laws and regulations pertaining to the installation and use of this type of equipment.
  • Page 6 1.3.4 SKYLINE 2-POINT HARNESS, SIZE X-LARGE PRODUCT CODE: SKY-1013 SPECIFICATIONS:  45 mm (1.75”) polyester webbing  Steel adjuster buckles with black polyester coating  Aluminum quick-release adjuster buckles  Color-coding: Blue mesh back  Minimum user weight: 220 lb (100 kg) ...
  • Page 7 1.4 DESCRIPTION OF SKYLINE 1-POINT HARNESS: Skyline 1-point harnesses are tested and certified to standard EN 1651-1999 (Paragliding equipment – Harnesses – Safety requirements and strength tests). 1.4.1 SKYLINE 1-POINT HARNESS, SIZE SMALL PRODUCT CODE: SKY-1008 SPECIFICATIONS:  45 mm (1.75”) polyester webbing ...
  • Page 8 1.5 DESCRIPTION OF SKYLINE PRONE HARNESS: Skyline prone harnesses are tested and certified to standard EN 1651-1999 (Paragliding equipment – Harnesses – Safety requirements and strength tests). 1.5.1 SKYLINE PRONE HARNESS, SIZE SMALL PRODUCT CODE: SKY-1010 SPECIFICATIONS:  45 mm (1.75”) polyester webbing ...
  • Page 9 1000 kg (2250 lb) in straight-pull  Working load limit : 100 kg (225 lb) / lanyard Labelling: This label must be permanently attached to the sling and be fully legible: ©2023, Skyline Ziplines Ltd. SKYLINE - USER INSTRUCTIONS MANUAL rev.4...
  • Page 10 1.8 DESCRIPTION OF SKYLINE DYNEEMA® ROPE 1.8.1 SKYLINE 60” DYNEEMA® ROPE PRODUCT CODE: SKY-1030-60 SPECIFICATIONS:  8 mm (5/16”) Dyneema® rope  1.5 m (60”) length  Break strength: 6033 kg (13300 lb) in straight-pull  Working load limit : 603 kg (1330 lb)

  • Page 11: Limitations

    2.7 RESCUE: Should a rescue be required, the user/supervisor/employer must have a rescue plan and the means at hand to implement it. 2.8 TRAINING: Skyline harnesses, slings and lanyards must only be installed and used by persons trained in their correct application and use (see Section 4).

  • Page 12: System Requirements

    Skyline must determine the compatible connectors that should be used with their equipment. Carabiners used to connect the Skyline 2-point harnesses to the Skyline slings should meet these specifications: Minimum break strength of 2200 kg (4850 lb) Shape must be designed to attach on 45mm (1.75”) wide webbing on one side (harness) and 25mm (1”)

  • Page 13: Donning And Fitting

    4. DONNING AND FITTING 4.1 PROCEDURE FOR DONNING AND FITTING THE SKYLINE 2-POINT HARNESS: 4.1.1 Detach the 2 front quick-connect buckles and loosen the shoulder straps by pulling on the red pull-tabs. 4.1.2 Slip legs in leg loops, and put on both shoulder straps.
  • Page 14 4.2 PROCEDURE FOR DONNING AND FITTING THE SKYLINE 1-POINT HARNESS: 4.2.1 Loosen the shoulder straps and side straps by pulling on the red pull-tabs. 4.2.2 Slip legs in leg loops, and put on both shoulder straps. 4.2.3 Adjust the shoulder straps by pulling on the free end of the webbing by the green pull-tabs, away from the buckle.
  • Page 15 4.4 PROCEDURE FOR INSTALLING THE SKYLINE SLINGS: 4.4.1 Thread the sling end that has the half-twist in the Skyline spreader bar dedicated holes. 4.4.2 Thread the other end of the sling through the half-twist end and pull tight.

  • Page 16: Training

    The Skyline harnesses, slings and lanyards must be inspected before each use. 6.1.2 The Skyline harnesses, slings and lanyards must be inspected by a competent person, other than the user, at least once a year (or more frequently if deemed necessary by the frequency or conditions of use).

  • Page 17: Maintenance And Storage

    A product that was not formally inspected at least once per year should be removed from service and replaced, unless stated otherwise by Skyline after a thorough inspection. Service life begins when the product is used for the first time. Log book must be updated with date of first use.

  • Page 18: Incident/Failure Reporting

    9. INCIDENT/FAILURE REPORTING In the unfortunate situation that a Skyline harness, sling or lanyard is involved in an incident or a failure, please notify Skyline immediately so that prompt corrective measures can be taken. Complete information concerning the incident (date, location, details as to event and consequence, etc) must be communicated to admin@skylineziplines.ca...

  • Page 19: Inspection Form

    - Product has received forces resulting from a fall or shock loading without a subsequent inspection. - Product has undergone modifications or alterations outside Skyline production units. - Product has been in contact with detrimental chemical products or intensive source of heat.

  • Page 20: Inspection Log Sheet

    INSPECTION LOG SHEET FOR SKYLINE HARNESSES, LANYARDS AND SLINGS Model: User identity (company) Serial no: Name: Description: Address: Manufacturer: Skyline Ziplines Ltd Telephone: 6-1006 Lynham Road Fax: Whistler, BC, Canada V0N 1B1 E-mail: Note: Each log entry should have a corresponding inspection form...
