Summary of Contents for indie Realplum iND83205
- Page 1 iND83205 “Realplum” Realplum EVB Quick Start Guide 6/8/2020 Application Note...
-
Page 2: Table Of Contents
Application Note EALPLUM UICK TART UIDE 1.0 T ABLE OF ONTENT 1.0 TABLE OF CONTENT ....................2 2.0 LIST OF FIGURES ..................... 3 3.0 REALPLUM HARDWARE INTRODUCTION ............. 4 Realplum IC ............................. 4 Realplum EVB ............................6 3.2.1 Realplum EVKit Features ........................7 3.2.2 Realplum EVB Schematic ........................ -
Page 3: List Of Figures
Application Note EALPLUM UICK TART UIDE 2.0 L IST OF IGURES Figure 1: Realplum Block Diagram ....................5 Figure 2: Realplum Evaluation board ....................6 Figure 3: Realplum EVB Schematic ....................7 Figure 4: Screenshot – new folder in IAR devices area ..............8 Figure 5: Screenshot –... -
Page 4: Realplum Hardware Introduction
Application Note EALPLUM UICK TART UIDE 3.0 R EALPLUM ARDWARE NTRODUCTION 3.1 R EALPLUM The ”RealPlum” IC is an automotive LED lighting integrated device that combines together a 32bit MCU (Cortex M0) with a power management unit capable of handling 45V Load dump from the car battery, 3 high voltage constant current open drain IO with PWM, a LIN slave transceiver supporting LIN auto-addressing, a LIN master transceiver for extension and an integrated 10 bit ADC for monitoring, aging and temperature compensation purpose. - Page 5 Application Note EALPLUM UICK TART UIDE ▪ LDO 3.3Vout (ASIC Core and IO supply + MCU I/O) ▪ LDO 1.5VOut (MCU Core/Flash) Package: 4x4 mm 20 lead QFN package Application: Figure 1: Realplum Block Diagram 5/18 Realplum EVK Quick Start Guide rev 0.2 6/8/20 Proprietary and Confidential information...
-
Page 6: Realplum Evb
Application Note EALPLUM UICK TART UIDE 3.2 R EALPLUM The Realplum evaluation board (EVB) is a convenient platform for users to test the capabilities of the device The EVB provides access to each of the chip’s pins for easy testing. An RGB LED is installed on the EVB, and each output can be debugged via a jumper. -
Page 7: Realplum Evkit Features
TART UIDE 3.2.1 Realplum EVKit Features ▪ Realplum 32-bit Cortex M0 Indie Semiconductor’s Realplum 32-bit ARM Cortex M0. ▪ Power Management Power is supplied to the EVB from an external DC power supply using a screw terminal connector. ▪ Red/Green/Blue LED ▪... -
Page 8: Realplum Evb Board Configuration
Application Note EALPLUM UICK TART UIDE 3.3 R EALPLUM BOARD CONFIGURATION J4 must be shorted with a jumper to apply VIN to the Realplum device. Three jumpers are needed at J1 to provide power for the red, green, and blue LEDs. When programming by the SWD port, a jumper may be needed at J8 to provide the debugger with a VTT reference voltage of 3.3V. - Page 9 TART UIDE Figure 5: Screenshot – new folder in IAR flashloader area 2) Copy the indie Realplum Software Development Kit into your working area: Unzip the provided file - libdev.realplum.B1.01.02.00.0000.zip (or similar / later revision) anywhere in your working environment.
- Page 10 Application Note EALPLUM UICK TART UIDE Figure 7: Screenshot – device file location in IAR 5) Locate the Realplum flashloader config files The flashloader files are provided within the software development kit. They are located under the following directory: libdev.realplum.B1.01.02.00.0000\drivers\flashloader Figure 8: Screenshot –...
- Page 11 Figure 9: Screenshot – flashloader file location in IAR You are now ready to launch IAR and the Realplum SDK code: 7) Go back to the indie Realplum SDK directory and launch Realplum IAR project (IAR IDE Workspace) Figure 10: Screenshot – SDK project area 11/18 Realplum EVK Quick Start Guide ...
- Page 12 Application Note EALPLUM UICK TART UIDE The project will open. Select the Realplum_app tab as circled in the figure below. Figure 11: Screenshot – Realplum_app tab 12/18 Realplum EVK Quick Start Guide rev 0.2 6/8/20 Proprietary and Confidential information...
- Page 13 Application Note EALPLUM UICK TART UIDE Now you can build the demo code: Figure 12: Screenshot – Rebuild All There may be a list of Warnings and these can be ignored. 13/18 Realplum EVK Quick Start Guide rev 0.2 6/8/20 Proprietary and Confidential information...
- Page 14 Application Note EALPLUM UICK TART UIDE The code is now ready to be loaded into the Realplum microcontroller: Figure 13: Screenshot – Download and Debug Once the code has been loaded into the MCU, you are now able to run it (DEBUG\GO) 14/18 Realplum EVK Quick Start Guide ...
-
Page 15: Annex: Overview Of Iar Config
➔ General Options within the IAR Project should indicate the indiesemi Realplum device Figure 14: Screenshot – IAR device selection ➔ The links to debugger and flash programmer are within the indie Realplum SDK: Figure 15: Screenshot – IAR flashloader selection You can now re-flash the Realplum evaluation board with the SDK code and explore its structure. -
Page 16: Revision History
Application Note EALPLUM UICK TART UIDE 6.0 R EVISION ISTORY Rev # Date Action 6/5/2020 Initial Release 6/8/2020 General clean up work, improved figure captions 16/18 Realplum EVK Quick Start Guide rev 0.2 6/8/20 Proprietary and Confidential information... -
Page 17: Contacts
Application Note EALPLUM UICK TART UIDE 7.0 C ONTACTS United States 32 Journey Aliso Viejo, California 92656, USA Tel: +1 949-608-0854 sales@indiesemi.com China D2-608, China Sensor Network Innovation Park, 200#, LinHu Road, XinWu district, WuXi City, China +86 139 1837 6572 Scotland Hobart House 80 Hanover St... - Page 18 Purchasers’ products. No license, express or implied, to any intellectual property right is granted by indie semiconductor by this document. The materials, products and information are provided “as is” without warranty of any kind, whether express, implied, statutory, or otherwise, including fitness for a particular purpose or use, merchantability, performance, quality or non-infringement of any intellectual property right.
- Page 19 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: indie Semiconductor iND83209/EVK01...
