IMAGE VIDEO
Division of 1077541 Ontario Limited
Revision: A, January 2011
© 2011 Image Video, Division of 1077541 Ontario Limited
Contents of this document may not be reproduced in any form without the written
permission of Image Video.
Image Video
Division of 1077541 Ontario Limited
1620 Midland Ave.
Scarborough, Ontario
Canada M1P 3C2
Phone:
+1 416-750-8872
Fax:
+1 416-750-8015
Web:
www.imagevideo.com
Support:
support@imagevideo.com
Sales:
sales@imagevideo.com
TSI-3000 Tally System Interface
Instruction Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Image TSI-3000
- Page 1 Division of 1077541 Ontario Limited TSI-3000 Tally System Interface Instruction Manual Revision: A, January 2011 © 2011 Image Video, Division of 1077541 Ontario Limited Contents of this document may not be reproduced in any form without the written permission of Image Video. Image Video Division of 1077541 Ontario Limited 1620 Midland Ave.
-
Page 2: Table Of Contents
PREFACE......................IV 1 INTRODUCTION ....................1 1.1 GENERAL ........................ 1 1.2 TALLY CONTROL SYSTEM OVERVIEW ............1 1.3 TSI-3000 TALLY SYSTEM INTERFACE OVERVIEW........2 1.3.1 TSI-3000 Specifications..................3 1.4 TSI-3000ACO AUTO CHANGE-OVER OVERVIEW ........... 4 1.4.1 TSI-3000ACO Specifications ................5 1.5 WARRANTY ......................6 2 INSTALLATION....................7... -
Page 3: List Of Tables
3.2.4.3 Detailed Network Connectivity Page............18 3.2.5 TSI-3000 Setup Page..................19 3.2.6 TSI-3000 Operation Information Page.............. 20 3.2.7 TSI-3000 Internal Hardware Resources Page ........... 20 3.2.8 TSI-3000 Configuration Tools Page ..............21 3.2.8.1 Clear Configuration .................. 21 3.2.8.2 Remove Inter-TSI Network Configuration..........21 3.2.8.3 Start FTP Server.................. - Page 4 Throughout this manual the TSI-3000 Tally System Interface is also referred to as the TSI or the TSIs when referring to both TSI-3000s in a redundant system. The TSI- 3000ACO Auto Change-Over is also referred to as the ACO.
-
Page 5: Introduction
TSI-3000 Tally System Interface and TSI-3000ACO Auto Change-Over units. This information in this section is intended to assist the user in understanding the functioning of a tally control system and the role of a TSI-3000 in it. 1.2 Tally Control System Overview The Image Video tally control system is an essential component of broadcast and production environments. -
Page 6: Tsi-3000 Tally System Interface Overview
• Monitor tally system from PC with on-screen display of multiple monitor walls The Image Video Tally System quickly identifies originating sources carried to any point in your signal switching system. It traces a signal's path through various types of routing and processing equipment including routing switchers, production switchers, and master control switchers. -
Page 7: Tsi-3000 Specifications
One power supply is standard and a second supply can be added for increased device reliability. For increased system reliability the TSI can be paired with another TSI-3000 and a TSI- 3000ACO Auto Change-Over for redundant controller operation. -
Page 8: Tsi-3000Aco Auto Change-Over Overview
COM 6 Figure 3: TSI-3000ACO Front and Rear View The TSI-3000ACO selects the active controller in an Image Video Tally Control System with redundant TSI-3000s. It interfaces to both TSIs to monitor their operational state in order to determine the best controller to run the system. All serial I/O connections are routed through the ACO allowing the ACO to switch all serial I/O connections to the active TSI. -
Page 9: Tsi-3000Aco Specifications
Image Video Introduction 1.4.1 TSI-3000ACO Specifications Physical Dimensions 44.5 mm high x 483 mm wide x 406 mm deep (1.75 in. high x 19 in. wide x 16 in. deep) Weight 6.71 kg (14.8 lb.), including interconnect cables and 2 supplies 8.21 kg (18.1 lb.), shipping... -
Page 10: Warranty
If during a period of ninety (90) days from the date of original purchase for use, an Image Video product requires a part replacement, due to defective materials or workmanship,... -
Page 11: Installation
TSIs. 2.2 Mounting The TSI-3000 and the TSI-3000ACO units are intended to be mounted in a standard 19 inch rack. There are no special mounting requirements, however, it should be noted that any excessive direct light on the front of the unit can make the LCD and status LEDs difficult to distinguish. -
Page 12: Tsi-3000Aco Power
TSI A TSI B unlabelled 68-pin connectors on the respective TSIs using the male 68-pin half-pitch ‘D’ to male 68-pin half-pitch ‘D’ cables. connections on the rear of the ACO are not used in a TSI-3000 system. COM2 Revision: A... -
Page 13: Serial I/O Ports
Image Video Installation 2.6 Serial I/O Ports The TSI-3000 provides 11 independent serial I/O ports: one RS-232 serial port and ten RS-422/485 serial ports. These ports are used to control and monitor other serially connected devices in the tally control system. -
Page 14: Serial Ports Com7 To Com12
TSI-3000 Tally System Interface Instruction Manual Image Video The 6P6C modular jack connector provides a convenient wiring interface to many Image Video products that also use a modular jack for serial I/O. These ports can also be used for any device that needs an RS-422 or RS-485 serial connection. Adapters are available to convert the port to a 9-pin ‘D’... -
