CH67
SPECIFICATIONS
·
Weight capacity is 3 lbs MAX.
1
Determine the position and location of the part on the work
surface. Mark the mounting position for the mounting
hardware and drill a 6.00mm [1/4"] DIA. pilot hole for
drywall or a 3.00mm [1/8"] DIA. pilot hole wood
installation.
2022.10.05
33.00mm
[1-5/16"]
79.00mm
[3-1/8"]
FRONT VIEW
Stud
PILOT HOLE
TABLE OF CONTENTS
SIDE VIEW
2
Place plastic anchor into the pilot hole. Skip this step for
wood installation.
1
. . . . . . . . . . . . 1X CH67
. . . . . . . . 1X Mounting Base
. . . . . . . . . . . 1X Hex Key
. . . . . . . . . . 1X Set Screw
. . . . . . . . 1X Plastic Anchor
. . . . . . . . . . . 1X 1-7/16"
No. 8
Wood Screw
10.00mm
[13/32"]
16.00mm SQ.
[5/8"]
65.00mm
[2-9/16"]
Plastic Anchor
(For drywall
use only)
Advertisement
Summary of Contents for Mockett CH67
- Page 1 SPECIFICATIONS TABLE OF CONTENTS · ... . 1X CH67 Weight capacity is 3 lbs MAX..1X Mounting Base ... 1X Hex Key .
- Page 2 No. 8 Wood Screw CH67 Mounting Base Use hex key to loosen set screw. Tilt CH67 down to release Align and secure the mounting base with 1-7/16" No. 8 mounting base. wood screw. Secure the part using set screw and hand-tighten with the Align CH67 to mounting base.
