PiPe
55|60|65
Shower Drain Heat Recovery
THREADED PUSHFIT
P. 7
THREADED PUSHFIT UK
P. 13
THREADED CEMENT
P. 19
IMPORTANT
IMPORTANTE
BELANGRIJK
INSTALLATION MANUAL
MANUAL DE INSTALAÇÃO
MANUAL DE INSTALACIÓN
INSTALLATION MANUEL
INSTALLATIONSANLEITUNG
INSTRUKCJA INSTALACJI
INSTALLATIEHANDLEIDING
GUIDA ALL'INSTALLAZIONE
WICHTIG
WAŻNY
1
Advertisement
Related Manuals for Aliaxis zypho PiPe 55
Summary of Contents for Aliaxis zypho PiPe 55
- Page 1 PiPe IMPORTANT IMPORTANTE THREADED PUSHFIT P. 7 WICHTIG 55|60|65 WAŻNY THREADED PUSHFIT UK P. 13 BELANGRIJK THREADED CEMENT P. 19 INSTALLATION MANUAL MANUAL DE INSTALAÇÃO MANUAL DE INSTALACIÓN INSTALLATION MANUEL INSTALLATIONSANLEITUNG INSTRUKCJA INSTALACJI INSTALLATIEHANDLEIDING GUIDA ALL’INSTALLAZIONE Shower Drain Heat Recovery...
-
Page 2: Maintenance
TECHNICAL DATA Before the freshwater connection a non-return valve Before proceeding to assembly, please make sure all and a shut-off valve should be installed. the following conditions are verified Do not thermally insulate the PiPe. It is required that • Max. mains water pressure endured : 6 bar; the distance from the shower to the PiPe is kept to •... - Page 3 DADOS TÉCNICOS ao PiPe não seja superior a 3 metros para reduzir as Antes de proceder à instalação, por favor certifique-se perdas de calor e garantir uma boa eficiência. que todas as condições seguintes se verificam: Sugerimos a utilização de torneira de duche termos- •...
-
Page 4: Informations Techniques
INFORMATIONS TECHNIQUES de chaleur et de garantir une bonne efficacité. Avant de poursuivre l’assemblage, veuillez confirmer On suggère l’utilisation d’un robinet de douche ther- si toutes les conditions sont vérifiées: mostatique. • Pression max. de l’eau prise en charge: 6 bar; •... - Page 5 DANE TECHNICZNE metry, aby zmniejszyc straty ciepła i zapewnic dobra Przed przystapieniem do montazu nalezy upewnic sie, wydajnosc. Zalecamy zastosowanie termostatycznej ze wszystkie ponizsze warunki zostały baterii prysznicowej. • Zweryfikowane Maks. dopuszczalne cisnienie wody w Niezastosowanie sie do OPCJI KONFIGURACJI INSTALA- sieci: 6 barów;...
- Page 7 PiPe THREADED PUSHFIT 55|60|65 PIPE 55 ZYPI55GDTP00 PIPE 60 ZYPI60GDTP00 PIPE 65 ZYPI65GDTP00 Shower Drain Heat Recovery...
- Page 8 PiPe INSTALLATION OPTIONS / INSTALLAZIONE CONFIGURAZIONE OPZIONI / OPÇÕES INSTALAÇÃO / OPCIONES CONFIGURACIÓN / OPTIONS D’INST / 55|60|65 INSTALLATIONSSOP / OPCJE INSTALACJI / INSTALLATIE OPTIES THREADED Hot water Preheated water Cold water PUSHFIT Água quente Água pré-aquecida Água fria Agua caliente Agua precalentada Agua fría Eau chaude...
- Page 9 PiPe THREADED DIMEN PUSHFIT 55|60|65 Product body Corpo del prodotto Corpo do produto Cuerpo del producto Ø75 mm Corps du produit Grundkörper Korpus produktu Productbehuizing Cleaning access Apertura per pulizia Acesso de limpeza Accès au nettoyage Ø50 mm Acceso de limpieza Zugang reinigen Czyszczak Reinigingstoegang...
- Page 10 PiPe 55|60|65 Pre-heated water out Cold water in Shower water out 2X 45˚ Elbow...
- Page 11 PiPe THREADED PUSHFIT 55|60|65 Shut-o valve (Not supplied) Shut-o valve & Non-return valve type EA (Not supplied) TEST Double check valve (Not supplied)
- Page 13 PiPe THREADED PUSHFIT UK 55|60|65 PIPE 55 ZYPI55GDTI00 PIPE 60 ZYPI60GDTI00 PIPE 65 ZYPI65GDTI00 Shower Drain Heat Recovery...
- Page 14 PiPe INSTALLATION OPTIONS 55|60|65 THREADED PUSHFIT UK Hot water Preheated water Cold water 55 40 55 40 55 40 55 40 The preheated water is transferred to the tap only. The preheated water is transferred to the boiler only. 55 40 55 40 55 40...
- Page 15 PiPe THREADED PUSHFIT UK 55|60|65 DIMEN Product body Ø75 mm Cleaning access Ø50 mm Shower water out Ø43 mm Cold water in BRASS ¾” Pre-heated water out BRASS ¾” Shower water in Rubber o’ring Ø50 mm Fixing clamp Metal / Rubber 450 Elbow Ø50 mm 900 Tee...
- Page 16 PiPe 55|60|65 Pre-heated water out Cold water in Shower water out 1X Reducer Ø50-Ø43 mm 2X 45˚ Elbow...
- Page 17 PiPe THREADED PUSHFIT UK 55|60|65 Shut-o valve (Not supplied) Shut-o valve (Not supplied) Double Double check valve check valve (Not supplied) (Not supplied) TEST...
- Page 19 PiPe THREADED CEMENT 55|60|65 PIPE 55 ZYPI55GDTS00 PIPE 60 ZYPI60GDTS00 PIPE 65 ZYPI65GDTS00 Shower Drain Heat Recovery...
- Page 20 PiPe INSTALLATION OPTIONS / INSTALLAZIONE CONFIGURAZIONE OPZIONI / OPÇÕES INSTALAÇÃO / OPCIONES CONFIGURACIÓN / OPTIONS D’INST / 55|60|65 INSTALLATIONSSOP / OPCJE INSTALACJI / INSTALLATIE OPTIES THREADED Hot water Preheated water Cold water CEMENT Água quente Água pré-aquecida Água fria Agua caliente Agua precalentada Agua fría Eau chaude...
- Page 21 PiPe THREADED DIMEN CEMENT Product body 55|60|65 Corpo del prodotto Corpo do produto Cuerpo del producto Ø75 mm Corps du produit Grundkörper Korpus produktu Productbehuizing Cleaning access Apertura per pulizia Acesso de limpeza Accès au nettoyage Ø50 mm Acceso de limpieza Zugang reinigen Czyszczak Reinigingstoegang...
- Page 22 PiPe 55|60|65 Pre-heated water out Cold water in Shower water out 2X 45˚ Elbow...
- Page 23 PiPe THREADED CEMENT 55|60|65 Shut-o valve (Not supplied) Shut-o valve & Non-return valve type EA (Not supplied) TEST Double check valve (Not supplied)
- Page 24 5 anos 5 años 5 lat 5 jaar 5 aastat 5 go Shower Drain Heat Recovery UNITED KINGDOM POLAND https://www.aliaxis.co.uk http://www.aliaxis-ui.pl +44 1480 442 600 +48 22 329 7900 customerservice@aliaxis.com +48 71 399 5674 lcholast@aliaxis.com IBERIA (SPAIN & PORTUGAL) THE NETHERLANDS https://www.aliaxis.es...
