Page 1 INSTALLATION MANUAL Awnings Helios...
Page 2: Table Of Contents
Confirmed 2022-06-13 Awnings Helios CONTENT LIST OF COMPONENTS............................3 PRODUCT DESCRIPTION............................5 S I MPORTANT SAFETY INSTRUCTIONS........................6 PREPARATION FOR INSTALLATION.........................8 INSTALLATION................................8 USE OF THE AWNING ............................15 AWNING FABRIC INFORMATION .......................... 17 MAINTENANCE ..............................17 DISASSEMBLY AND STORAGE ..........................18 GENERAL WARRANTY CONDITIONS ........................19...
Page 3: List Of Components
Confirmed 2022-06-13 Awnings Helios IMPORTANT: Read this manual before use and installation of the product. Keep this manual for the future. LIST OF COMPONENTS Main technical parameters Maximum size for wall mounting: 6.0 x 3.5 m (width x depth); Maximum size for ceiling mounting: 5.0 x 3.0 m (width x depth);...
Page 4 IMPORTANT! Fixing elements are not included in the set. Fixing elements (bolts, anchors, etc.) must be bought before the installation, considering the structure of the wall for the installation. If you are unsure about the choice of fixing elements, consult the specialists (fixing elements) or contact Acorn Blinds experts for the installation of the awning.
Page 5: Product Description
Confirmed 2022-06-13 Awnings Helios PRODUCT DESCRIPTION The structure of the terrace awning is intended for installation on the wall or ceiling of the building. The awning fabric can be unfolded with the help of a handle (manual control) or a motor (motor control), thus creating sun and visual protection.
Page 6: S I Mportant Safety Instructions
Confirmed 2022-06-13 Awnings Helios Fabric Front profile cover 7 Cartridge Front profile Side cover Elbow Bracket IMPORTANT SAFETY INSTRUCTIONS For your safety and the safety of others, you must follow and observe the safety instructions below. Symbol description This warning sign in the manual indicates the danger that can result in serious injuries or death or are important to the proper operation of the awning.
Page 7 Do not start the installation without proper fixing elements. The awning can be installed only on a flat wall or ceiling of the building. If the wall or ceiling is unstable or cracked, consult construction specialists or contact Acorn Blinds experts for the installation.
Page 8: Preparation For Installation
This manual is intended for mounting on a solid masonry or brick wall or stable and solid ceiling. If the wall or ceiling of the building for the installation of the awning consists of porous blocks and have an insulation layer or clinker finish, we recommend that you contact Acorn Blinds experts for the installation.
Page 9 Confirmed 2022-06-13 Awnings Helios The base must be flat (not convex) so that the awning brackets are mounted in one plane. Brackets mounted in an uneven plane can cause the whole structure to become curved/crushed, and the awning might be damaged or operate incorrectly.
Page 10 Confirmed 2022-06-13 Awnings Helios ATTENTION! The fixing points of the brackets must be aligned horizontally! Otherwise, you won’t be able to insert the awning into the brackets and adjust it because the holes will be already drilled. We recommend double-checking if the fixing line of the brackets is completely horizontal and in the same line! If you have a possibility, use a laser level for marking fixing points ATTENTION! The central bracket shown is only required if the width of the awning is >...
Page 11 Confirmed 2022-06-13 Awnings Helios You can also attach to the ceiling using a ceiling bracket. Put the awning bracket on the marked lower hole and mark the appropriate points on the wall or ceiling. The bracket should be attached with five bolts. Use the spirit level to make sure that holes of each bracket are aligned vertically.
Page 12 Confirmed 2022-06-13 Awnings Helios 4. Insert anchoring pins Use only heavy-duty anchor pins and bolts suitable for the wall structure (at least 5 kN load per point). Insert the anchoring pin After drilling, blow dust out of the holes. Insert heavy-duty anchoring pins. If necessary, use the hammer to insert the pins into the wall.
Page 13 Confirmed 2022-06-13 Awnings Helios...
Page 14 For your safety and the safety of others, we recommend that you contact Acorn Blinds professionals for assistance.
Page 15: Use Of The Awning
Confirmed 2022-06-13 Awnings Helios USE OF THE AWNING Angle adjustment The recommended slope is adjusted by the manufacturer (25 degrees), but you can adjust the slope after the installation if required: from 3 to 72 degrees. A slope of fewer than 14 degrees is not recommended, although the adjustment mechanism allows for a smaller angle.
Page 16 Confirmed 2022-06-13 Awnings Helios Unfolding and folding of the awning and manual control. The awning can be unfolded and folded using the included handle. Attach the hook of the handle on the ring located on the side specified in the order. Unfold or fold the awning by turning the handle.
Page 17: Awning Fabric Information
Confirmed 2022-06-13 Awnings Helios AWNING FABRIC INFORMATION Only the highest quality materials are used for the production of awnings. However, even with the most advanced technologies, it is impossible to avoid certain fabric changes that occur to some degree in almost all awning fabrics.
Page 18: Disassembly And Storage
Confirmed 2022-06-13 Awnings Helios • Cleaning of visible and accessible components. Inspection of the structure and mounting points; • Regularly check if wall brackets are attached properly. Tighten the brackets if they are loose. • Check all the bolts and nuts once every six months and tighten them if they are loose.
Page 19: General Warranty Conditions
Confirmed 2022-06-13 Awnings Helios • If you plan to reassemble the awning on the same wall later, we recommend that you do not disassemble and leave the wall brackets in place. • If you reassemble the awning on the same wall brackets, inspect the stability and solidity of the brackets before installation.
