Summary of Contents for OBERON Arc Series
- Page 1 Arc Flash Curtain Cube Assembly Instructions...
- Page 2 BLUE MONSTER PVC cement available at Home Depot and other outlets. Open carton and remove six (6) PVC tubes, 64-1/2” long, and a box containing the feet. Carefully remove fabric with attached PVC tubing and webbing. © Oberon | All rights reserved. Page 2 of 10...
- Page 3 Assembly Instructions Arc Curtain Cube 3. Unroll fabric and tubing on a large, clean table or floor. Unfold the three sections and lay flat. © Oberon | All rights reserved. Page 3 of 10...
- Page 4 Tee. “Foot” the Tee and using the rubber mallet, tap the other end of the tube in until it bottoms out. Repeat with the other five (5) tubes. © Oberon | All rights reserved. Page 4 of 10...
- Page 5 Next, still “footing” the base Tees, position the elbows on the top crossbar over the previously assembled tubes and tap elbows in until they bottom out on both sides. Repeat with the other two (2) crossbars. © Oberon | All rights reserved. Page 5 of 10...
- Page 6 Cement all six (6) tubes to the Tee joints. 10. Install feet as per instruction #8. DO NOT GLUE Tee feet. You may choose to glue the “Mono feet” in place. This is recommended. © Oberon | All rights reserved. Page 6 of 10...
- Page 7 Wrap the excess cord around the crossbar and tie it off with two (2) half hitches or a knot of your choice that won’t come loose. Tighten up the other two (2) panels. © Oberon | All rights reserved. Page 7 of 10...
- Page 8 Tighten the lacing so as to cause the fabric to be taut in the frame. Tie off as required and finish the other two (2) panels. 14. Stand the unit up ... DONE! © Oberon | All rights reserved. Page 8 of 10...
- Page 9 Assembly Instructions Arc Curtain Cube 15. The Oberon Arc Flash Curtain Cube is designed to fold in on itself for easy storage. 16. For more configuration ideas and to see the Curtain Cube in action, visit the Arc Flash Curtain Cube page on our website.
- Page 10 Oberon 375 Faunce Corner Road North Dartmouth, MA 02747 USA P: 800.322.3348 F: 508.999.4443 service@oberoncompany.com www.oberoncompany.com...
