WH1A
!
·
Neck and base will not be level. This is to ensure that bottles
are displayed as close to level as possible.
·
Dimensions are based on general bottle measurements.
·
Actual bottle measurements will vary based on type and
manufacturer.
SPECIFICATIONS
·
Recommended bottle size is 750ml MAX.
1a
Right Facing
PLACE LEVELER HERE
Base
Determine the position, orientation and location for the part
on the work surface. Tape one side of the template then
place leveler below template. Once template is level, secure
by taping other side.
2022.09.12
WARNING
!
4"
TOP VIEW
Neck
Template
8" O.C.
Leveler
(Not Included)
TABLE OF CONTENTS
23/32" DIA.
4"
1b
Left Facing
PLACE LEVELER HERE
Neck
Leveler
(Not Included)
Determine the position, orientation and location for the part
on the work surface. Tape one side of the template then
place leveler below template. Once template is level, secure
by taping other side.
1
. . . . . . . . . . . 1X WH1A
Base
. . . . . . . . . . . 1X WH1A
Neck
. . . . . . . . . . 2X Rosette
. . . . . . . . . 2X Nylon Wall
Anchor
. . . . . . . . . 2X 1-31/32"
Wood Hanger Screw
. . . . . . . . . . . 1X 7/8"
Wood Hanger Screw Driver
. . . . . . . . . 1X Template
23/32" DIA.
FRONT VIEW
Base
Template
8" O.C.
