ARMATURA Vanguard Series Quick Start Manual

Vanguard Series Smart Reader
Model: VG10CKQ
Quick Start Guide
Version1.0
The Vanguard series stands out as one of the most compact multi-frequency RFID readers
currently on the market. It boasts compatibility with over 100 RFID card types, along with
the ability to recognize QR codes, and supports both NFC and Bluetooth Low Energy
credentials. Furthermore, it offers Bluetooth support for Armatura ID/Armatura Connect
and ACMS systems.
Parts Included
Make sure your box contains everything listed. If any pieces are missing, contact your dealer.
Please save the original box and packing materials if you ever need to ship your device.
VG10CKQ Reader (1pc)
Quick Start Guide (1pc) and Mounting Template (1pc)
Mounting Plate (1pc)
Screwdriver (1pc)
Grub screw/Countersunk KA3.6 x 1.57 inchs (40mm) self – tapping screws (4pcs) and
Anchors (4pcs) – for mounting directly to a wall (no junction box)
Torx screw TM3 x 0.24 inches (6mm) (1pc) – for fixing the reader to the mounting plate
Recommended Parts(not supplied)
Cable
5-10 conductor (Wiegand)
4 conductor Twisted Pair Over-All Shield and UL approved, Belden 3107A or equivalent
(OSDP)
Certified LPS DC power supply
Metal or plastic junction box
Drill with various bits for mounting hardware
Mounting hardware
3
Reader Connection
The Vanguard Series Reader communicates with the control panel using either
RS-485 (OSDP) or Wiegand.
Pigtail
Red
Black
Red/Green
Brown
Bare
Green
White
Orange
Pink
Yellow
Violet
1. Connection via Wiegand.
2. Connection via RS-485 (OSDP).
+VDC
GND
485-
485+
www.armatura.us
Description
+9 - 24V DC
Ground
RS-485 A
RS-485 B
Drain
Wiegand Data 0
Wiegand Data1
Green LED Input
Red LED Input
Beep Input
Tamper
Tamper
Beep
Red LED
Green LED
Wiegand Data 1
Wiegand Data 0
Ground
+9~24V DC
+9~24V DC
Ground
RS-485 B
RS-485 A
1
Product Overview
1
2
3
2
Installing The Reader On The Wall
1
Attach the mounting template
1.
sticker to the wall 59 inches
from the ground (adjustable)
and drill holes according to
59"(1.5m)
the mounting paper.
2. Secure the mounting plate on
the wall with the wall mounting
screws.
2
3. After passing the wires through
the wiring hole and connected,
and then attach the device to
the mounting plate from top
to bottom.
4.
Fasten the device to the mount-
ing plate with a security screw.
4
Using And Testing The Reader
Turn on the reader,
and it will emit a beep while
the LEDs flash.
5
Frequency Bands And Maximum Output Power
Frequency bands
2402MHz - 2480MHz
125kHz
13.56MHz
6
Certificate Information
ARMATURA LLC www.armatura.us
Copyright © 2022 ARMATURA LLC. All rights reserved.
1 LED Indicator
4
2
Touch Keypad
5
3 QR Coce Scanner &
6
Card Reading Area
4 Speaker
5 Beeper
6 Tamper Switch
Cable
7
7
8 Mounting Hole
8
1.77"(45.0mm)
3
4
Present the credential to the
reader and you will hear a beep
acknowledging the credential.
Maximum output power
6.59dBm
3.8dBuA/m@10m
-22.20dBuA/m@10m
E-mail: sales@armatura.us
0.96"(24.5mm)
Scan QR Code
Card
Virtual Card
