- Page 1 E V A N 8 0 6 0 B 1 - M N 0 1 0 1 q u i c k s t a r t g u i d e O c t . 5 , 2 0 2 3 ©Mitsubishi Electric Corporation...
- Page 2 S u m m a r y o f E V A N 8 0 6 0 B 1 - M N 0 1 0 1 ◆ EVAN8060B1-MN0101 includes the evaluation board integrated MCU and shutter which are necessary to evaluate the MelDIR with the PC.
- Page 3 Set “MelDIR”on the holder, and fix the cover with screws again. MelDIR Holder Cover （2）Connect evaluation board and MelDIR by attached cable. Connect to a PC by a microB-A USB cable for data communication. Cable USB port (microB) Back side ©Mitsubishi Electric Corporation...
- Page 4 (1) Go to the following web site and download VCP driver. https://www.ftdichip.com/old2020/Drivers/VCP.htm Zip file is available from "Available as a setup executable" on the right side of Windows* in the table. (2) Extract the zip file, then run CDM21228_Setup.exe and install the driver software. ©Mitsubishi Electric Corporation...
- Page 5 （2）Double-click IR_VIEW.exe in the folder below. /MIRVIEW-V301(E)/Executable Port Closed under ”Capture Control” （3）Click （3） tab. (Port Opened is shown and the button turns red.) （4） （4）Click Power. (The button turns red.) （5） （5） Click Init Sensor. (The button turns red.) ©Mitsubishi Electric Corporation...
- Page 6 (4) USER button USER button on evaluation （4）Press (Capture stop) board to stop acquisition of thermal images. ・Please refer to “MelDIR MCU demo kit start manual_V301(E) v1.10” included with the viewer software for detailed functions and usage. ©Mitsubishi Electric Corporation...
-
Page 7: Power Off
（3）The frame rate is changed from 8 fps to 4 fps （1） High Sensitivity(4 fps) checkbox under “Capture Control” tab is checked before POWER ON. This suppresses noise and improves quality of thermal images. （3） （3）Make settings with POWER OFF ©Mitsubishi Electric Corporation... - Page 8 •The Demo Kit are provided for the evaluation and verification. Do not incorporate in a final product, regardless of the application. If the customer would install into a final product, Mitsubishi Electric Corporation shall not be liable for all harms.
- Page 9 • Do not use or store in a location with dust, salt, or iron powder. Dust or other contaminants may collect in or on the product and cause failure. • Do not use in a location with intense static electricity or electromagnetic waves. Risk of product failure. ©Mitsubishi Electric Corporation...
- Page 10 MITSUBISHI ELECTRIC CORPORATION Model : EVAN8060B1-MN0101 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 12 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Mitsubishi Electric EVA-8060B1-MC02V1-01...
