RG-EST310V2
Note
The device and software will be upgraded constantly. Please
contact Ruijie technical support for details.
Management software WSP-EST310 V2 has been installed on the
device.
Part Description
RG-EST310V2 Camera End
RG-EST310V2 Video Recorder End
24V/0.5A PoE Power Adapters
Anchors
Mounting Brackets
Self-Tapping Screws (ST4.2Q9)
Pole Clamps
Warranty card
Quick Start Guide
Power Cable
Networking
Wireless Bridge User Manual
Parts List
1
Qty
1
1
2
4
2
4
4
1
1
2
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ruijie Networks RG-EST310V2
Summary of Contents for Ruijie Networks RG-EST310V2
- Page 1 Ruijie technical support for details. Parts List Management software WSP-EST310 V2 has been installed on the device. Part Description RG-EST310V2 Camera End RG-EST310V2 Video Recorder End 24V/0.5A PoE Power Adapters Anchors Mounting Brackets Self-Tapping Screws (ST4.2Q9) Pole Clamps Warranty card...
- Page 2 Camera Switch Switch Camera-Switch(Optional)-Camera End Video Recorder End-Switch-Server LED & Ports LED Description System LED Blinking Green: The device is being booted. Solid Green: The device is working properly. LAN LED Off: No cable is connected. Blinking Green: Link is up. The port is sending or receiving data. Solid Green: Link is up.
- Page 3 Solid: The stronger the signal gets, the more LEDs light up. 12V DC Power Port Inner Diameter: 2.1mm. Outer Diameter: 5.5mm. LAN/PoE Port Reset Button...
- Page 4 Cable Connection Video Recorder End PoE Power Adapter LAN/PoE PoE Max Distance: 100m (CAT5/6/7 Cable) Camera End PoE Power Adapter LAN/PoE Port PoE Max Distance: 100m (CAT5/6/7 Cable) Mounting the Device Pole Mounting 1. Secure the mounting bracket to the pole by threading two clamps...
- Page 5 through the mounting bracket. Install the device to the mounting bracket. Wall Mounting Secure the mounting bracket on the wall. Install the device to the mounting bracket. Bridging Management The wireless bridges are used in pairs without extra configuration. If you want to manage the bridge or view data, both App management and Web management are available.
- Page 6 2. Open a browser window, enter http://192.168.120.1 into the address bar and press Enter. Wired Login Set the IP address on your computer. IP Address: 10.44.77.100 Subnet Mask: 255.255.255.0 Gateway: 10.44.77.254 2. Open a browser window, enter http://10.44.77.254 into the address bar and press Enter.
- Page 7 One-to-Many Settings Select Master Bridge Select any video recorder end as the master bridge and power on the device. Select Slave Bridge Select any other device (either video recorder end or camera end) as the slave bridge and take the following steps to configure the slave bridge.
- Page 8 Select Camera(CPE) and click Next Click Scan and select an SSID from the dropdown list or enter an SSID (Example: @Ruijie-wds-xxxx. xxxx indicates the last four...
- Page 9 Click Submit. 8. The Mode LED on the video recorder end is solid on and the Mode LED on the camera end blinks at 0.5 Hz 9. If you want to add camera ends, please take the above steps again. Notes 1 .Please make sure that there are no obstacles between both ends.
- Page 10 location, it is recommended to select one-to-many solution to reduce cost and improve efficiency. 6. Please make sure that the distance between both ends are over 2 meters. 7. The Mode LED on the video recorder end is solid on and the Mode LED on the camera end blinks at 0.5 Hz 8.
