Summary of Contents for Eiki A Series
- Page 1 Solutions to have more efficient presentation and better decision-making User Manual (A SERIES) Version: V1.0...
-
Page 2: Table Of Contents
Solutions to have more efficient presentation and better decision-making Contents Contents ......................1 Package Contents ....................2 Overview ......................2 Features ......................5 Application Diagram ..................5 Quick Guide ....................... 6 Specifications ....................8 Troubleshooting ....................11... -
Page 3: Package Contents
1 x 12V 2A Power Supply 1 x Power Cord, US type Antenna CD within User manual Overview A SERIES is wireless collaboration system, it aims to provide solutions to have more efficient presentation and better decision-making. Front View... - Page 4 Solutions to have more efficient presentation and better decision-making Indicates the status of Base Unit. LED Status Description static blue during the boot process connect successfully, ready to share content LED Strip upgrade is completed blinking blue connection is in process ...
- Page 5 Solutions to have more efficient presentation and better decision-making Button Indicates the status of Button. LED Status Description static blue during the boot process connect successfully, ready to share content pairing is in process blinking blue connection is in process LED Strip ...
-
Page 6: Features
Solutions to have more efficient presentation and better decision-making Features One-click to wirelessly share content from PC or laptop Using 2.4GHz or 5GHz band to guarantee a great wireless connection Provides a runtime executable software that does not require installation ... -
Page 7: Quick Guide
Solutions to have more efficient presentation and better decision-making Quick Guide Connect the Base Unit and the display devices Connect the power supply Power on Base Unit and displays Insert the Button into a USB port of computer Browse to and execute the application Click the Button to share content when connection is completed (LED strip of the Button is static blue) After executing the application, the application icon appears in the system tray,... - Page 8 Solutions to have more efficient presentation and better decision-making 12. Insert the Button in the USB port of specific Base Unit 13. Unplug the Button from the Base Unit when the LED strip of the Button turns to static red from static blue, now the Button is ready for use 14.
-
Page 9: Specifications
Solutions to have more efficient presentation and better decision-making Specifications Technical Input USB, Type A male 1 x HDMI, Type A 19-pin female Output 1 x VGA, D-SUB female 1 x Stereo out, 3.5mm ear jack Recommended Windows 7/8.1/10, Mac OS X 10.10 and later, Android 4.1 and operating system later, iOS 9.0 and later Input resolutions... - Page 10 Solutions to have more efficient presentation and better decision-making Encryption AES CCMP Number of simultaneous on screen Number of simultaneous connections iOS/Android Airplay mirroring and available via third party DLNA apps for portable devices JPG image content compatibility PC minimum requirements: CPU: Intel Pentium Dual Core, 1.83GHz Memory: 2048 MB RAM PC recommended requirement:...
- Page 11 Solutions to have more efficient presentation and better decision-making Base Unit: Aluminum Alloy Chassis Material Button: Plastic Device Dimension Base Unit: 7.4”x1.6”x4.3” (188mmx40mmx110mm) Button: 3.2”x0.6”x2.0” (80mmx15mmx50mm) (W x H x D) Package Dimension 15.3”x2.6”x10.4” (388mmx67mmx264mm) (W x H x D) 4.19 lbs.
-
Page 12: Troubleshooting
Solutions to have more efficient presentation and better decision-making Troubleshooting Problem Cause Solution No automatic refresh of Refresh the view on computer Can’t find the drive after drives Reconnect to the USB port or try inserting the Button Bad connection at USB port another USB port The computer doesn’t meet Try another computer which... - Page 13 Solutions to have more efficient presentation and better decision-making Put the Base Unit closer Change the orientation of the antennas Low signal strength Remove as much as possible all obstructions between the Buttons and the Base Unit Use of overlays, 3D or Some programs of windows are Disable overlays or hardware...
- Page 14 Solutions to have more efficient presentation and better decision-making Notes Please read the user manual carefully before operating. Contents shown in this manual are for reference only. Appearances, features, specifications are subject to change without notice, please contact technical support for the latest details.
- Page 15 Solutions to have more efficient presentation and better decision-making Engineering manual A. To access the Web Interface via the LAN 1. Open a browser 2. Browse to the LAN IP address shown in the top left corner of the welcome screen, then a login screen appears a) The LAN IP address is only valid when the Base Unit is connected to the LAN router or the LAN port of the computer...
- Page 16 Solutions to have more efficient presentation and better decision-making B. To access the Web Interface via the wireless network 1. Connect to the Base Unit wireless network. The default SSID and password are ‘ESHOW+Mac ID’ and ‘12345678’. a) Make sure the frequency band of the Base Unit is set to 2.4GHz if the computer or the portable device doesn’t support 5GHz, or those devices will not be able to connect to the Base Unit via the wireless network 2.
- Page 17 Solutions to have more efficient presentation and better decision-making 3. SettingsVideo out. Click Save to confirm the changes HDMI Resolution list VGA Resolution list...
- Page 18 Solutions to have more efficient presentation and better decision-making 4. MaintainStatus 5. MaintainReset factory. Click Reset to execute factory reset 6. MaintainPassword.Click Save to confirm the changes 7. HelpVersion...