Page 15: Ethernet Ports
See the separate TSI-3000 system programming documentation for details. When the TSI-3000 has more than one Ethernet port the user must ensure the network matches the IP address configuration of the port it is attached to. In a system with redundant TSIs network connections must be made to both TSIs. -
Page 16: Linear Time Code Reference
LTC CLOCK REF. connected tally displays. The TSI-3000 will read a play speed (x1 speed) SMPTE or EBU format linear time code signal. The TSI-3000 can also be programmed to read SMPTE 309M or Leitch format date information from the time code user bits. See the separate TSI-3000 system programming documentation for details. -
Page 17: Connector Clearance
Installation 2.11 Connector Clearance The 9-pin ‘D’ connectors spacing on the rear panel of the TSI-3000 and the TSI- 3000ACO may restrict the selection of the mating connector backshell. Most 9-pin D connector backshells are less than 0.65” (16.5 mm) high; however, sample parts should be evaluated prior to purchasing production quantities. -
Page 18: Figure 10: Tsi-3000Aco Connector Clearance
TSI-3000 Tally System Interface Instruction Manual Image Video COM 9 COM 10 COM 11 COM 12 TSI B COM 1 COM 2 COM 3 COM 4 COM 5 COM 6 Figure 10: TSI-3000ACO Connector Clearance Revision: A... -
Page 19: Configuration And Operation
The TSI-3000 user interface panel is used to configure the basic setup of the TSI and monitor the operation of the TSI and the external devices connected to it. -
Page 20: General Operation
The Escape button is used to go back to a previous menu level and to discard a data entry. On start-up the User Interface Panel displays its firmware version. The display will change to the main status screen after the TSI-3000 application software has loaded and started. -
Page 21: Communication Status
3.2.4 Communication Status Pages The communication status pages show status of the external devices programmed to communicate with the TSI-3000. There is one page with the summary of all devices and individual detail pages for each device. 3.2.4.1 Communication Summary Page The communication summary page gives the connectivity status of all the serial ports and any network connected devices. -
Page 22: Detailed Network Connectivity Page
3.2.4.3 Detailed Network Connectivity Page The detailed network connectivity page shows the programmed and operational details of the devices configured to communicate with the TSI-3000 with a network connection. This page is shown when a network configured device is selected in the communication summary page. -
Page 23: Tsi-3000 Setup Page
3.2.5 TSI-3000 Setup Page The TSI-3000 setup page shows the unit identification and network interface settings of the TSI-3000. This page is shown when the Setup button is selected from the main status screen. The Unit ID cell is the unique number assigned to a TSI or TSI redundancy pair to distinguish it in a tally control system with several TSIs. -
Page 24: Tsi-3000 Operation Information Page
Selecting the Save and Reboot button in the main menu bar will restore save any changes to the cell values and initiate a TSI-3000 reboot. A prompt is displayed after the Save and Reboot button is selected to confirm the user’s intent to save the new cells values and reboot the TSI. -
Page 25: Tsi-3000 Configuration Tools Page
TSI-3000. In these cases it can be useful to clear the TSI-3000 configuration and reload the newest configuration from the tally System Console. -
Page 26: Setup Using Tally System Console 2
TSI PS Figure 12: TSI PS Front View The TSI-3000 is powered by one or two TSI PS internal plug-in power supplies. The standard TSI is equipped with one power supply. For power supply redundancy an optional second power supply can be installed. With power supply redundancy both supplies share the load equally;... -
Page 27: Tsi-3000Aco Operation
3.5.1 TSI-3000ACO Operational Mode The TSI-3000ACO operates in one of three modes: automatic selection of the active TSI- 3000, manual selection of the ‘A’ TSI-3000, and manual selection of the ‘B’ TSI-3000. The operating mode is selected using the front panel rotary switch. -
Page 28: Active Status
TSI-3000 Tally System Interface Instruction Manual Image Video LED Colour Condition Description Not ready No heartbeat signal is being received from the TSI. This problem is usually caused by the TSI being turned off or not connected to the ACO. - Page 29 Image Video Configuration and Operation LED Colour Condition Description Power Source The external power source is connected to the ACO; however, there is no power from the source. The problem is usually caused by the power adapter being unplugged from the wall outlet.
-
Page 30: Maintenance
To maintain a proper CPU operating temperature is it necessary to periodically open the TSI-3000 and clean out any dust or debris that may have accumulated on the fans or be restricting air flow. How often this needs to be done is dependent on the environment the TSI is operating in. -
Page 31: Exchanging A Tsi Ps
LED on the just inserted supply will illuminate to indicate it not providing power. 6. Install the 2 front panel screws to secure the power supply to the TSI-3000 frame. 7. Turn on the power switch and confirm the power LED illuminates and the fault LED goes off.
